Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22 WP5 P9 P91 P92 ELBOW TEE REDUCER CAP FOR OIL AND GAS

Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22 WP5 P9 P91 P92 ELBOW TEE REDUCER CAP FOR OIL AND GAS

  • Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22  WP5  P9  P91  P92  ELBOW  TEE  REDUCER  CAP FOR OIL AND GAS
  • Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22  WP5  P9  P91  P92  ELBOW  TEE  REDUCER  CAP FOR OIL AND GAS
  • Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22  WP5  P9  P91  P92  ELBOW  TEE  REDUCER  CAP FOR OIL AND GAS
  • Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22  WP5  P9  P91  P92  ELBOW  TEE  REDUCER  CAP FOR OIL AND GAS
  • Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22  WP5  P9  P91  P92  ELBOW  TEE  REDUCER  CAP FOR OIL AND GAS
Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22  WP5  P9  P91  P92  ELBOW  TEE  REDUCER  CAP FOR OIL AND GAS
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG GROUP
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015, IEI
Model Number: ASTM A234 WP11, WP22, WP5, P9,P91, P92
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: Ply-wooden Case Or Iron Case
Delivery Time: 10 DAYS
Payment Terms: L/C, T/T
Supply Ability: 200 TONS PER MONTH
Contact Now
Detailed Product Description
Material: ASTM A234 WP11, WP22, WP5, P9,P91, P92 Size: OD: 1/2" NB - 48" NB. WT: SCH 10S - SCH XXS
Dimension: ANSI B16.9, MSS SP 43 Type: ELBOW , TEE, REDUCER, BEND ELBOW, CAP ,CROSS
Application: Oil And Gas
High Light:

butt welding fittings

,

forged steel fittings



Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22 WP5 P9 P91 P92 ELBOW TEE REDUCER CAP FOR OIL AND GAS



Carbon Steel Pipe Fitting - Long Radius Elbow 90

Butt Weld Fitting , ASTM A234 WPB ,90DEG. ELBOW , LR , 1" SCH40 BW B16.9 , Black Painting

Standard

Nominal
Pipe Size
Outside
Diameter
Inside
Diameter
Wall
Thickness
Center
To End
Pipe
Schedule
Weight
Pounds
1/2 0.84 0.622 0.109 1.5 40 0.16
3/4 1.05 0.824 0.113 1.5 40 0.17
1 1.32 1.049 0.133 1.5 40 0.4
1 1/4 1.66 1.38 0.14 1.88 40 0.55
1 1/2 1.9 1.61 0.145 2.25 40 0.8
2 2.38 2.07 0.154 3 40 1.6
2 1/2 2.88 2.47 0.203 3.75 40 3.2
3 3.5 3.07 0.216 4.5 40 4.8
3 1/2 4 3.55 0.226 5.25 40 6.6
4 4.5 4.03 0.237 6 40 8.9
5 5.56 5.05 0.258 7.5 40 15.1
6 6.62 6.07 0.28 9 40 24
8 8.62 7.98 0.322 12 40 47.8
10 10.75 10.02 0.365 15 40 83.4
12 12.75 12 0.375 18 * 123
14 14 13.25 0.375 21 30 155
16 16 15.25 0.375 24 30 206
18 18 17.25 0.375 27 * 262
20 20 19.25 0.375 30 20 324
24 24 23.25 0.375 36 20 466
30 30 29.25 0.375 45 * 720
36 36 35.25 0.375 54 * 1,039
42 42 41.25 0.375 63 * 1,420
48 48 47.25 0.375 72 * 2,000

Extra Strong

Nominal
Pipe Size
Outside
Diameter
Inside
Diameter
Wall
Thickness
Center
To End
Pipe
Schedule
Weight
Pounds
1/2 0.84 0.546 0.147 1.5 80 0.26
3/4 1.05 0.742 0.154 1.5 80 0.29
1 1.32 0.957 0.179 1.5 80 0.48
1 1/4 1.66 1.27 0.191 1.88 80 0.79
1 1/2 1.9 1.5 0.2 2.25 80 1.2
2 2.37 1.93 0.218 3 80 2.1
2 1/2 2.88 2.32 0.276 3.75 80 3.8
3 3.5 2.9 0.3 4.5 80 6.3
3 1/2 4 3.36 0.318 5.25 80 8.6
4 4.5 3.82 0.337 6 80 12.5
5 5.56 4.81 0.375 7.5 80 21.2
6 6.63 5.76 0.432 9 80 34.4
8 8.63 7.63 0.5 12 80 71.3
10 10.75 9.75 0.5 15 60 111
12 12.75 11.75 0.5 18 * 158
14 14 13 0.5 21 * 201
16 16 15 0.5 24 40 270
18 18 17 0.5 27 * 348
20 20 19 0.5 30 30 422
24 24 23 0.5 36 * 604
30 30 29 0.5 45 20 997
36 36 35 0.5 54 20 1,380
42 42 41 0.5 63 * 1,880
48 48 47 0.5 72 * 2,502




Product range :

Size : 1/8"NB TO 48"NB IN

Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS

Type : Seamless / ERW / Welded / Fabricated /Forged

Form : Eccentric Reducer, Concentric Reducer

Materials
Stainless Steel Reducer - SS Reducer
ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L

Carbon Steel Reducer - CS Reducer
ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.

Low Temperature Carbon Steel Reducer - LTCS Reducer
ASTM A420 WPL3 / A420WPL6

Alloy Steel Reducer - AS Reducer
ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91

Duplex Steel Reducer
ASTM A 815 UNS NO S 31803 , S 32205.

Nickel Alloy Reducer
Standard

  • ASTM / ASME SB 336.
  • UNS 10276 (HASTELLOY C 276 Reducer)
  • UNS 2200 (NICKEL 200 Reducer),
  • UNS 2201 (NICKEL 201 Reducer),
  • UNS 4400 (MONEL 400 Reducer),
  • UNS 8020 (ALLOY 20 Reducer),
  • UNS 8825 (INCONEL 825 Reducer),
  • UNS 6600 (INCONEL 600 Reducer),
  • UNS 6601 (INCONEL 601 Reducer),
  • UNS 6625 (INCONEL 625 Reducer),

Value Added Services

  • Hot Dip Galvanizing
  • Epoxy Coating

Carbon Steel Butt Weld Fitting ASTM A234 WP11 WP22  WP5  P9  P91  P92  ELBOW  TEE  REDUCER  CAP FOR OIL AND GAS 1
