ASTM B111/ ASME SB111 C70600 Copper Nickel Tubes (Application for Heat Exchanger)

ASTM B111/ ASME SB111 C70600 Copper Nickel Tubes (Application for Heat Exchanger)

ASTM B111/ ASME SB111 C70600 Copper Nickel Tubes (Application for Heat Exchanger)
video
ASTM B111/ ASME SB111 C70600 Copper Nickel Tubes (Application for Heat Exchanger)
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM B111/ASME SB111 C70600
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle With Plastic Cap
Delivery Time: 15DAYS
Payment Terms: T/T, L/C
Supply Ability: 200 TONS PER MONTH
Contact Now
Detailed Product Description
Standard: ASTM B111/ASME SB111 Material: Copper Nickel Alloy C70600
Length: 3000mm-6000mm, 6 Meters Or Customized, 18000max., 11.8m Or As Required., 8m Thickness: 0.4-30mm, 1.0mm, 0.6mm-2500mm, 1mm-60mm, 0.6-25 Mm
Outer Diameter: 6-630mm, Customized, 6-762mm, 6-860mm;, 6mm-630mm Surface: Annealing, 8K, Polishing Or Unpolishing, Morror/Satin
Finish: Brush Polish, Cold Drawn, Pickled, Bright Annealed Or Un Annealed, Bright
High Light:

C70600 Copper Nickel Heat Exchange Tube

,

ASTM B111 Heat Exchange Tube

,

ASME SB111 Copper Nickel Tube

ASTM B111 C70600 Seamless Nickel Copper Alloy Tube For Heat Exchanger and Condenser

We are one of the largest stainless steel, duplex and alloy steel pipe manufacturers in China. After more than 30 years of development, we have accumulated a large number of customers all over the world, and Yuhong products have also won unanimous praise from customers.



ASME SB 111 SB 111 C70600 pipe, resistant to seawater corrosion, with high antifouling properties to marine microorganisms. Widely used in shipbuilding, petrochemical, natural gas and other offshore and related industries. C70600 Copper Nickel Pipe / Copper Nickel 90/10 Seamless Pipe has good corrosion resistance, especially in sea water.



UNS C70600 copper-nickel alloy is annealed at 593 to 816°C (1100 to 1500°F). UNS C70600 copper-nickel alloy has good cold workability. Suitable for high temperature service.

. UNS C70600 copper-nickel alloy is used in areas where stainless steel cannot be used due to chloride stress corrosion cracking (CSCC) and other parts where high corrosion resistance is required. These alloys are also used as machined and forged valve and pump components for seawater service. C70600 (90/10) copper-nickel alloy is highly resistant to seawater corrosion due to its high content of manganese and iron. Suitable for marine condensers, copper-nickel alloy Copper 90/10 and copper-nickel alloy Copper 70/30 are used in seawater condensation systems, heating and water supply, chemical industry, seawater desalination, etc.

.Copper alloys UNS C70600 and C71500 are standard specification seamless copper-nickel alloy pipes for desalination plants.

However, the C70600 and C71500 alloys are easily welded by the most common methods. Both alloys should be welded using consumables from Alloy C71500. When welding copper-nickel to steel, 65% nickel-copper consumables should be used because they can withstand more iron dilution from steel than C71500 copper-nickel consumables.



ASTM B111 B466 C70600 Copper Nickel Tubing Chemical Composition
Grade C(Max) Pb Mn P S Zn Fe Ni Cu
C70600 0.05 0.02 1.0 0.02 0.02 0.50 1.0-1.8 9.0-11.0 Balance



ASME SB 111 SB 466 C70600 Pipe | EEMUA 234 UNS 7060X Physical Properties
Properties Metric Imperial
Density 8.94 g/cm3 0.323 lb/in3



ASME SB 111 SB 466 ASTM B111 C70600 Pipe

Outside Diameter Wall Thickness
DN OD Actual Standard Special
in mm mm WT kg/m WT kg/m
  4 8 1 0.2
1/8 6 10 1 0.25
1/4 8 12 1 0.31
3/8 12 16 1 0.42 1.5 0.61
1/2 16 20 1 0.53 1.5 0.78
3/4 20 25 1.5 0.99 2 1.29
1 25 30 1.5 1.19 2 1.56
1 1/4 32 38 1.5 1.53 2 2.01
1 1/2 40 44.5 1.5 1.8 2 2.38
2 50 57 1.5 2.33 2 3.07
2 1/2 65 76 2 4.14 2.5 5.14
3 80 88.9 (89) 2 4.86 2.5 6.04
4 100 108 2.5 7.37 3 8.8
5 125 133 2.5 9.12 3 10.9
6 150 159 2.5 10.93 3 13.08
7 175 194 3 16.01
8 200 219.1 (219) 3 18.12 3.5 21.09
10 250 267 3 22.13 4 29.4
12 300 323.9 (324) 4 35.76 5 44.56
14 350 368 4 40.69 5.5 55.72
16 400 419 4 46.39 6 69.25
18 450 457 4.5 56.92







UNS C70600 copper-nickel alloy is primarily used in seawater service as forged and machined valve and pump assemblies, fittings and hardware. The alloy is also used in applications where high corrosion resistance and chloride stress corrosion cracking prevention measures prevent the use of stainless steel.

Copper-nickel alloys have excellent resistance to biofouling and marine corrosion, and have good machinability. When nickel is added, copper is stronger and more resistant to corrosion.

UNS C70600 is a copper-nickel alloy with excellent corrosion resistance even in marine environments. The alloy has average high strength and good creep resistance at elevated temperatures, at a higher cost than copper-aluminum alloys and other alloys with similar mechanical properties



Mechanical Testing Such as Tensile of Area

  • Hardness Test
  • Chemical Analysis – Spectro Analysis
  • Positive Material Identification – PMI Testing
  • Flattening Test
  • Micro and MacroTest
  • Pitting Resistance Test
  • Flaring Test
  • Intergranular Corrosion (IGC) Test
