ASTM A270 TP304 Stainless Steel Welded Tube Sanitary Tube For Food and Beverage

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, LR, GL, DNV, NK, TS, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A270 TP304 Stainless Steel Sanitary Weld Tube

Payment & Shipping Terms:

Minimum Order Quantity:	500kgs
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	7 DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Product Name:	Stainless Steel Sanitary Tube	Shape:	Round, Square, Rectangle
Standard:	ASTM A270 / ASME SA270	Material:	TP304/304L/316/316L
O.D.:	25.4, 38.1, 50.8, 63.5MM....	W.T.:	1.2, 1.5, 2MM....
Surface:	Annealing,pickling,polishing,600 Grit Polished,Bright	Type:	Seamless / Welded
NDT:	ET, HT, PT
Highlight:	ASTM A270 Stainless Steel Welded Tube , Sanitary Stainless Steel Welded Tube , ASTM A270M Stainless Steel Welded Tube

ASTM A270 TP304 / 1.4301 / UNS S30400 Polished Stainless Steel Sanitary Welded Tubing

ASTM A270 TP304 welded stainless steel sanitary tube is designed for high-purity, corrosion-resistant applications in industries like food, beverage, pharmaceuticals, and biotechnology. While TP304 is the most widely used grade, TP316/L is preferred for chloride exposure. Always validate material selection against specific operational conditions (e.g., temperature, chemical exposure) and ensure proper welding/polishing to maintain system integrity.

Why Choose ASTM A270 Welded Tubing?

Hygiene: Meets strict sanitary requirements for contamination-free fluid transport.
Durability: Resists corrosion from cleaning agents (e.g., detergents, sterilants).
Customization: Available in various sizes (1/8" to 12" diameters) and finishes.

Equivalent Grade of ASTM A270 TP304 Stainless Steel Welded Tube Sanitary Tube

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
		BS	En	No	Name
304	S30400	304S31	58E	1.4301	X5CrNi18-10	2332	SUS 304

Chemical Composition of ASTM A270 TP304 Stainless Steel Welded Tube Sanitary Tube

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
304	min.	–	–	–	–	–	18.0	–	8.0	–
304	max.	0.08	2.0	0.75	0.045	0.030	20.0		10.5	0.10

Mechanical Properties of ASTM A270 TP304 Stainless Steel Welded Tube Sanitary Tube

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
304	515	205	40	92	201

Regular Dimensional Tolerences

Size OD	Nominal Wall	Outside Diameter	Length	Wall

1/2" (12.7)	0.065" (1.65)/0.049" (1.25)	+/-0.005 (0.13)	+1/8" (3.18) - 0	+/-10.0%
3/4" (19.1)	0.065" (1.65)/0.049" (1.25)	+/-0.005 (0.13)	+1/8" (3.18) - 0	+/-10.0%
1" (25.4)	0.065" (1.65)/0.049" (1.25)	+/-0.005 (0.13)	+1/8" (3.18) - 0	+/-10.0%
1-1/2" (38.1)	0.065" (1.65)/0.049" (1.25)	+/-0.008" (0.20)	+1/8" (3.18) - 0	+/-10.0%
2" (50.8)	0.065" (1.65)/0.049" (1.25)	+/-0.008" (0.20)	+1/8" (3.18) - 0	+/-10.0%
2-1/2" (63.5)	0.065" (1.65)	+/-0.010" (0.25)	+1/8" (3.18) - 0	+/-10.0%
3" (76.2)	0.065" (1.65)	+/-0.010" (0.25)	+1/8" (3.18) - 0	+/-10.0%
4" (101.6)	0.083" (2.11)	+/-0.015" (0.38)	+1/8" (3.18) - 0	+/-10.0%
6" (152.4)	0.083" (2.11)	+/-0.030" (0.76)	+1" (25.4) - 0	+/-10.0%
6" (152.4)	0.109" (2.77)	+/-0.030" (0.76)	+1" (25.4) - 0	+/-10.0%
8" (203.2)	0.109" (2.77)	+0.061" (1.55)/-0.031" (0.79)	+1" (25.4) - 0	+/-10.0%

Application

Food & Beverage:
- Milk processing, beer/wine production, juice lines.
Pharmaceuticals:
- Purified water systems, CIP (clean-in-place) systems, API (active pharmaceutical ingredient) transport.
Biotechnology:
- Bioreactors, fermentation tanks, vaccine production.
Cosmetics:
- High-purity fluid handling.
