ASTM A179 ASME SA179 Seamless Carbon Steel Boiler Tube A210 Gr. A Tube

ASTM A179 ASME SA179 Seamless Carbon Steel Boiler Tube A210 Gr. A Tube

  • ASTM A179 ASME SA179 Seamless Carbon Steel Boiler Tube A210 Gr. A Tube
  • ASTM A179 ASME SA179 Seamless Carbon Steel Boiler Tube A210 Gr. A Tube
  • ASTM A179 ASME SA179 Seamless Carbon Steel Boiler Tube A210 Gr. A Tube
ASTM A179 ASME SA179 Seamless Carbon Steel Boiler Tube A210 Gr. A Tube
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ISO9001-2008, API 5L, API 5CT
Model Number: ASTM A179, ASME SA179
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Packaging Details: PLYWOOD CASE,BUNDLE,WOVEN BAG
Delivery Time: 7DAYS
Payment Terms: L/C, T/T
Contact Now
Detailed Product Description
Standard: A179,SA179 Material: GR.A ,B,C
Length: 6000MM,6096MM,SRL,DRL OD: 3/4" (19.05), 1"(25.4) , 1-1/4"(31.75), 1-1/2"(38.1), 2" (50.8), 2-1/2"(63.5) , 3" (76.2)
High Light:

ASME SA179 Carbon Steel Boiler Tube

,

A210 Carbon Steel Boiler Tube

,

Boiler Cold Drawn Seamless Tube

ASTM A179 ASME SA179 Seamless Carbon Steel Boiler Tube, A210 Gr. A Tube



What is ASME SA 179 (ASTM A179) Standard Specification. ASTM A179 (SA 179) standard specification covers seamless cold drawn low carbon steel pipe, for tubular heat exchanger, condensers and other similar heat transfer equipment. The ASTM A179 tube covers the OD from 1/8” to 3”, which is 3.2m m to 76.2 mm.



Seamless cold-drawn tube for tubular heat exchangers, condensers, and similar heat transfer apparatus.This pipe shall be made by the cold drawn process



Application: For high, middle, low pressure boiler and pressure purpose





Production Standard, Grade, Steel No:

ASTM A178 Grade A, C, D

ASTM A179 Grade A, C, D

ASTM A192

ASTM A210 GradeA-1, C

BS3059-Ⅰ 320 CFS

BS3059-Ⅱ 360, 440, 243, 620-460, 622-490, S1, S2, TC1, TC2

EN10216-1 P195TR1/TR2, P235TR1/TR2, P265TR1/TR2

EN10216-2 P195GH, P235GH, P265GH, TC1, TC2

DIN17175 ST35.8, ST45.8

DIN1629 ST37.0, ST44.0, ST50.0

JIS G3454 STPG370, STPG410

JIS G3461 STB340, STB410, STB440

GB5310 20G, 15MoG, 12CrMoG, 12Cr2MoG, 15CrMoG, 12Cr1MoVG, 12Cr2MoWVTiB

GB9948 10, 20, 12CrMo, 15CMo

GB3087 10, 20

Delivery Condition:Annealed, Normalized, Normalized and Tempered

Inspection and Test:

Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength,

Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.

Surface treatment:

Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting



Tube Sizes for Heat Exchangers & Condensers & Boiler
Outside Diameter   BWG
25 22 20 18 16 14 12 10
  Wall Thickness mm
0.508 0.71 0.89 1.24 1.65 2.11 2.77 3.40
mm inch   Weight kg/m
6.35 1/4 0.081 0.109 0.133 0.174 0.212
9.53 3/8 0.126 0.157 0.193 0.257 0.356 0.429
12.7 1/2   0.214 0.263 0.356 0.457 0.612 0.754
15.88 5/8   0.271 0.334 0.455 0.588 0.796 0.995
19.05 3/4   0.327 0.405 0.553 0.729 0.895 1.236
25.4 1   0.44 0.546 0.75 0.981 1.234 1.574 2.05
31.75 1 1/4   0.554 0.688 0.947 1.244 1.574 2.014 2.641
38.1 1 1/2   0.667 0.832 1.144 1.514 1.904 2.454 3.233
44.5 1 3/4       1.342 1.774 2.244 2.894 3.5
50.8 2       1.549 2.034 2.574 3.334 4.03
63.5 2 1/2       1.949 2.554 3.244 4.214 5.13
76.2 3       2.345 3.084 3.914 5.094 6.19
88.9 3 1/2       2.729 3.609 4.584 5.974 7.27
101.6 4         4.134 5.254 6.854 8.35
114.3 4 1/2         4.654 5.924 7.734 9.43
Form of Tube: Straight & U-bend & Finned & Coiled
Stainless Steel Tube: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81.

Carbon &Alloy Steel Tube: A/SA178, A/SA179, A/SA192,A/SA209, A/SA210, A/SA213, A.SA214
