Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | ASTM A276 SS304, 304L, 316L, 310S, etc. |
| Minimum Order Quantity: | 100KGS |
|---|---|
| Packaging Details: | PLYWOOD CASE , PALLET |
| Delivery Time: | 7 DAYS |
| Payment Terms: | L/C,T/T |
| Product Name: | Round Bar | Standard: | ASTM A276, ASTM B166 |
|---|---|---|---|
| Material: | Stainless Steel: 304, 304L, 316L, 310S, Etc. Nickel Alloy:UNS N06600, N06601, N06603, N06690, N06693, N06025, N06045,etc. | Shape: | Round |
| Diameter: | Round Bars: 4mm To 500mm Bright Bars:4mm To 200mm | Length: | Can Custom Length |
| Surface: | Bright Surface | Application: | Oil And Gas Industries, Food Processing Industries, Equipments, Pipeline, Etc. |
| High Light: | 316L Stainless Steel Round Bar,Annealed Stainless Steel Round Bar,Bright Stainless Steel Round Rod 4mm |
||
ASTM A276 AISI 316L Stainless Steel Round Bar , Rod Bright Surface
ASTM A276 specifification covers hot-fifinished or cold-fifinished bars except bars for reforging (Note 1). It includes rounds, squares, and hexagons, and hot-rolled or extruded shapes, such as angles, tees, and channels in the more commonly used types of stainless steels. The free-machining types (Note 2), for general corrosion resistance and high-temperature service, are covered in a separate speci-fification.
NOTE 1 —For bars for reforging, see Specifification A 314.
NOTE 2 —For free-machining stainless bars designed especially for optimum machinability, see Specifification A 582/A 582M.
ASTM A276 316L is a molybdenum-bearing grade, the second mostly sought after grade next to grade 304 amongst the austenitic stainless steels. The molybdenum gives 316 better overall stability properties than Grade 304, particularly higher resistance in chloride environments.
Stainless Steel 316l Round Bars Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
ASTM A276 316l Round Bar Range
| ASTM A276 316l Round Bar Specification | ASTM A276 / ASTM A479 /ASTM A182 / ASME SA276 / ASME SA479 / ASME SA182 |
| ASTM A276 316l Round Bar Manufacturing Process | Hot Rolled / Cold Rolled / Hot Forging / Rolling / Machining |
| 316l Stainless Steel Rounds Bar Form | Stainless Steel Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Stainless Steel Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Stainless Steel Threaded, Stainless Steel Half Round Bar, Profiles, Stainless Steel Billet, Ingot, I/H Bar, Forging etc. |
| ASTM A276 316l Round Bar Other Grades |
304 / 304L / 304H / 309S / 316lL / 316lTi / 317L / 321 / 321H / 347H / 904L etc. UNS No. - UNS S30400, UNS S30403, UNS S31008, UNS S316l20, UNS S316l03, UNS S316l03, UNS S316l35, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904 |
| Cold Rolled Bar Technique | 316l Stainless Steel Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| ASTM A276 316l Round Bar Dimension | Round Bars : Outside Diameter in the range of 4mm to 500mm |
| ASTM A276 316l Round Bar Length | can Custom Length |
| ASTM A276 310 Round Bar Forms and Shape | Round, Square, Rectangle, Bright, etc. |
| ASTM A276 316l Round Bar Finish | Black, Bright Polished, Rough Turned, etc. |
| ASTM A276 316l Round Bar Dimension Standard | ASTM A 484 / ASTM A276, EN-10060, DIN-1013 etc. |
| ASTM A276 316l Round Bar Heat Treatment | Condition A in which the bars are Annealed Condition H in which the bars are Hardened and Tempered at a relative Temperature Condition T in which the bars are Hardened and Tempered at a relatively High Temperature Condition S in which the bars are Strain Hardened or relatively Light Cold Worked Condition B in which the bars are Relatively severe Cold worked. Solution Annealed, Aging and Double Aging |
| ASTM A276 316l Round Bar Packaging | Plywooden Case / Pallet, etc |
| ASTM A276 316l Round Bar Shipment & Transportation | By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
Stainless Steel 316l Round Bar Mechanical Properties
| Element | SS 316L |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | 485 Min |
| Yield Strength (0.2%Offset) | 170 Min. |
| Elongation | 40% Min |
| Hardness (Brinell) | 217 Max. |
Stainless Steel Bar Specifications
| ASTM A276 | This specification encompasses cold-finished or hot-finished bars, including rounds, squares, and hexagons, and hot-rolled or extruded shapes, such as angles, tees, and channels in the more commonly used types of stainless steels. |
| ASTM A479 | This specification includes cold and hot finished stainless steel bars, including rounds, squares, and hexagons, and hot-rolled or extruded shapes such as angles, tees, and channels. |
| ASTM A484 | This specification includes wrought stainless steel bars, shapes, forgings, and billets or other semi-finished materials, except wire, for forging. The materials are available in four types of conditions. |
| ASTM A582 | This specification includes cold or hot finished bars, which are suitable for machining processes. This specification includes rounds, squares, and hexagons, from common types of stainless free-machining steels. |
| ASTM B473 | This specification includes nickel alloy bar & wire, which can be produced in a solution-annealed condition, stabilized-annealed condition, or annealed condition. |
A276 316l Round Bar Applications
Oil and Gas Industries
Food Processing Industries
Equipments
Pipeline
