Carbon Steel Pipe ASTM A192 Oil Gas Pressure Vessel Chemical Heating Power Plants

Product Details:

Place of Origin:	China
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	A192

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	Depends on quantity
Payment Terms:	T/T, L/C AT SIGHT
Supply Ability:	10000 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Standard:	ASTM A192	Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Test:	ET, UT, HT, PT	Type:	Carbon
O.D.:	1/ 2” NB To 36”NB	W.T.:	SCH 10 To SCH XXS
Highlight:	ASTM A192 Carbon Steel Pipe , 1/2” Pressure Vessel Carbon Steel Pipe , Heating Power Plants Seamless Steel Pipe

ASTM A192 Carbon Steel Pipe Oil Gas Pressure Vessel Chemical Heating Power Plants

Name: Carbon Steel Pipe ASTM A192 Oil Gas Pressure Vessel Chemical Heating Power Plants
Brand: Yuhong Group Co.,Ltd
SKU: A192
Price: 100000.00 USD
Availability: InStock

Abstract of ASTM A192

ASTM A192 seamless steel pipe as minimum wall thickness seamless carbon steel boiler tube and high pressure superheater tube, AGICO provides ASTM A192 steel pipe in hot rolled and cold drawn delivery condition, it is generally used for high pressure boiler (working pressure up to 9.8Mpa, working temperature between 450℃-650℃) heating surface tube, collector tube, coal saver, superheater, reheater.

Chemical Composition of ASTM A192

Grade	Chemical composition(%)
C	Type	C	Si	Mn	P	S
ASTM A192	S=Seamless	0.06~0.18	0.25Max	0.27~0.63	0.035Max	0.035Max

Mechanical Properties of ASTM A192

Grade	Elongation %	Tensile Test MPa or N/mm2
Grade	A	Min Yield Strength	Tensile Strength
ASTM A192	=35	=180	=325

Hardness Requirement of ASTM A192

Brinell Hardness Number	Rockwell Hardness Number
(Tubes 0.200 in. [5.1 mm] and over in wall thickness)	(Tubes less than 0.200 in. [5.1 mm] in wall thickness)
137 HB	77 HRB
