ASTM A213 / ASME SA213 T9 T91 T92 Alloy Steel Seamless tube for Boiler , Superheater , Heat exchanger application

ASTM A213 / ASME SA213 T9 T91 T92 Alloy Steel Seamless tube for Boiler , Superheater , Heat exchanger application

ASTM A213 / ASME SA213  T9 T91 T92 Alloy Steel Seamless tube for Boiler , Superheater , Heat exchanger application
video
ASTM A213 / ASME SA213  T9 T91 T92 Alloy Steel Seamless tube for Boiler , Superheater , Heat exchanger application
Product Details:
Place of Origin: China, Gernmany , Japan
Brand Name: YUHONG
Certification: ISO9001-2008 PED , AD2000, LR, API 5L
Model Number: ASTM A213 T9, T91, T92, ASME SA213 T9, T91, T92
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 10days->
Payment Terms: T/T, L/C
Supply Ability: 5000 tons per month
Contact Now
Detailed Product Description
Standard: ASTM A213, ASME SA213 Grade: T9, T91, T92
Application: Boiler, Heat Exchanger NDT: Eddy Current Test, Hydrostatic Test , Ultrasonic Test
Highlight:

carbon steel seamless tube

,

boiler condensate pipe





ASTM A213 / ASME SA213 T9 T91 T92 Alloy Steel Seamless tube for Boiler , Superheater , Heat exchanger application



Yuhong Group supply huge qty of Cr-Mo Alloy seamless pipe and tube , and export more than 35 countries . Our alloy seamless tube be width used in boiler and heating.



YUHONG controls the entire manufacturing process from raw material to finished products, Inspection points are localed in the manufacturing process to ensure all products meet all requirements. In such quality control system, faults are detected at the earliest possible stage of the production process in order to eliminate the risk of rejection at final inspection. We have made continuous efforts to reduce the problem throughout total quality assurance system including traceability control, YUHONG not only inspect by ourself , also through TPI like BV, SGS, DNV, ABS, MOODY, IBR, so that today the quality of our productsis clearly recognized by our client.




Carbon Chromiun Low Temperature Stainless Steel Duplex Copper& Bronze Titanium Ni-Alloy
SA178-A SA213-T1 SA333-Gr.1 SA213 TP316L A789-S31803 SB111-C70600 SB338-GR.1 SB163 NO2200
SA178-C SA213-T11 SA333-Gr.3 SA249 TP316H A789-S32205 SB111-C71500 SB338-GR.2 SB167 NO2201
SA179 SA213-T12 SA333-Gr.6 SA268 TP316Ti A789-S32750 SB111-C71640 SB338-GR.5 SB444 NO8020
SA192 SA213-T22 SA333-Gr.7 SA269 TP316LN A789-S32760 SB111-C68700 SB338-GR.7 SB514 NO6022
SA209-T1 SA213-T5 SA333-Gr.8 SA376 TP321 A789-S32707 SB111-C44300 SB338-GR.9 SB619 N10276
SA209-T1a SA213-T9 SA334-Gr.1 TP304 TP321H A789-S32304   SB338-GR.12 SB622 NO4400
SA209-T1b SA213-T91 SA334-Gr.3 TP304L TP347 A789-S31500     SB626 NO6600
SA210-A1   SA334-Gr.6 TP304H TP347H S31254     SB674 NO6601
SA210-C   SA334-Gr.7 TP304N TP405 254MA     SB677 NO6625
SA214   SA334-Gr.8 TP310H TP409 17-4PH     SB704 NO690
SA513 MT 1010     TP310S TP410 17-7PH     SB705 NO8800
SA513 MT 1015     TP309S TP430 15-7PH     N1001 NO8810
SA513 MT 1020     TP317 TP439       N10665 NO8811
      TP317L TP444       N10675 NO8825
      TP348 TP446       TP904L
      TP347HFG





Tube Sizes for Heat Exchangers & Condensers & Boiler

Outside Diameter   BWG
25 22 20 18 16 14 12 10
  Wall Thickness mm
0.508 0.71 0.89 1.24 1.65 2.11 2.77 3.40
mm inch   Weight kg/m
6.35 1/4 0.081 0.109 0.133 0.174 0.212
9.53 3/8 0.126 0.157 0.193 0.257 0.356 0.429
12.7 1/2   0.214 0.263 0.356 0.457 0.612 0.754
15.88 5/8   0.271 0.334 0.455 0.588 0.796 0.995
19.05 3/4   0.327 0.405 0.553 0.729 0.895 1.236
25.4 1   0.44 0.546 0.75 0.981 1.234 1.574 2.05
31.75 1 1/4   0.554 0.688 0.947 1.244 1.574 2.014 2.641
38.1 1 1/2   0.667 0.832 1.144 1.514 1.904 2.454 3.233
44.5 1 3/4       1.342 1.774 2.244 2.894 3.5
50.8 2       1.549 2.034 2.574 3.334 4.03
63.5 2 1/2       1.949 2.554 3.244 4.214 5.13
76.2 3       2.345 3.084 3.914 5.094 6.19
88.9 3 1/2       2.729 3.609 4.584 5.974 7.27
101.6 4         4.134 5.254 6.854 8.35
114.3 4 1/2         4.654 5.924 7.734 9.43





ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Chemical Composition and Mechanical Properties

Grade Chemical Composition%
C Si Mn P, S Max Cr Mo Ni Max V Al Max
T2 0.10~0.20 0.10~0.30 0.30~0.61 0.025 0.50~0.81 0.44~0.65
T11 0.05~0.15 0.50~1.00 0.30~0.60 0.025 1.00~1.50 0.44~0.65
T12 0.05~0.15 Max 0.5 0.30~0.61 0.025 0.80~1.25 0.44~0.65
T22 0.05~0.15 Max 0.5 0.30~0.60 0.025 1.90~2.60 0.87~1.13
T91 0.07~0.14 0.20~0.50 0.30~0.60 0.02 8.0~9.5 0.85~1.05 0.4 0.18~0.25 0.015
T92 0.07~0.13 Max 0.5 0.30~0.60 0.02 8.5~9.5 0.30~0.60 0.4 0.15~0.25 0.015
Grade Chemical Composition% Mechanical Properties
W B Nb N T. S Y. P Elongation Hardness
T2 ≥ 415MPa ≥ 205MPa ≥ 30% 163HBW(85HRB)
T11 ≥ 415MPa ≥ 205MPa ≥ 30% 163HBW(85HRB)
T12 ≥ 415MPa ≥ 220MPa ≥ 30% 163HBW(85HRB)
T22 ≥ 415MPa ≥ 205MPa ≥ 30% 163HBW(85HRB)
T91 0.06~0.10 0.03~0.07 ≥ 585MPa ≥ 415MPa ≥ 20% 250HBW(25HRB)
T92 1.50~2.00 0.001~0.006 0.04~0.09 0.03~0.07 ≥ 620MPa ≥ 440MPa ≥ 20% 250HBW(25HRB)

ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Tolerance

Outside Diameter OD Tolerance WT Tolerance Ovality Tolerance Cut Length Tolerance
OD≤ 12, 7 mm ± 0, 13 mm ± 15 % + 3, 18 mm, – 0 mm
12, 7 mm < OD ≤ 38, 1 mm ± 0, 13 mm ± 10 % max, 1, 65 mm + 3, 18 mm, – 0 mm
38, 1 mm < OD ≤ 88, 9 mm ± 0, 25 mm ± 10 % max, 2, 41 mm + 4, 76 mm, – 0 mm
  • T11 Alloy Steel Tube for power generation, petroleum, and other high temperature services
  • T22 Alloy Steel Tube for power generation, petroleum, and other high temperature services
  • T5 Alloy Steel Tube for petroleum
  • T9 Alloy Steel Tube for petroleum
  • T91 Alloy Steel Tube for power generation
  • T92 Alloy Steel Tube for power generation
  • T1 Alloy Steel Tube for boiler replacement and repair
  • SA209 T1 tube for Manufacturing Boilers
  • ASTM A213/ ASME SA213 T5 Alloy Steel Tube for Superheaters
  • ASTM A213/ ASME SA213 T5 Alloy Steel Tube for Heat Exchangers

ASTM A213 / ASME SA213  T9 T91 T92 Alloy Steel Seamless tube for Boiler , Superheater , Heat exchanger application 0
