Detailed Product Description

Specification:	ASTM A335	Grade:	P22
Type:	Seamless	Surface:	Black Painted
Non Destructive Tesr:	Eddy Current Test -ASTM E426, Hystostatic Test-ASTM A999, Ultrsonic Test -ASTM E213	Size Standard:	ASTM B16.10 & B16.19 & Customized
High Light:	P22 Alloy Steel Seamless Pipe , Beveled Alloy Steel Seamless Pipe , A335 High Temperature Alloy Steel Tubes

ASTM A335 P22 Alloy Steel Seamless Pipe Black Painting Beveled

A335/SA335 Grade P22 Alloy Steel Seamless Pipes are Carbon steel pipes with addition of chromium, molybdenum, and sometimes vanadium. Chromium, or chrome, improves high-temperature strength, increases oxidation resistance and raises the tensile, yield and hardness at room temperatures.

Molybdenum increases the strength, elastic limit, resistance to wear, impact qualities and hardenability. It increases the resistance to softening, restrains grain growth and makes chromium steel less susceptible to embrittlement. Moly is also the most effective additive for increasing high temperature creep strength, or creep resistance, and it also enhances the corrosion resistance of steel and inhibits pitting.

Grade P22 is used for high temperature service applications and is tolerant to variations in its microstructure.

Chemical Composition Of P22

Carbon, %	P, %	Mo, %	Mn, %	Si, %	S, %	Cr, %
00.015 max	00.025 max	00.87-1.13	00.30-0.61	00.50 max	00.025 max	1.90-2.60

Mechanical and Physical Properties

Tensile Stress, MPa	Yield Stress, MPa	Elongation, %
415 MPa minimum	205 MPa minimum	30 minimum

Thick Wall

ASTM A335 P22 Alloy Steel Seamless Pipe Black Painting Beveled 0

Tensile Strength

	Seamless
	ASTM A335 P22 Pipes
Tensile Stress, minimum, psi
ksi	60
MPa	415
Yield Stress, minimum, psi
ksi	30
MPa	205

Tolerance For ASTM A335/ASME SA 335 P22 Seamless Pipes

NPS	OD Tolerance	NPS	WT Tolerance
1/8″ ≤ NPS ≤ 1 1/2″	+/- 0.4	1/8″ ≤ NPS ≤ 2 1/2″ , All T/D ratios.	+20%, -12.5%
1 1/2 < NPS ≤ 4″	+/- 0.79	NPS ≥ 2 1/2″ , T/D ≤ 5%	+22.5%, -12.5%
4″ < NPS ≤ 8″	+1.59, -0.79	NPS ≥ 2 1/2″ , T/D > 5%	+15%, -12.5%
8″ < NPS ≤ 12″	+2.38, -0.79	(T= Specified Wall Thickness; D = Specified Outside Diameter)
NPS > 12″	+/- 1%

P22 material equivalent

ASTM International	BSi - British Standards institute	Material
A335 Gr. P22	3604/622	2 1/4% Chrome 1% Moly

ASTM A335 P22 Alloy Steel Seamless Pipe Black Painting Beveled 1

ASTM A335 P22 Pipe Weight Chart

Size NPS	I.D.	Pipe O.D.	Standard Wall Thickness	Weight per Foot	Standard as per XXHY	Schedule Chart	Pipe Volume Gallon Capacity Per FT	Section Modulus
1/2	0.622	0.84	0.109	0.85	STD	40	.0158	.0407
	0.546		0.147	1.09	XHY	80	.0122	.0478
	0.464		0.188	1.31		160	.0088	.0528
	0.252		0.294	1.72	XXHY		.0026	.0577
3/4	0.824	1.05	0.113	1.13	STD	40	.0277	.0705
	0.742		0.154	1.48	XHY	80	.0225	.0853
	0.612		0.219	1.95		160	.0153	.1006
	0.434		0.308	2.44	XXHY		.0077	.1103
1	1.049	1.315	0.133	1.68	STD	40	.0449	.1328
	0.957		0.179	2.17	XHY	80	.0374	.1606
	0.815		0.250	2.85		160	.0271	.1904
	0.599		0.358	3.66	XXHY		.0146	.2136
1 1/4	1.380	1.66	0.140	2.27	STD	40	.0777	.2346
	1.278		0.191	3.00	XHY	80	.0666	.2913
	1.160		0.250	3.77		160	.0549	.3421
	0.896		0.382	5.22			.0328	.4110
1 1/2	1.610	1.90	0.145	2.72	STD	40	.1058	.3262
	1.500		0.200	3.63	XHY	80	.0918	.4118
	1.338		0.281	4.86		160	.0730	.5079
	1.100		0.400	6.41			.0494	.5977
2	2.157	2.375	0.109	2.64		10	.1898	.4205
	2.067		0.154	3.66	STD	40	.1743	.5606
	1.939		0.218	5.03	XHY	80	.1534	.7309
	1.875		0.250	5.68			.1434	.8045
	1.813		0.281	6.29			.1344	.8666
	1.687		0.344	7.47		160	.1161	.9806
	1.503		0.436	9.04	XXHY		.0922	1.1043
2 1/2	2.635	2.875	0.120	3.53		10	.2833	.6870
	2.469		0.203	5.80	STD.	40	.2487	1.0640
	2.443		0.216	6.14			.2435	1.1169
	2.375		0.250	7.02			.2301	1.2468
	2.323		0.276	7.67	XHY	80	.2202	1.3386
	2.125		0.375	10.02		160	.1842	1.6371
	1.771		0.552	13.71	XXXHY		.1280	1.9971
3	3.260	3.50	0.120	4.34			.4336	1.0411
	3.188		0.156	5.58			.4147	1.3122
	3.156		0.172	6.12			.4064	1.4265
	3.124		0.188	6.66			.3984	1.5342
	3.068		0.216	7.58	STD.	40	.3840	1.7241
	3.000		0.250	8.69			.3672	1.9372
	2.938		0.281	9.67			.3521	2.1207
	2.900		0.300	10.26	XHY	80	.3431	2.2253
	2.624		0.438	14.34		160	.2811	2.8774
	2.300		0.600	18.6	XXHY		.2158	3.4243
3 1/2	3.760	4.0	0.120	4.98		10	.5768	1.3776
	3.548		0.226	9.12	STD.	140	.5136	2.3939
	3.500		0.250	10.02			.4998	2.6001
	3.438		0.281	11.17			.4821	2.8562
	3.364		0.318	12.52	XHY	80	.4617	3.1400
	2..728		0.636	22.87	XXHY		.3085	4.8795
4	4.260	4.5	0.120	5.62		10	.7404	1.7612
	4.188		0.156	7.24			.7156	2.2354
	4.124		0.188	8.67			.6942	2.6296
	4.094		0.203	9.32			.6838	2.8173
	4.062		0.219	10.02			.6725	3.0184
	4.026		0.237	10.80	STD.	40	.6613	3.2145
	4.000		0.250	11.36			.6528	3.3611
	3.938		0.281	12.67		60	.6326	3.7021
	3.876		0.312	13.97			.6126	4.0273
	3.826		0.337	15.00	XHY	80	.5972	4.2713
	3.624		0.438	19.02		120	.5361	5.1790
	3.438		0.531	22.53		160	.4822	5.8997
	3.152		0.674	27.57	XXHY		.4054	6.7927
5	5.187	5.563	0.188	10.80			1.0979	4.1161
	5.125		0.219	12.51			1.0716	4.7279
	5.047		0.258	14.63	STD.	40	1.0391	5.4500
	5.001		0.281	15.87			1.0204	5.8644
	4.939		0.312	17.51			.99647	6.4074
	4.875		0.344	19.19			.9696	6.9358
	4.813		0.375	20.80	XHY	80	.9449	7.4300
	4.563		0.500	27.06		120	.8495	9.2534
	4.313		0.625	32.99		160	.7590	10.7976
	4.063		0.750	38.59	XXHY		.6734	12.0954
6	6.407	6.625	0.109	7.59		5	1.6748	3.5769
	6.357		0.134	9.30		10	1.6488	4.3475
	6.313		0.156	10.79			1.6260	5.0107
	6.249		0.188	12.94			1.5937	5.9351
	6.219		0.203	13.94			1.5780	6.3804
	6.187		0.219	15.00			1.5620	6.8261
	6.125		0.250	17.04			1.5306	7.6905
	6.065		0.280	18.99	STD.	40	1.5008	8.4958
	6.001		0.312	21.06			1.4688	9.3416
	5.937		0.344	23.10			1.4391	10.111
	5.875		0.375	25.05			1.4082	10.893
	5.761		0.432	28.60	XHY	80	1.3541	12.224
	5.625		0.500	32.74			1.2909	13.711
	5.501		0.562	36.43		120	1.2346	14.9806
	5.375		0.625	40.09			1.1787	16.1821
	5.187		0.719	45.39		160	1.0977	17.8243
	4.897		0.864	53.21	XXHY		.9784	20.025
	4.625		1.000	60.13			.8727	21.7719
	4.375		1.125	66.14			.7809	23.1237

Applications

-Pharmaceutical equipment
-Chemical equipment
-Sea water equipment
-Heat exchangers
-Condensers
-Pulp and paper industry
-Off-shore oil drilling companies
-Power generation
-Petrochemicals
-Gas processing
-Specialty chemicals
