| Place of Origin: | China |
| Brand Name: | Atlas |
| Certification: | ISO9001:2015 |
| Model Number: | 0.3-18mm |
| Minimum Order Quantity: | 500KG |
|---|---|
| Packaging Details: | coil, spool with plate. |
| Delivery Time: | 1-15 days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 500tons per month |
| Material: | 302 | Surface: | Bright |
|---|---|---|---|
| Coil Inner Diameter: | 250-1000mm | Standard: | JIS G. EN. ASTM. DIN. GB Etc |
| Packing: | Coil Or Special Packing With Plate | Status: | Soft , Semi-soft |
| High Light: | ss spring wire,wire for making springs |
||
302 stainless steel spring wire based on ASTM A580 spring wire
ToponeWire has a long history of producing only the highest quality stainless steel wire for the spring industry. Our customers have come to rely on the engineering and metallurgical services provided by Sumiden Wire. When you need a reliable, domestic producer who can provide unsurpassed quality, service, and delivery, give us a call.
Toponewire has stocks of most types of spring wire, which is the raw material in the production of springs and spring solutions.
This includes black wire, oil-hardened and stainless steel wire, covered bronze wire and beryllium-copper wire.
Our suppliers of raw materials are recognized steel and wire producers. In this way we ensure the production of your requirement for specialized solutions and uniform springs regardless of the quantity and
size of the springs.
| Steel Grade | C | Si | Mn | P | S | Cr | Ni | N |
| 302 | 0.15max. | 1.00max. | 2.00max. | 0.045 max | 0.030 max | 17.0-19.00 | 8.0-10.0 | 0.10max. |
| Steel Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation (%) | Area Reduction Ratio C (%) |
| 302 | 620 min | 310 min | 30 min | 40 min |
| Steel Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation (%) | Area Reduction Ratio C (%) |
| 302 | 520 min | 210 min | 35 min | 50 min |
Spring wire is a complex raw material. The wire ensures the spring's ability to change form when it is coiled or processed in some other way. At the same time the wire needs to have a strength and hardness that ensures its stability when after compression or expansion the spring returns to its original form.
Most springs are produced from spring wire - also known as carbon wire - where the carbon content is between 0.5 and 1.2 percent depending on the requirement for the tensile strength.
Spring wires with a higher tensile strength are used when there are increased requirements for the wear resistance of the spring.
The tensile strength is derived from the spring wire going through a special hardening and subsequent pulling process.
Toponewire has many years of experience with specialized springs so we know which raw materials best suit your needs.
This may be oil-hardened wire or springs in a stainless material, which puts different demands on raw materials and manufacture.
For example, if the spring needs to be seawater-resistant or non-magnetic, Toponewire uses hard-drawn bronze wire.
