ASTM B111 C44300 Seamless Copper Nickel Tube

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM B111 C44300

Payment & Shipping Terms:

Minimum Order Quantity:	1PC

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Minimum Order Quantity:	1 PC	Packaging Details:	Ply-wooden Case /Iron Case/ Bundle With Plastic Cap
Delivery Time:	15DAYS	Payment Terms:	T/T, L/C
Supply Ability:	1500 Tons Per Month	Price:	Negotiable
NDT:	Eddy Current Test , Hydrostatic Test , Ultrasonic Test
Highlight:	ASTM B111 Seamless Boiler Tubes , C44300 Boiler Tube , ASTM B111 Boiler Tube

ASTM B111 Cold Finished C44300 Seamless Boiler Tubes

Standard:	ASTM B111/ ASME SB111	Material:	C44300
Testing:	ET, HT, Flattening Test; Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination; Tension Testing.	Application:	Boiler Pipe, Hydraulic/Automobile Pipe,
Surface:	Polished	Shape:	Round Pipe
High Light:	C44300 Seamless Boiler Tubes , Cold Finished Seamless Boiler Tubes , ASME SB111 Seamless Boiler Tubes

ASME SB111 C44300-O61 Seamless Copper Nickel Brass Tube Cold Finished

We are one of the biggest manufactures of stainless steel & duplex steel & alloy steel tubes and pipes in China. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.

ASTM B111 ASME SB 111 C44300 Admiralty Brass is ideal for heat exchanger tubes. Normally made to order to meet engineering requirements, you will find this alloy often times used in oil and gas applications that also require its non corrosive properties. C44300 and C68700 have good corrosion resistance. C44300 Admiralty Brass Seamless Tubes Tensile strength minimum in 310Mpa, Yield Strength minimum in 105Mpa.

COUNTRY	STANDARD	NAME
ASTM	ASTM B111	Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock
GB/T	GB/T8890	Seamless Copper Alloy Heat Exchanger Tubes
BS	BS2871	Copper and Copper Alloys Tubes
JIS	JIS H3300	Copper and Copper Alloy-Seamless Pipes and Tubes
DIN	DIN1785	Wrought Copper and Copper Alloy Tubes for Condensers and Heat Exchangers

ASTM B111 / ASME SB 111 C44300 Admiralty Brass Chemical Composition

Elements	Composition, %
Cu, incl. Ag	70.0-73.0
Sn	0.9-1.2
Al	–
Ni, incl. Co
Pb	0.06 max
Fe	0.07 max
Zn	Balance
Mn	–
As	0.02-0.06
Sb	–
P	–
Cr	–
Other named elements	–

ASTM B111 / ASME SB 111 C44300 Admiralty Brass Mechanical Properties

Properties	Measurement
Yield strength	105 MPa
Melting point	899 ~ 938 °C
Tensile strength	310 MPa
Thermal conductivity	109 W/m-K @ 20.0 °C
Density	8.53 g/cc
Heat capacity	0.09 cal/g-°C @ 20ºC
CTE linear strength	20.2 10-6/°C @ 20.0 – 300 °C

ASTM B111 / ASME SB 111 C44300 Admiralty Brass Physical Properties

Copper or Copper Alloy UNS No.	Melting Point		Density		Coefficients of Linear Thermal Expansion		Specific Heat Capacity		Thermal Conductivity
	°C	°F	lb/in3	g/cm3	1×10-6/°C @ 20.0 – 30.0 °C	1×10-6/°F @ 70.0 – 570 °F	cal/g-°C, 20 °C	BTU/lb-°F @ 70°F	W/m-K, 20 °C	BTU/ft2/ft/h/°F @ 70°F

C44300	2140 – 2260	2010-2100	0.308	8.53	16.2	9	0.09	0.09	29	17

Application:

Evaporator Tubing
Heat Exchanger Tubing
Condenser Tube Plates
Distiller Tubes
Oil Well Pump Liner
Ferrules
Bourdon Tubes
Condenser Tubes

SB111 C44300 material has the following benefits:

Durability – The structure and chemical composition of an SB111 C44300 makes it durable. Its products can last up to 10 years, depending on where you are using it and the frequency of use.
Cost-effective – The overall value of installing, functioning and maintaining products of this material is relatively low. You, therefore, get quality by selecting this material to manufacture your products.
Versatile usage – You can manufacture different products using this material. For instance, you can make pipes and tubes for a variety of usage.

Test:
