Yuhong Holding Group Co.,LTD
Place of Origin: | China |
Brand Name: | YUHONG |
Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
Model Number: | MONEL400/NO4400 |
Minimum Order Quantity: | 100KGS |
---|---|
Price: | Negotiable |
Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
Delivery Time: | 15-30 days |
Payment Terms: | T/T, L/C AT SIGHT |
Supply Ability: | 100 tons per month |
Alloy Or Not: | Alloy | Technique: | ERW |
---|---|---|---|
Thickness: | As Required | Section Shape: | Round |
Outer Diameter(round): | 1'' - 48'' | Standard: | ASTM,ASME |
High Light: | astm b165 smls steel pipe,uns no4400 smls steel pipe,smls monel 400 pipe |
Monel 400 is a Nickel-Copper alloy, resistant to sea water and steam at high temperatures as well as to salt and caustic solutions.Monel 400 is a nickel-copper alloy with excellent corrosion resistance in a wide variety of media. Monel 400 is characterized by good general corrosion resistance, good weldability and moderate to high strength. The alloy has been used in a variety of applications. It has excellent resistance to rapidly flowing brackish water or seawater. It is particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated. The alloy is slightly magnetic at room temperature. Monel 400 is widely used in the chemical, oil and marine industries.
Characteristics
Chemical Composition
Ni | C | Mn | S | Si | Cu | Fe | |
Max | 0.3 | 2.00 | 0.024 | 0.5 | 34.0 | 2.50 | |
Min | 63.0 | 28.0 |
Mechanical Properties
Condition & Size |
Tensile Strength, min. ksi [MPa] |
Yield Strength, min. ksi [MPa] |
Elongation, min. % |
---|---|---|---|
*A | 70 [480] | 28 [195] | 35 |
*B | 70 [480] | 25 [170] | 35 |
*C | 85 [585] | 55 [380] | 15 |
Applications:
