ASTM A554 Polished TP304 Stainless Steel Welded Square Tube Decorative Tube

ASTM A554 Polished TP304 Stainless Steel Welded Square Tube Decorative Tube

  • ASTM A554 Polished TP304 Stainless Steel Welded Square Tube Decorative Tube
  • ASTM A554 Polished TP304 Stainless Steel Welded Square Tube Decorative Tube
  • ASTM A554 Polished TP304 Stainless Steel Welded Square Tube Decorative Tube
  • ASTM A554 Polished TP304 Stainless Steel Welded Square Tube Decorative Tube
ASTM A554 Polished TP304 Stainless Steel Welded Square Tube Decorative Tube
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: TP304 / 304L TP316 / 316L TP321 / 321H
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Packaging Details: requirements/wooden case packing/Woven bag packing
Delivery Time: 7days
Payment Terms: L/C, T/T
Contact Now
Detailed Product Description
Product Name: Stainless Steel Welded Tube Standard: ASTM A554
Material Grade: TP304 / 304L TP316 / 316L TP321 / 321H Shape: Square
Surface: Polished Certificate: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Third Party Inspection: BV,SGS,ASP
High Light:

ASTM A554 Welded Square Tube

,

Polished Welded Square Tube



ASTM A554 Polished TP304 Stainless Steel Welded Square Tube Decorative Tube



ASTM A554 TP304 Polished Stainless Steel Welded Tube Square Decorative Tube




Overview
1.1 This specification covers welded stainless steel tubing for mechanical applications where appearance, mechanical properties, or corrosion resistance is needed.
1.2 This specification covers as-welded or cold-reduced mechanical tubing in sizes to 16 in. (406.4 mm) outside diameter, inclusive (for round tubing) and in wall thicknesses 0.020 in. (0.51 mm) and over.
1.3 Tubes shall be furnished in one of the following shapes as specified by the purchaser: round, square, rectangular, or special.
1.4 Supplementary requirements of an optional nature are provided and when desired shall be so stated in the order.
1.5 Values stated in inch-pound units, in accordance with the specifications, are to be regarded as the standard.





ASTM A554 Tubes furnished in one of the following shapes - round, square, rectangular, or special. Heat analysis performed in ASTM A554 Stainless Steel Tubing several grades of steel shall conform to the required chemical composition for manganese, phosphorus, carbon, silicon, sulfur, nickel, chromium, molybdenum, titanium, columbium, and tantalum. For ASME SA 554 Tubing small diameter or thin walls, or for both, where many drawing passes are required, the carbon content of 0.040 % maximum is necessary for grades MT-304L and MT-316L.





ASTM A554 STAINLESS STEEL TUBING SPECIFICATION

Specifications ASTM A554/ ASME SA554
Grades ASTM A554 ( MT304/304L, MT316/316L ),JIS G3446 ( SUS304TK, SUS316TK ), CNS 5802 ( 304TK, 316TK ), (YC1)
Size 6NB to 1200NB IN
O.D. 9.5mm ~ 139.7mm
Wall Thickness 0.6 ~ 3.05mm
Schedule SCH. 5, 10, 20, 30, 40, 60, 80, 100, 120, 140, 160, XXS.
Method TIG or TIG + Plasma or Laser
Finish 2B MIll Finish , No.4 finish, BA Finish, 400 Grit Finish, 550 Grit Finish, 600 Grit Finish
Length Single Random, Double Random & Cut Length
Types Round, Square, Rectangle, Coil, "U" Shape, Hydraulic & Honed Tubes
Products ASTM A554 Stainless Steel Polished Tubes, ASTM A554 L Polished Tubes, ASTM A554 TP316 No.4 Finish Tube, ASTM A554 TP316L Polished Tubes, ASTM A554 Tubing, ASTM A554 TP201 Welded Mechanical Tubing, ASTM A554 Welded Polished Tubes, ASTM A554 TP316 Stainless Steel Square Tube, ASTM A554 TP316L Mirror Polished Austenitic Stainless Steel Tubings for Decoration, ASTM A554 Square Tube





ASTM A554 TP304 EQUIVALENT

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
ASTM A554 TP304 S30400 304S31 58E 1.4301 X5CrNi18-10 2332 SUS 304c




Tube Gauge for ASTM A554 ASTM A554 Stainless Steel Welded Tubing, Polished, Plain End , TP304 / 304L TP316 / 316L TP321 / 321H Square

O.D./In. Wall/In. Wt./Ft.
0.750 x .750 .065
.605
0.750 x .750 .120 1.028
1.000 x 1.000 .049 .634
1.000 x 1.000 .065 .827
1.000 x 1.000 .083 1.035
1.000 x 1.000 .120 1.436
1.250 x 1.250 .065 1.047
1.250 x 1.250 .083 1.317
1.250 x 1.250 .120 1.844
1.500 x 1.500 .065 1.268
1.500 x 1.500 .083 1.599
1.500 x 1.500 .120 2.252
1.500 x 1.500 .180 3.230
1.750 x 1.750 .120 2.660
2.000 x 2.000 .065 1.710
2.000 x 2.000 .083 2.164
2.000 x 2.000 .120 3.050
2.000 x 2.000 .180 4.136
2.000 x 2.000 .250 5.410
O.D./In. Wall/In. Wt./Ft.
2.500 x 2.500 .083 2.730
2.500 x 2.500 .120 3.900
2.500 x 2.500 .180 5.352
3.000 x 3.000 .083 3.290
3.000 x 3.000 .109 4.250
3.000 x 3.000 .120 4.750
3.000 x 3.000 .180 6.578
3.000 x 3.000 .250 8.810
4.000 x 4.000 .120 6.460
4.000 x 4.000 .180 9.351
4.000 x 4.000 .250 12.210
5.000 x 5.000 .250 16.350
6.000 x 6.000 .250 19.020
6.000 x 6.000 .375 27.120
6.000 x 6.000 .500 38.123
8.000 x 8.000 .250 26.528
8.000 x 8.000 .375 39.291
8.000 x 8.000 .500 51.721




Tube Gauge for ASTM A554 ASTM A554 Stainless Steel Welded Tubing, Polished, Plain End , TP304 / 304L TP316 / 316L TP321 / 321H Rectangular

O.D./In. Wall/In. Wt./Ft.
0.750 x 1.500 .065
.937
1.000 x 1.500 .083 1.317
1.000 x 2.000 .065 1.270
1.000 x 2.000 .120 2.252
1.000 x 3.000 .065 1.710
1.500 x 2.500 .065 1.710
1.500 x 3.000 .120 3.480
2.000 x 3.000 .120 3.900
2.000 x 3.000 .180 5.352
O.D./In. Wall/In. Wt./Ft.
2.000 x 4.000 .120 4.750
2.000 x 4.000 .180 6.578
2.000 x 4.000 .250 8.810
2.000 x 5.000 .180 8.060
2.000 x 6.000 .180 9.420
2.000 x 6.000 .250 12.210
3.000 x 4.000 .120 5.610
4.000 x 6.000 .180 11.900
4.000 x 6.000 .250 15.620
4.000 x 6.000 .375 23.994
4.000 x 6.000 .500 31.324





Usage & Applications

1. Chemical and petrochemical

2. Power generation

3. Renewable energy

4. Pulp and Paper

5. Process piping

6. Oil and gas

7. Food and beverage
8. Marine Industry
etc.
