Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | Yuhong |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | ASTM B466 C70600 |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
|---|---|
| Delivery Time: | 7 Days |
| Name: | COPPER NICKEL ALLOY SEAMLESS PIPE | Specification: | ASTM B466 |
|---|---|---|---|
| Test: | ET, HT, Flattening Test,Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination,Tension Testing. | Grade: | UNS No. C10100, C10200, C10300, C10800, C12000, C12200, C14200, C19200, C23000, C28000, C44300, C44400, C44500, C60800, C61300, C61400, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, And C72200 |
| High Light: | ASTM B466 C70600 Copper Alloy Pipe,ASME B36. 19 Copper Alloy Pipe |
||
ASTM B466 C70600 COPPER NICKEL ALLOY SEAMLESS PIPE ASME B36. 19
ASTM B466 C70600(CuNi 90/10) COPPER NICKEL ALLOY SEAMLESS PIPE ASME B36. 19
C70600 Pipe also called CuNi 90/10 Pipe, UNS C70600 Pipe, ASTM B466 C70600 Copper Nickel Pipe or Cupro Nickel 90/10 Pipe is ASME B36. 19 M, DIN 86019, EEMUA 144 and MIL-T-16420 copper nickel pipe.C70600 Pipes can stand a test of time, even in the most hostile environments like salty water.The main, wrought copper-nickel alloys chosen for sea water service contain 10 or 30 percent nickel. They also have important additions of iron and manganese which are necessary to maintain good corrosion resistance.C70600 Copper Nickel 10% Alloy is used in applications where resistance to corrosion and stress cracking is important. C70600 Copper Nickel 10% Alloy is known for its moderate strength, weldability and formability.
Typical Uses for C706 Copper Nickel "90/10":
AUTOMOTIVE: Power Steering Tube, Brake Lines
CONSUMER: Screw Lamp Bases
INDUSTRIAL: Condenser Plates, Condensers, Weld Torch Tips, Heat Exchanger Tubes, Valve Bodies, Evaporator Tubes, Pressure Vessels, Distiller Tubes, Pump Impellers for Oil Refining, Ferrules, Evaporators
MARINE: Boat Hulls, Tube Sheet for Salt Water Service, Salt Water Pipe Fittings, Salt Water Piping Systems, Salt Water Piling Wrap, Hot Water Tanks, Salt Water Baffles, Propeller Sleeves, Ship Hulls, Water Hoses
PLUMBING: Flanges
ASTM B466 C70600 Copper Nickel Seamless Pipes and Tubes Range
|
ASTM B466 C70600 Copper Nickel Seamless Pipe & Tubes Specification and Grade |
MIL-T-16420K, ASME-SB-466, ASTM-B-466, MIL-15005, ASME-SB-111, ASTM-B-111, UNS C71500, UNS C70600, CU -NI- 90/10, CU -NI- 70/30, CN102, C70600, C70610, CW352H, DEF STAN 02-879 Annex C, DEF STAN 02-779, NES 779, BS2870, BS2874, ASTM B151, EN 12163, 2.0872 NF A51-115, CuNi10Fe1Mn, |
|
Application |
|
|
Type |
Seamless / Hot Rolled / Cold Drawn / Welded / ERW |
|
Outer Diameter Size |
1/4 NB TO 12" NB 3 MM OD TO 114.3 MM OD |
|
Wall Thickness |
Schedule 10 to Schedule 160 |
| Length | 5 to 7 Meters, 09 to 13 Meters, Single Random Length, Double Random Length And Customize Size. |
|
Ends |
Plain Ends / Beveled Ends |
| Delivery Conditions | As Rolled, Cold Drawn, Hot Finish, Stress Relieved, Annealed, Hardened, Tempered |
| Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
|
Other Testing |
NACE MRO175, Hardness Test, Flare, Hydrostatic Test, Eddy Current test, Grain Size Test, Eddy Current, Annealed, Tempered, Stress Relieved etc. |
| Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM And ASME |
|
Value Added Services |
Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
| Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
| Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
Chemical Composition ASTM B466 Chemical Composition 90/10 Seamless Pipes and Tubes
The chemical composition of UNS C70600 copper nickel alloys is outlined in the following table.
| Element | Content (%) |
| Cu | 88.7 |
| Fe | 1.3 |
| Ni | 10.0 |
Physical Properties ASTM B466 Chemical Composition 90/10 Seamless Pipes and Tubes
The following table shows the physical properties of UNS C70600 copper nickel alloys.
| Properties | Metric | Imperial |
| Density | 8.94 g/cm3 | 0.323 lb/in3 |
