ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / Sheet / Coils

ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / Sheet / Coils

  • ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / Sheet / Coils
  • ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / Sheet / Coils
  • ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / Sheet / Coils
  • ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / Sheet / Coils
  • ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / Sheet / Coils
ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / Sheet / Coils
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: API , ABS, DNV, GL , LR, NK
Model Number: ASTM A240 UNS N08904 DIN1.4539 904L Stainless Steel Plate, Sheet
Payment & Shipping Terms:
Minimum Order Quantity: 500KGS
Packaging Details: Water proof and Seaworthy Package
Delivery Time: 7 DAYS
Payment Terms: LC, TT
Contact Now
Detailed Product Description
Product Name: Stainless Steel Plate, Sheet Standard: ANSI, ASTM, ASME, JIS, DIN, EN
Material: Stainless Steel 904L, 316L, 316, 321, 304, 304L, Etc. Width: As Resquest
Processing: Bending, Welding, Decoiling, Punching, Cutting Technique: Cold Rolled, Hot Rolled
Finish: Polished, Mirror, Bright, Hairline, Satin, Brushed, Ect. Packing: Water Proof And Seaworthy Package
High Light:

SS904L Stainless Steel Sheet

,

TP904L Stainless Steel Plate

,

Polished Cold Rolled Stainless Steel Plate

ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / sheet / Coils



With decades of production and export experience in this field, YUHONG GROUP is proud to say that we can handle kinds of projects, such as heat exchanger / boiler projects, marine projects, oil & gas projects etc. Every year we sell more than 80000 tons of stainless steel pipes and tubes. Our products have been well known among the customers around the world. YUHONG GROUP has build long term relationship with these valuable clients, which already cover more than 65 countries.



Description



904L Alloy (UNS N08904) is a super austenitic stainless steel with moderate to high corrosion resistance in a wide range of process environments. The combination of high chromium and nickel content, coupled with the addition of molybdenum and copper, guarantees good to excellent corrosion resistance, superior to 316L and 317L molybdenum reinforced stainless steel. The 904L alloy was originally developed to withstand environments containing dilute sulfuric acid. It also provides good resistance to other inorganic acids such as hot phosphoric acid as well as most organic acids. Therefore, it has excellent resistance to warm seawater and chloride attacks. The 904L is resistant to stress corrosion cracking due to the high amount of nickel in its composition. In addition, the addition of copper to these grades resists sulfuric acid and other reducing agents under both aggressive and mild conditions. Not only that, 904L alloy is easy to weld and process with standard shop manufacturing practices.



A240 904L Chemical Composition, max %



C Mn P S Si Cr
0.02 2.00 0.045 0.035 1.00 19.0-23.0
Ni Mo N Cu Others
23.0-28.0 4.0-5.0 0.10 1.0-2.0



A240 904L Mechanical Properties



Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) Brinell (HB)
904L 490 220 36 70-90 typical 150



SS 904L Sheets & Plates Equivalent Grades



STANDARD WERKSTOFF NR. UNS JIS KS BS AFNOR EN
SS 904L 1.4539 N08904 SUS 904L STS 317J5L 904S13 Z2 NCDU 25-20 X1NiCrMoCu25-20-5



Physical Properties of ASTM A240 TP 904L Stainless Steel Plates and Sheets


Grade

Density
(kg/m3)

Elastic Modulus
(GPa)

Mean Co-eff of Thermal Expansion (µm/m/°C)

Thermal Conductivity
(W/m.K)

Specific Heat 0-100°C
(J/kg.K)

Elec Resistivity
(nΩ.m)

0-100°C

0-315°C

0-538°C

At 20°C

At 500°C

904L

7900

190

15

-

-

11.5

-

500

952



ASTM A240 TP904L SS904L Stainless Steel Plate / Strip / Sheet / Coils 0
