Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | ATLAS |
| Certification: | ISO9001:2015 |
| Model Number: | 201 304 316 316L |
| Minimum Order Quantity: | 500KG |
|---|---|
| Packaging Details: | coil or spool with plate. |
| Delivery Time: | 1-15 days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | >500 Tons Per Month | Material: | 201 304 316 316L |
|---|---|---|---|
| Surface: | Soap Coated/Bright | Coil Inner Diameter: | 250-1000mm |
| Standard: | JIS G. EN ASTM. DIN. GB Etc | Packing: | Coil Or Spool |
| High Light: | ss flat wire,flat spring steel wire |
||
annealed stainless steel flat wire 201 304 316
SUS 201 304 316 Flat Wire
1) Material: 201 304 316 316L Stainless Steel Flat Wire
2) Standard: ASTM, DIN, GB, JIS, SUS
3) Diameter: 0.25mm-18.0mm*custom size
4) Surface finish: Electrolysis bright, bright, Polish, matt.
5) Certification: ISO9001: 2008
6) Packing: Woven bag, coil, others are also available according to client' requirement
7) Application: Tie wire, pins, lashing, forming wire, filters, gaskets, elevators, safety wire, shaped and flat wire, conveyors, jewelry, springs, brush welding, electrical, wire line, craft and many more applications.
Terms
1) Trade Terms: FOB/CIF/CFR
2) Shipping Port: Shanghai Port
3) Payment: T/T or L/C at sight
4) Delivery: Within 30 days upon receipt of the 30% deposit
5)HS Code: 7223000000
Common types:
2.5 x 0.50mm
2.5 x 0.60mm
2.5 x 0.70mm
304 (2.15*0.75mm)
316 (2.0*0.8mm)
316L (1.95*0.75mm)
201 (1.35*0.65mm)
430 (1.15*0.55mm)
Application: mainly used to bind the carbon, box;making clean ball,pruduce conveyor belt,etc.
Feature:The product with good surface smoothness and stong corrosion resistancefeatures,the surface looks bright and beautiful.
| DIAMETER(MM) | TENSILE STRENGTH(MPA) | ELONGATION(%) | ||
|
SOFT-ANNEALED |
SEMI-HARD |
HARD |
FOR SOFT-ANNEALED WIRE ONLY | |
| 0.20~0.30 | 640~980 | _ | _ | ≥20 |
| 0.30~0.60 | 590~930 | _ | _ | ≥20 |
| 0.60~1.00 | 540~880 | 830~1180 | 1180~1520 | ≥25 |
| 1.00~3.00 | 490~830 | 780~1130 | 1130~1470 | ≥25 |
| 3.00~6.00 | 490~830 | 730~1080 | 1080~1420 | ≥30 |
| 6.00~14.00 | 490~790 | 730~1030 | _ | ≥30 |
Chemcial composition:
| Grade | C | Mn | P | S | Si | Cr | Mo | Cu | Ni | N |
| 1.4410 | 0.03max | 2.0 max |
0.035 max |
0.015max |
1.0 max |
24.0- 26.0 |
3.0- 4.5 |
- |
6.0- 8.0 |
0.20- 0.35 |
304 Stainless steel flat wire feature
1) Excellent linearity and helix for automatic coiling
2) Uniform and perfect surface
3) Excellent coil-forming ability
4) High elasticity and high fatigue-resistance
5) Strong heat-resistance against exposure to the toughest environment
304 stainless steel flat wire application
With bright surface, slight magnetism and no cracks on forming,is widely used in bicycle fittings,
kitchen and sanitation tools, goods shelf, pet cages, gill racks, decorative handles and baskets,
food and medical machinery accessies etc.
Quality Assurance:
1. Every material will be inspected at least three times, which are raw material, wire rod and final wire.
2. Every material will be inspected by both machine and manual work.
3. Each coil of wire will be inspected of the surface defects before packing.
4. If the material is not in conformity to the order, we will refund 100% payment.
