ASTM A312 TP316L Stainless Steel Seamless Pipe Heavily Cold Worked for Chloride Corrosion Resistance and Sub-Zero Temperature Use

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A312 TP316L

Payment & Shipping Terms:

Minimum Order Quantity:	100 KGS
Price:	NEGOTIABLE
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	20-80 days
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	1500 Tons Per Month

Contact Now

All Products

Stainless Steel Seamless Pipe (331)

Stainless Steel Seamless Tube (322)

Duplex Stainless Steel Pipe (134)

Duplex Stainless Steel Tube (36)

Needle Tube (156)

Fin Tube (703)

Heat Exchanger (28)

Heat Exchanger Tube (458)

Heat Exchanger Tube Bundle (49)

Heat Exchanger Tubesheet (125)

Heat Exchanger Baffle (39)

Air Cooler (11)

Pressure Vessel (4)

Stainless Steel Welded Pipe (61)

Stainless Steel Welded Tube (132)

Nickel Alloy Pipe (273)

Nickel Alloy Tube (101)

Copper Alloy Tube (250)

Alloy Steel Tube (210)

Titanium Tube (20)

Bright Annealed Tube (172)

Boiler Tube (152)

Steel Fitting (860)

Steel Flange (659)

Others (404)

Cladding Parts (8)

Detailed Product Description

Steel Grade:

300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series

Highlight:

Cold Worked Steel Seamless Pipe

Cold Rolled Seamless Steel Pipe TP316L

Brush Polish Stainless Seamless Pipe

ASTM A312 TP316L Stainless Steel Seamless Pipes Heavily Cold Worked

ASTM A312 TP316L is a specification for tubular products. Yuhong is a leading supplier of various ASTM A312 TP316L pipe sizes. Our ASME A312 TP316L products are uniquely suitable for sub-zero temperature applications. Our stainless steel tubes range from small to medium sizes, and we can also produce custom ASTM A312 TP316L seamless pipes.

These seamless pipes offer exceptional resistance to chloride corrosion, making 316L stainless steel pipes resistant to pitting and crevice corrosion even in chloride-rich environments. Our stainless steel pipe 316L seamless products are ideal for marine applications, seawater purification systems, and wastewater management applications.

Pipes are available in different schedules to accommodate various diameters and wall thicknesses. Stainless Steel Tube 316L Schedule 40 is designed for medium pressure ranges, while Stainless Steel Tube 316L Schedule 10S has relatively smaller wall thickness. Our 316L seamless pipe Sch 40 pipe is among the most commonly used in the oil and gas industry.

Material Properties

Grade 316 is the standard molybdenum-containing austenitic stainless steel, second in importance only to 304. The addition of molybdenum provides superior overall corrosion resistance compared to 304, particularly higher resistance to pitting and crevice corrosion in chloride environments.

This grade offers excellent forming and welding characteristics, making it easily formable into various parts for industrial, construction, and transportation applications. Grade 316 also features excellent welding characteristics, with post-weld annealing not required for thin sections.

Grade 316L, the low carbon version of 316, is not susceptible to sensitization (grain boundary carbide precipitation), making it ideal for heavy-duty welded components (approximately 6mm and thicker). The austenitic structure provides excellent toughness, even at low temperatures.

This steel is preferred for marine environments due to its superior pitting corrosion resistance compared to other grades. Its negligible magnetic response makes it suitable for applications requiring non-magnetic metals.

ASTM A312 TP316L Specification List

Manufacturer & exporter of dual certified ASTM A312 Grade TP316L Square Pipe in China. SS 316L Round Pipes are manufactured as per ASME B36.10 standard.

Specification	Details
ASTM / ASME Grade	ASTM A312 / ASTM SA 312
Dimensional ANSI Specifications	ANSI/ ASME B36.19M, ANSI/ ASME B36.10M
Different Types and Forms	Rectangle, Hex, Honed, Square, Round, Hydraulic Pipe supplier
Basic types we produce	100% X Ray Welded, CDW, ERW, Welded, Seamless, Fabricated
Pipe End Bevel	Plain, Beveled and Threaded End
Delivery & Finished Condition	Bright Annealed, Cold Drawn, Polished, Annealed and Pickled, Pickled and Passivated
Mechanical Surface Finish	2B, No.4, No.1, No.8 Mirror Finish or custom Finish as per customer Requirements
ASTM A312 TP316L Wall Thickness	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Other Facilities we offer	Grooving, Threading, Machining, Ultrasonic Testing, Customer Tagging/ Marking, Destructive, MTR's Available, Threading, Polishing, Export Documentation, Non Destructive, Beveling, Export Packaging, Cutting, Color Coding, Material testing

SS 316L Pipes Marking

Specification
Grade
Nominal Pipe Sizes
Pipe Schedule or Wall Thickness
Manufacturing Method (Seamless / Welded)
Heat Number
Manufacturer/ Supplier Name or Custom Logo - on request

Marked Pipe Sample: ANSI B36.19 ASTM A312 TP316L 12" NB SCH 60S SEAMLESS HEAT NO. XXXX

Final Finishing

Solution Annealed & Pickled

Applications

Food processing equipment, especially beer brewing, milk processing and wine making
Kitchen benches, sinks, equipment and appliances
Building paneling, railings and decoration
Chemical containers, including for transportation
Heat exchangers
Woven or welded screens for mining, quarrying and water filtration
Threaded fasteners
Springs
Other industrial applications
