Yuhong Holding Group Co.,LTD
Place of Origin: | CHINA |
Brand Name: | YUHONG |
Model Number: | TP304/304L , TP316L , TP310S, TP316Ti, TP321/321H , TP347 , TP317 |
Minimum Order Quantity: | 1 PC |
---|---|
Price: | NEGOTIABLE |
Packaging Details: | Ply-wooden Case |
Delivery Time: | 10-15 DAYS |
Payment Terms: | L/C, T/T |
Supply Ability: | ACCORDING TO CUSTOMER'S REQUEST |
Certification: | API, PED | Standard: | ANSI:ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48,DIN:DIN2527, DIN2566, DIN2573, DIN2 |
---|---|---|---|
Material: | F316/316L , 1.4438 , S31700 | Flange Type: | WELD NECK FLANGE , LAP JOINT FLANGE, BLIND FLANGE, SLIP ON FLANGE, THREAD FLANGE, SOCKET WELD FLANGE ORIGICE FLANGE , SPECTTACLE FLANGE, OVERLAY CLADDING |
Package: | Ply-wooden Case | ||
High Light: | stainless steel flanges,carbon steel flanges |
Brida de acero inoxidable,Norma ASME A182 ,Material F316 /F316L ,Size 1/2'',1'',1 1/2'',2'',RF ,FF,B16.5
Slip-on Flanges
Slip-on flanges are a popular type of pipe flanges. These are type of flanges that slide over the end of piping and then welded in place. These flanges are ideal for lower pressure applications. These are easily fitted and welded into different pipes. Welding reduces fabrication costs of these pipes. These are available in wide variety of sizes and applications.
|
![]() |
How to measure slip-on flanges?
Take the measurements of:
Key Features of Slip-On Flanges :
Some important features are as follows:
One size fits all pipe schedules.
Fabricators can more easily cut pipe to length for slip-on flanges.
The smaller thickness of this flange allows for easier alignment of bolting holes.
They are generally not preferred for high pressure temperature environments.
Advantages of slip on flanges:
Low cost installation
Less time needed to spent on ensuring the accuracy of the cut pipe
they are somewhat easier to align
the slip-on flanges have low hub because the pipe slips into the flange before welding
the flange is welded both inside and outside to provide sufficient strength
they prevent leakage
Product Range-
Size : 1/8" NB TO 48"NB.
Class : 150#, 300#,400 #,600#,900#, 1500# & 2500 #.
Stainless Steel Slip on Flanges: ASTM A 182, A 240
Grade : F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L, Duplex stainless steel UNS S31803, 2205, Super Duplex stainless steel UNS S32750
Carbon Steel Slip on Flanges : ASTM A 105, ASTM A 181
Alloy Steel Slip on Flanges: ASTM A 182, GR F1, F11, F22, F5, F9, F91
