Bridas de acero inoxidable &acero duplex &acero aleadoTH RF 1'' 150LB 317L High Precision ASME B16.5 A182 Standard

Bridas de acero inoxidable &acero duplex &acero aleadoTH RF 1'' 150LB 317L High Precision ASME B16.5 A182 Standard

  • Bridas de acero inoxidable &acero duplex &acero aleadoTH RF 1'' 150LB 317L  High Precision ASME B16.5  A182 Standard
  • Bridas de acero inoxidable &acero duplex &acero aleadoTH RF 1'' 150LB 317L  High Precision ASME B16.5  A182 Standard
  • Bridas de acero inoxidable &acero duplex &acero aleadoTH RF 1'' 150LB 317L  High Precision ASME B16.5  A182 Standard
  • Bridas de acero inoxidable &acero duplex &acero aleadoTH RF 1'' 150LB 317L  High Precision ASME B16.5  A182 Standard
Bridas de acero inoxidable &acero duplex &acero aleadoTH RF 1'' 150LB 317L  High Precision ASME B16.5  A182 Standard
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: F304/F304L, /F316/F316L, F51, F53, F55
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: NEGOTIABLE
Packaging Details: PLY-WOODEN CASE OR PALLET
Delivery Time: 10-15 DAYS
Payment Terms: L/C, T/T
Supply Ability: ACCORDING TO CUSTOMER'S REQUEST
Contact Now
Detailed Product Description
Standard: ASTM A182 Material Grade: F304/F304L, /F316/F316L, F51, F53, F55
Certificate: API,PED,ABS Third Party Inspection: BV,SGS,ASP
Type: SORF,SOFF,WNRF,WNFF,BLIND
High Light:

stainless steel flanges

,

carbon steel flanges

Bridas de acero inoxidable &acero duplex &acero aleadoTH RF 1'' 150LB 317L High Precision ASME B16.5 A182 Standard



NOS ENCANTARíA APOYARLES EN LENGUA ESPAÑOLA Y INGLESA SI TIENEN CUALQUIER REQUERIMIENTO RELATIVO!



YUHONG SPECIAL STEEL deal with Austenitic Stainless Steel, Nickel Alloy Steel(Hastelloy , Monel, Inconel, Incoloy ) flanges  already more than 25 years,every year sell more than 20000 tons of steel flanges with material Stainless steel &Duplex steel &alloy steel. Our client already cover more than 45 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Russia, Korea, Singapore, Austrial, Poland, France , ....And our group branch company and factory have been already approved by :ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2008, ISO 14001-2004.




YUHONG Stainless distributes Stainless Steel Flanges including: Slip-Ons, Socket Weld, Blinds, Lap Joints, Threaded and Weld Necks.
Slip-on Flanges

Slip-on Flanges have a lower initial cost than welding neck flanges because they require less accuracy in cutting pipe to length, and they provide a greater ease of alignment in assembly. However, their calculated strength under internal pressure is approximately 2/3's the strength of welding neck flanges, and their life under fatigue is 1/3 shorter. Slip-on Flanges are limited to 1/2" to 2½" sizes in 1500lbs standard.

Threaded Flanges
Threaded Flanges are used for special applications. They can be assembled without welding and can be used in extremely high pressure services--at or near atmospheric pressure--where alloy steel is essential for strength. Threaded flanges are not suited for conditions involving temperature or bending stresses, or under cyclic conditions where leakage through the threads may occur.

Weld Neck Flanges
Weld Neck Flanges have a long tapered hub and gradual transition of thickness in the region of the butt weld joining them to the pipe. The tapered hub provides important reinforcement to the flange and resistance to dishing. This type of flange is preferred for severe service conditions resulting from high pressure, sub-zero or high temperatures.

Blind Flanges
Blind Flanges are used to blank off the ends of piping, valves and pressure vessel openings. Blind Flanges can handle high stress from internal pressure and bolt loading since the maximum stresses in the blind flange are bending stresses at the center.

Socket Weld Flanges
Socket Weld Flanges were developed for use on small size high pressure piping. With an internal weld, socket weld flanges are stronger and have greater fatigue strength than double welding a slip-on flange. Smooth bore conditions can be easily attained by grinding the internal weld. This flange is commonly used in chemical process piping.

Lap Joint Flanges
Lap Joint Flanges are used with lap joint stubs. Lap joint flanges are commonly used in carbon or low alloy steel piping systems that need to be frequently dismantled for inspection and cleaning. They should not be used at any points where severe bending stresses occur.



Grade   C Mn Si P S Cr Mo Ni N
316L Min - - - - - 16.0 2.00 10.0 -
Max 0.03 2.0 0.75 0.045 0.03 18.0 3.00 14.0 0.10
304 Min - - - - - 18.0 - 8.0 -
Max 0.08 2.0 0.75 0.045 0.030 20.0 - 10.5 0.10
304L Min - - - - - 18.0 - 8.0 -
Max 0.030 2.0 0.75 0.045 0.030 20.0 - 12.0 0.10


Bridas de acero inoxidable &acero duplex &acero aleadoTH RF 1'' 150LB 317L  High Precision ASME B16.5  A182 Standard 0
