ASTM A106 Gr. B A53 GR.B Black Carbon Steel Seamless Pipe

ASTM A106 Gr. B A53 GR.B Black Carbon Steel Seamless Pipe

  • ASTM A106 Gr. B A53 GR.B Black Carbon Steel Seamless Pipe
  • ASTM A106 Gr. B A53 GR.B Black Carbon Steel Seamless Pipe
  • ASTM A106 Gr. B A53 GR.B Black Carbon Steel Seamless Pipe
  • ASTM A106 Gr. B A53 GR.B Black Carbon Steel Seamless Pipe
ASTM A106 Gr. B A53 GR.B Black Carbon Steel Seamless Pipe
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM A106 Gr. B
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: According to Client Requirements/ Ply-wooden Case/ Iron Case/ Bundle with plastic Cap
Delivery Time: 30-50 DAYS
Payment Terms: T/T, L/C
Supply Ability: According to Client Requirements
Contact Now
Detailed Product Description
Application: Boiler Pipe, Chemical Fertilizer Pipe, Structure Pipe Product Name: Factory Direct Sales Stainless Steel Pipe For Electric Heating Element,Seamless Stainless Steel Pipe/tube
Shape: Round Pipe Outer Diameter: 1 - 140 Inch
Usage: Construction Structure,Building,Transportation,For Liquid Delivery,chemical Industry
High Light:

A53 Seamless Black Steel Pipe

,

Black Seamless Pipe ASTM A106

,

ASTM A106 Carbon Steel Pipe

ASTM A106 Gr. B A53 GR.B Black Carbon Steel Seamless Pipe





We are one of the biggest projects pipeline products supplier in China. Our products contain steel pipe/tube,fittings, flanges. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.



Our main products: Stainless/Duplex/Nickel Alloy Pipe/Tube/Fitting/Flange:

1>. A: Stainless Steel Grade: TP304/304L/304H, TP310S/310H, TP316/316L/316Ti/316H, TP317L/317LN, TP321/321H, TP347/347H, NO8904(904L),

B: PH Stainless Steel:17-4PH(1.4542), 17-7PH(1.4568),15-7PH(1.4532)

C: Duplex Steel Grade: S31803(2205), S32750(2507), S32760, S32304, S32101, S31254(254Mo), 235Ma, UNS NO8926, NO8367.
D: Nickel Alloy Steel Grade:Hestalloy:C-276, C-4, C-22, C-2000, X, B-2, B-3, G-30, G-35. Monel:400,401, 404, R-405, K500.

Inconel:600, 601, 617, 625, 690, 718, 740, X-750. Incoloy:800, 800H, 800HT, 825, 840.

Pure Nickel:Ni-200, Ni-201, Ni-270. NS Alloy:Ns 1101, NS1102, NS1103,NS3105.

2>. Standards: ASTM A213, A249, A269, A312, A789,A790, B163,B167, B444, B677,... and ASME,DIN, EN, JIS, BS, GOST,...

3>. Out diameter sizes range: 0.5mm~650mm. Wall thickness:0.05mm~60mm. Max. length under 26 meters/PC.
4>. Seamless & welded, Solution Pickling/Bright Annealed / Polished.



ASTM A106 seamless pressure pipe (also known as ASME SA106 pipe) is commonly used in the construction of oil and gas refineries, power plants, petrochemical plants, boilers, and ships where the piping must transport fluids and gases that exhibit higher temperatures and pressure levels.



ASTM A106 Gr. B Black Carbon Steel Seamless Pipe Chemical Composition

Grade Grade A Grade B Grade C
Carbon max. % 0.25 0.30* 0.35*
*Manganese % 0.27 to 0.93 *0.29 to 1.06 *0.29 to 1.06
Phosphorous, max. % 0.035 0.035 0.035
Sulfur, max. % 0.035 0.035 0.035
Silicon, min.% 0.1 0.1 0.1
Chrome, max. % 0.4 0.4 0.4
Copper, max. % 0.4 0.4 0.4
Molybdenum, max. % 0.15 0.15 0.15
Nickel, max. % 0.4 0.4 0.4
Vanadium, max.% 0.08 0.08 0.08



ASTM A106 Gr. B Black Carbon Steel Seamless Pipe Mechanical Properties

Seamless and ERW A53 Grade A A53 Grade B
Tensile Strength, min, psi 48,000 60,000
Yield Strength 30,000 35,000



ASTM A106 Gr. B Black Carbon Steel Seamless Pipe Physical Properties

Density at 20 °C Modulus of elasticity kN/mm² at Thermal conductivity at 20 C° Spec. thermal capacity at 20 C° Spec. electrical resistivity at 20 °C
Kg/dm³ 20 C° 300 C° 400 C° 450 C° W/m K J/kg K Ω mm²/m
7,85 210 192 184 179 51 461 0,20



Hot forming and Heat treatment

Hot forming Heat treatment
Temperature °C Type of cooling Normalizing 1) Stress-relieving anneal 2) Type of cooling
1100 – 950 Air 890 – 950 °C 600 – 650 °C Air



ASTM A106 Gr. B Black Carbon Steel Seamless Pipe Application Industries



  • Off-Shore Oil Drilling Companies
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Heat Exchangers
  • Condensers
  • Pulp and Paper Industry



ASTM A106 Gr. B Black Carbon Steel Seamless Pipe Test Certificates



  • EN 10204/3.1B,
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • Third Party Inspection Report, etc



Material Testing:

  • Mechanical Testing Such as Tensile of Area
  • Hardness Test
  • Chemical Analysis – Spectro Analysis
  • Positive Material Identification – PMI Testing
  • Flattening Test
  • Micro and MacroTest
  • Pitting Resistance Test
  • Flaring Test
  • Intergranular Corrosion (IGC) Test



ASTM A106 Gr. B A53 GR.B Black Carbon Steel Seamless Pipe 0
