ASME SA209 T1a Seamless Carbon-Molybdenum Alloy Steel Tube Minimum Wall Thickness

ASME SA209 T1a Seamless Carbon-Molybdenum Alloy Steel Tube Minimum Wall Thickness

  • ASME SA209 T1a Seamless Carbon-Molybdenum Alloy Steel Tube Minimum Wall Thickness
  • ASME SA209 T1a Seamless Carbon-Molybdenum Alloy Steel Tube Minimum Wall Thickness
  • ASME SA209 T1a Seamless Carbon-Molybdenum Alloy Steel Tube Minimum Wall Thickness
  • ASME SA209 T1a Seamless Carbon-Molybdenum Alloy Steel Tube Minimum Wall Thickness
ASME SA209 T1a Seamless Carbon-Molybdenum Alloy Steel Tube Minimum Wall Thickness
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASME SA209 T1a
Payment & Shipping Terms:
Minimum Order Quantity: 100 KGS
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 20-80 days
Payment Terms: T/T, L/C
Supply Ability: 1500 Tons Per Month
Contact Now
Detailed Product Description
Standard: ASTM, DIN, JIS, GB Application: Boiler Pipe
Thickness: 2 - 70 Mm Technique: Hot Rolled,Cold Drawn,Cold Rolled
Length: 4-12 M Type: Seamless Tubes
Material: Alloy Steel Shape: Round
Temperature Resistance: High Tolerance: ±1%
Edge: Mill Edge Slit Edge Alloy Or Not: Alloy
Schedule: Sch.10 To Sch.XXS
High Light:

Carbon Molybdenum Alloy Steel Tube

,

SMLS Alloy Steel Tube

,

2mm Alloy Steel Seamless Pipe

ASME SA209 T1a Seamless Carbon-Molybdenum Alloy Steel Tube Minimum Wall Thickness



ASTM A209 Grade T1a Alloy Steel Seamless Tubes are Carbon Steel Tubes with subsequent addition of chromium, molybdenum and sometimes vanadium are known as chrome moly Tubes.

ASTM Specification alloy steel Tubes are used for high temperature service applications. Seamless Alloy Steel Tubes according to ASTM A209 Grade T1a are reheated and furnished in full annlealed,isothermal annealed or normalised quenched and tempered condition.

ASTM A209 Grade T1a Alloy Steel Seamless Tubes have a typical chemistry with additions of 0.44-0.65 Molybdenum.

Bearing minimum tensile strength of 365 Mpa ASTM A209 Grade T1a Tubes have a minimum yield strength of 195 Mpa.

Chemical Properties:

Carbon: 0.15-0.25 Silicon: 0.10-0.50
Manganese: 0.30-0.80 Nickel: n/a
Potassium: 0.025 Chromium: n/a
Sulfur: 0.025 Molybdenum: 0.44-0.65

Mechanical Properties:

Tensile Strength:

ksi: 60

MPa: 414

Yield:

ksi: 32

MPa: 221

Elongation in 2in. or 50mm, min. %: 30

Max. Hardness Rockwell B: 81

Equivalent Designation

DIN EN BS NFA ASTM ASME
DIN 17175 Grade 16Mo5 – – ASTM A209 GradeT1a ASME SA 209 Grade T1a
