ASTM A270 TP304 Sanitary Stainless Steel Seamless Pipe Polished

ASTM A270 TP304 Sanitary Stainless Steel Seamless Pipe Polished

  • ASTM A270 TP304 Sanitary Stainless Steel Seamless Pipe Polished
  • ASTM A270 TP304 Sanitary Stainless Steel Seamless Pipe Polished
  • ASTM A270 TP304 Sanitary Stainless Steel Seamless Pipe Polished
  • ASTM A270 TP304 Sanitary Stainless Steel Seamless Pipe Polished
ASTM A270 TP304 Sanitary Stainless Steel Seamless Pipe Polished
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: TUV, API, PED, ISO
Model Number: ASTM A270 TP304
Payment & Shipping Terms:
Minimum Order Quantity: 100 KGS
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 20-80 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1500 Tons Per Month
Contact Now
Detailed Product Description
Steel Grade: 300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series Type: Seamless, Welded, Round Pipe
Standard: ASTM, AISI, GB, DIN, JIS Certification: ISO, SGS, BV, ISO&SGS, ISO/CE/SGS
Length: 3000-6000mm, Customized, 1800max, 11.8m Or As Required, 8m Thickness: 0.4-30mm, 1.0mm, 0.6-2500mm,1-60mm, 0.6-25mm
Technique: Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling Or Both Of Them Product Name: Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube
Material: 200 Series/300 Series/400 Series, 601 625 800 825, Stainless Steel, SS 201/304/316, X5CrNi18-20/1.4301 Outer Diameter: 6-630mm, 6-762mm, 6-860mm, Customized
Grade: 201/202/304/304L/316/316L/321/321H/347/347H/310S/410/420/430/440/439, Etc Finish: Brush Polish, Cold Drawn, Bright Annealed Or Un Annealed
High Light:

Polished Stainless Steel Seamless Pipe

,

TP304 Sanitary Steel Seamless Pipe

,

0.6mm Bright Annealed Tubing

ASTM A270 TP304 Sanitary Stainless Steel Seamless Pipe Polished

ASTM A270 TP304 grades cover standard specifications for sanitary modules. ASTM A270 TP304 pipe is designed with an austenitic composition and manufactured with high quality nickel and chromium compositions. The excellent content in these tubes gives them enhanced resistance to corrosive and reducing media in stress-induced environments. ASTM A270 TP304 Tubing has excellent resistance to oxidizing media and exhibits enhanced processability and strength. These tubes have good formability and can have threads, bevels and flat ends.



A270 Type 304 is usually produced in seamless and welded configurations. A270 Style 304 Seamless Sanitary Pipe is manufactured through an extrusion process in which a hot billet is passed through metal to precisely shape to the correct size. Compared to ASTM A270 TP304 Stainless Steel Welded Sanitary Pipe, these pipes are designed with no welds or seams for higher strength and load-bearing capacity. Welded pipe is; however, compared to seamless pipe, it is cheaper and can be formed into different sizes, which is not possible with the latter. ASME SA270 Grade 304 Welded Pipe is produced as sheet or strip is rolled and subsequently welded in a series of shop welding procedures. Pressurized vessel modules go through multiple testing and screening procedures before being suitable for use in these extreme conditions. ASME SA270 Gr 304 Welded Pipe has a long service life and will not degrade under any harsh environmental conditions. These tubes are available in sizes over 12 inches or cut to size. We are well connected to the supply chain, allowing us to deliver the best products to your door in short notice. For any questions and issues regarding our products or their pricing points, please contact us or visit us for more information.



A270 Sanitary Tubing Chemical Composition

CLASS C MAX THE MAX MN MAX P MAX S MAX NI CR MO OTHER PEOPLE
tp 304 0:08 0.75 2 0:04 0:03 8-11 18-20
tp 304L 0035 0.75 2 0:04 0:03 8-13 18-20
tp 316 0:08 0.75 2 0:04 0:03 10-14 16-18 2-3
tp 316L 0035 0.75 2 0:04 0:03 10-15 16-18 2-3

ASTM A270 Pipe Equivalent

GRADE UNS NO DIN/ EN / WERKSTOFF
304 S30400 1.4301
304H S30409 -
304L S30403 1.4306
310S S31008 1.4845
316S S31600 1.4436
316H S31609 -
316 TI S31635 1.4571
316L (2.5 MIN MOLY) S31603 1.4435
316L S31603 1.4404
317L S31703 1.4438
321 S32100 1.4541
321H S32109 -
347 S34700 1.4550
904L N08904 1.4539



Special characteristics

Temperature range: Density kg/dm³ Hardness (HB)
pressure bomb/pressure vessel
- 60°C bis 400°C
7,93 ≤ 230
excellent stability against pitting corrosion, stress corrosion and intergranular corrosion
