Durable Metal Flange ASME ASTM BS DIN 14" 170 - 150PSI Vanish Coating Surface

Durable Metal Flange ASME ASTM BS DIN 14" 170 - 150PSI Vanish Coating Surface

  • Durable Metal Flange ASME ASTM BS DIN 14" 170 - 150PSI Vanish Coating Surface
  • Durable Metal Flange ASME ASTM BS DIN 14" 170 - 150PSI Vanish Coating Surface
  • Durable Metal Flange ASME ASTM BS DIN 14" 170 - 150PSI Vanish Coating Surface
  • Durable Metal Flange ASME ASTM BS DIN 14" 170 - 150PSI Vanish Coating Surface
Durable Metal Flange ASME ASTM BS DIN 14" 170 - 150PSI Vanish Coating Surface
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: API, PED,
Model Number: ASTM A182,ANSI/AWWA C207 ,C228
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD
Packaging Details: PLY-WOODEN CASE
Delivery Time: 7 DAYS
Payment Terms: L/C, T/T
Supply Ability: 1000 TONS PER MONTH
Contact Now
Detailed Product Description
MATERIAL: STAINLESS F304, 304L, 304H, 316, 316L, Duplex F51,F53,F55 Flange TYPE: Weld Neck, Slip-On, Blind, Plate, Loose, Orifice
Face Type: RF(raised Face);FF(flat Face);RTJ(ring Type Joint); RJ(ring Joint Face) TG(tongue And Groove Face);MF M (male And Female Face) CLASS: 86PSI, 175-150 PSI
Name: Steel Flanges Certification: ASME ASTM BS DIN
High Light:

forged steel flanges

,

carbon steel flanges

SOFF ANSI / AWWA C207 / C228 CLASS D Flange ASME ASTM BS DIN 14" 170-150PSI





ASTM, BS, and DIN are standards organizations that provide specifications for various products, including flanges. The term "14" 170-150PSI flange" refers to a specific type of flange that meets the requirements of these standards.

ASTM refers to the American Society for Testing and Materials, which sets standards for various materials, including flanges. BS refers to the British Standards, which provides specifications for various products, including flanges. DIN refers to Deutsches Institut für Normung, the German Institute for Standardization, which sets standards for various products, including flanges.

The "14" in the term refers to the nominal pipe size (NPS) of the flange, which indicates the approximate inside diameter of the flange. In this case, it refers to a flange designed to fit a pipe with a 14-inch diameter.

The numbers 170-150 PSI refer to the pressure rating of the flange. It indicates the maximum pressure the flange can withstand without leaking or failing. In this case, the flange is rated for a pressure range of 170 to 150 pounds per square inch (PSI).

Overall, the term "ASTM BS DIN 14" 170-150PSI flange" specifies a flange that meets the standards set by ASTM, BS, and DIN, with a nominal pipe size of 14 inches and a pressure rating of 170-150 PSI.













Type WN, SO, PL, BL, SW, THRD, LJ, Spectacle Blind
Standard ASME,MSS, JIS, EN,GB, DIN,GOST,BS,others
Size 1/2” - 80”
Pressure 150#-2500#, PN6-PN40, 5K-16K





Steel Grade

A105
A350 LF2, LF3
A182 F5, F9, F91, F11, F12, F22
A182 F304, F304L, F316, F316L, F321
A694F42, F46, F56, F60, F65, F70,F80,F100 ,API 5L
Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555
Surface Vanish Coating, Black Oil coating as per customer’s requirement



Test

Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Blow Test, Impact Test), Exterior Size Inspection
Mill Test Certificate
EN 10204/3.1B











SOFF ANSI / AWWA C207 / C228 CLASS D Steel Flanges ASME ASTM BS DIN 14" 170 - 150PSI











Durable Metal Flange ASME ASTM BS DIN 14" 170 - 150PSI Vanish Coating Surface 1











Durable Metal Flange ASME ASTM BS DIN 14" 170 - 150PSI Vanish Coating Surface 2
