ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified

ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified

  • ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
  • ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
  • ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
  • ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM SB163 N04400
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap/Woven Case
Delivery Time: Depends on quantity
Payment Terms: L/C,T/T
Supply Ability: 1000 tons per month
Contact Now
All Products
Stainless Steel Seamless Pipe (290)
Stainless Steel Seamless Tube (277)
Duplex Stainless Steel Pipe (127)
Duplex Stainless Steel Tube (29)
Needle Tube (107)
Fin Tube (631)
Heat Exchanger (17)
Heat Exchanger Tube (424)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (116)
Heat Exchanger Baffle (36)
Air Cooler (8)
Pressure Vessel (4)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (114)
Nickel Alloy Pipe (261)
Nickel Alloy Tube (79)
Copper Alloy Tube (227)
Alloy Steel Tube (184)
Titanium Tube (10)
Bright Annealed Tube (153)
Boiler Tube (145)
Steel Fitting (804)
Steel Flange (590)
Others (391)
Cladding Parts (7)
Detailed Product Description
Material Grade: UNS N04400 / Monel 400 Product Type: Seamless Nickel-Copper Alloy Pipe
Certification Compliance: ASTM SB163, ASME SB163, EN 10204 3.1 End Connection Type: Plain End, Beveled End, Threaded
Surface Finish: Annealed & Pickled, Polished Corrosion Resistance: Seawater, Acids, Alkali Environments
Highlight:

ASTM SB163 Monel 400 seamless pipe

,

N04400 nickel alloy pipe EN10204 certified

,

Monel 400 pipe with 3.1 certification


ASTM SB163 UNS N04400 Nickel-Copper Alloy Seamless Pipe



N04400 Alloy Pipe Overview


ASTM SB163 UNS N04400 is a nickel-copper alloy seamless pipe renowned for exceptional corrosion resistance in acidic, alkaline, and marine environments. With high strength, thermal stability (up to 538°C), and superior fabricability, it’s ideal for critical applications in chemical processing, oil & gas, and marine engineering. Manufactured to ASTM SB163 standards, these pipes ensure reliability in extreme conditions.



N04400 Chemical Composition


The corrosion resistance of N04400 stems from its precise nickel-copper balance. Key elements include:


Element Content (%) Element Content (%)
Nickel (Ni) 63.0 min Copper (Cu) 28.0–34.0
Iron (Fe) 2.0 max Manganese (Mn) 2.0 max
Carbon (C) 0.3 max Sulfur (S) 0.024 max
Silicon (Si) 0.5 max



N04400 Equivalent Grades


N04400 alloy is globally recognized under these designations:


Standard Equivalent Grade Standard Equivalent Grade
UNS N04400 EN NiCu30Fe
DIN 2.4360 JIS NW4400
BS NA 13 ASME SB163



N04400 Mechanical Properties


Meets ASTM SB163 requirements for high strength and ductility:


Property Value
Tensile Strength 550 MPa (min)
Yield Strength (0.2%) 240 MPa (min)
Elongation (%) 35% (min)
Hardness (Rockwell B) 90 HRB (max)



N04400 Dimensional Tolerances


Precision-engineered to ASTM SB163 specifications:


Parameter Tolerance
Outer Diameter ±0.8% (OD ≤ 50mm)
±0.5% (OD > 50mm)
Wall Thickness +20% / -0% (Schedules 5S-XXS)
Length +3 mm / -0 mm (Cut Length)



N04400 Alloy Application Domains


N04400 pipes excel in corrosive and high-stress environments:


  • Marine Engineering: Seawater piping, pump shafts.


  • Chemical Processing: HCl/HF acid handling, heat exchangers.


  • Oil & Gas: Offshore platforms, valves, and fittings.


  • Power Generation: Feedwater heaters, condenser tubes.


  • Desalination Plants: Brine heaters, evaporator tubes.
