Yuhong Holding Group Co.,LTD
Place of Origin: | China |
Brand Name: | atlas |
Certification: | ISO9001:2015 |
Model Number: | 0.2-15mm |
Minimum Order Quantity: | 500KG |
---|---|
Packaging Details: | coil or spool with plate. |
Delivery Time: | 1-15 days |
Payment Terms: | D/P, Western Union, L/C, T/T |
Supply Ability: | >500 Tons Per Month | Material: | 304 304L 316 316L |
---|---|---|---|
Diameter: | 0.2-15mm | Packing: | By Customer Request |
Standard: | JIS G. EN. ASTM. DIN. GB Etc | Surface: | Matt Or Bright |
High Light: | annealed stainless steel wire,ss annealed wire |
304 304L 316 316L stainless steel wire for weaving mesh / woven wire / wire mesh
Product Name | Soft Annealed Stainless Steel Wire |
Surface | Bright Matt |
Standard | AISI DIN GB ISO JIS |
Treatment | cold-drawn, soft annealed |
Diameter | 0.8-15mm |
Features:
Acid resistant,alkali resistant and corrosion resistant
Custom tensile strength,wear resistant and durable
High temperature oxidation resistant,304 stainless steel mesh screen nominal tolerable temperature is 800 degree celsius,310s stainless steel mesh screen nominal tolerable temperature is up to 1150 degree celsius.
High surface finish,no surface treatment,easy and simple maintenance
Application:
For screening and filtration in acid and alkali environment.Also applied in the mining, chemical, food, pharmaceutical and other industries.
Mechanical properties
| TENSILE STRENGTH(MPA) | ELONGATION(%) | ||
| | | FOR SOFT-ANNEALED WIRE ONLY | |
0.20~0.30 | 640~980 | _ | _ | ≥20 |
0.30~0.60 | 590~930 | _ | _ | ≥20 |
0.60~1.00 | 540~880 | 830~1180 | 1180~1520 | ≥25 |
1.00~3.00 | 490~830 | 780~1130 | 1130~1470 | ≥25 |
3.00~6.00 | 490~830 | 730~1080 | 1080~1420 | ≥30 |
6.00~14.00 | 490~790 | 730~1030 | _ | ≥30 |
Physical Properties
Diameter Tolerance & Oval Tolerance | Mechanical Properties | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
Chemical Composition
AISI Grade | Chemical Composition(%) | |||||||
C | Si | Mn | P | S | Ni | Cr | Mo | |
304 | =<0.08 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 8.00~10.50 | 18.00~20.00 | - |
304H | >0.08 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 8.00~10.50 | 18.00~20.00 | - |
304L | =<0.030 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 9.00~13.50 | 18.00~20.00 | - |
316 | =<0.045 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 10.00~14.00 | 10.00~18.00 | 2.00~3.00 |
316L | =<0.030 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 12.00~15.00 | 16.00~18.00 | 2.00~3.00 |
430 | =<0.12 | =<0.75 | =<1.00 | =<0.040 | =<0.030 | =<0.60 | 16.00~18.00 | - |
430A | =<0.06 | =<0.50 | =<0.50 | =<0.030 | =<0.50 | =<0.25 | 14.00~17.00 | - |
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: We holding more than 1000tons in stock, generally it is 2-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=10000USD, 100% in advance. Payment>=10000USD, 30% T/T in advance ,balance before shippment.
If you have any further question, feel free to comments.
