| Place of Origin: | CHINA |
| Brand Name: | YUHONG GROUP |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | TP316Ti |
| Minimum Order Quantity: | 500kgs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Bundle /Ply-wooden Case |
| Delivery Time: | Depends on quantity |
| Payment Terms: | T/T, L/C at sight |
| Supply Ability: | 10000 Ton/month |
| Material Grade: | TP316Ti | Standard: | ASTM A269 |
|---|---|---|---|
| Size: | 1/8"TO 2" | W.T.: | SCH 5- SCH XXS |
| Length: | Single Random, Double Random & Cut Length | NDT: | ET HT UT PT |
| Packing: | Ply-wooden Case /Iron Case/ Bundle | Appllication: | Petrochemical/ Aviation /Food |
| High Light: | Petrochemical Stainless Steel Welded Tube,Stainless Steel Welded Tube ASTM A269,TP316Ti Welded Stainless Steel Round Tube |
||
Stainless Steel Welded Tube ASTM A269 TP316Ti Petrochemical Heat Exchangers
The characteristics of TP 316Ti
They are also used in the manufacture of petroleum tubing, fluid tubing, natural gas tubing, boilers, and heat exchangers. The grade offers seam, pitting and SCC resistance, as well as heat resistance at temperatures up to 860 degrees Celsius, so SS 316Ti tubes are perfect even in corrosive environments.
316Ti Stainless Steel Tube Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 10.00 - 14.00 | 68.395 min |
316 Ti Stainless Steel Tube Mechanical Property
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
ASTM A269 GRADE TP 316Ti Stainless Steel Tube Application
Heat exchanger
Condenser
Chemical
Petrochemical
aviation
