er304 er304H er304L stainless steel inox welding wire AWS

Product Details:

Place of Origin:	China
Brand Name:	Atlas
Certification:	ISO9001:2015
Model Number:	0.8-15mm

Payment & Shipping Terms:

Minimum Order Quantity:	500KG
Price:	USD 2.0-3.5/KG
Packaging Details:	coil or spool with plate.
Delivery Time:	1-15 days
Payment Terms:	D/P, Western Union, L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (242)

Stainless Steel Seamless Tube (237)

Finned Tube (453)

Heat Exchanger Tube (162)

Heat Exchanger Parts (169)

Stainless Steel Welded Pipe (50)

Stainless Steel Welded Tube (98)

Duplex Stainless Steel Pipe (135)

Alloy Steel Tube (129)

Bright Annealed Tube (152)

Copper Alloy Tube (169)

Nickel Alloy Pipe (309)

Needle Tube (26)

U Bend Tube (189)

Boiler Tube (110)

Steel Fitting (664)

Steel Flange (477)

Steel Valves (12)

Precision Steel Strip (29)

Alloy Wires (271)

Others (61)

Detailed Product Description

Supply Ability:	>500 Tons Per Month	Material:	SPECIAL MATERIAL
Diameter:	0.8-15mm	Packing:	By Customer Request
Standard:	JIS G. EN. ASTM. DIN. GB Etc	Surface:	Matt Or Bright
High Light:	ss spring wire , wire for making springs

er304 er304H er304L stainless steel inox welding wire AWS

Stainless steel Spring wire
Standards:ASTM / ASME,GB,DIN, JIS,
Steel Grade:special material for iggiration system
Out Diameter:0.8mm to 10mm or customized

Supply ability:1000 tons per month
Packing:Standard export packing
Payment terms:T/T or L/C
Delivery terms:FOB CFR CIF EX Works DDU
Certificate:ISO,SGB,BV,IQI,TUV,ETC

Name	Stainless steel spring wire
Key Word
Grade	201,202,303, 303Cu,304,304L,316,316L,310S,316Ti,321,430,904L,ETC
Standard	ASTM,SUS,JIS,EN,DIN,GB,ASME,ETC
Diameter	0.8mm to 10mm or as your requirement

Tolerance	Outer Diameter:+/-0.2mm,Thickness:+/-0.02nn,Length:+/-5mm
Surface	soap coated
Application	iggiration system
Certification	SGS,BV,IQI,TUV,ISO,ETC

Mechanical properties

DIAMETER(MM)	TENSILE STRENGTH(MPA)			ELONGATION(%)
DIAMETER(MM)	SOFT-ANNEALED	SEMI-HARD	HARD	FOR SOFT-ANNEALED WIRE ONLY
0.20~0.30	640~980	_	_	≥20
0.30~0.60	590~930	_	_	≥20
0.60~1.00	540~880	830~1180	1180~1520	≥25
1.00~3.00	490~830	780~1130	1130~1470	≥25
3.00~6.00	490~830	730~1080	1080~1420	≥30
6.00~14.00	490~790	730~1030	_	≥30

Physical Properties

Diameter Tolerance & Oval Tolerance

Mechanical Properties

(mm)Dia.	(mm)Dia.Tolerance	Oval.Tolerance
0.030-0.050	±0.003	≤0.003
0.050-0.080	±0.004	≤0.004
0.080-0.10	±0.005	≤0.005
0.10-0.16	±0.007	≤0.007
0.16-0.28	±0.010	≤0.010
0.28-0.50	±0.013	≤0.013
0.50-0.90	±0.015	≤0.015
0.90-1.60	±0.02	≤0.02
1.60-2.80	±0.03	≤0.03
2.80-5.00	±0.04	≤0.04
5.00-9.00	±0.05	≤0.05
9.00-12.00	±0.06	≤0.06
12.00-14.00	±0.07	≤0.07

Type	(mm)Dia	(N/mm2)Tensilestrength	(%)Elongation
SUS304.SUS304L	0.02-0.05	880-1130	≥10
SUS316.SUS316L	0.02-0.05	650-900	≥8
SUS304.SUS304L SUS309S SUS310S SUS316.SUS316L SUS321	0.05-0.16	650-900	≥20
	0.16-0.50	610-860	≥20
	0.50-1.60	570-820	≥30
	1.60-5.00	520-770
	5.00-14.00	500-750
SUS304J3	0.05-0.16	620-870	≥20
	0.16-0.50	580-830	≥20
	0.50-1.60	540-790	≥30
	1.60-5.00	500-750
	5.00-14.00	490-740

Chemical Composition

AISI Grade	Chemical Composition(%)
	C	Si	Mn	P	S	Ni	Cr	Mo
304	=<0.08	=<1.00	=<2.00	=<0.045	=<0.030	8.00~10.50	18.00~20.00	-
304H	>0.08	=<1.00	=<2.00	=<0.045	=<0.030	8.00~10.50	18.00~20.00	-
304L	=<0.030	=<1.00	=<2.00	=<0.045	=<0.030	9.00~13.50	18.00~20.00	-
316	=<0.045	=<1.00	=<2.00	=<0.045	=<0.030	10.00~14.00	10.00~18.00	2.00~3.00
316L	=<0.030	=<1.00	=<2.00	=<0.045	=<0.030	12.00~15.00	16.00~18.00	2.00~3.00
430	=<0.12	=<0.75	=<1.00	=<0.040	=<0.030	=<0.60	16.00~18.00	-
430A	=<0.06	=<0.50	=<0.50	=<0.030	=<0.50	=<0.25	14.00~17.00	-
