ASTM SA213 / ASTM A213 T2 T11 T22 Alloy Steel Seamless Tube for Heat Exchanger Application

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM SA213 T22

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	7DAYS
Payment Terms:	L/C,T/T
Supply Ability:	1000Tons/Month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Standard:	ASTM A213 / ASME SA213	Material Grade:	T2, T11, T22
Size:	According To Client's Request	Length:	6M/12M
Packing Details:	Ply-wooden Case /Iron Case/ Bundle With Plastic Cap	Certificate:	ISO9001-2008, API 5L, API 5CT
Highlight:	Alloy Steel Boiler Tube , T22 Seamless Alloy Steel Tube , Heat Exchanger Alloy Steel Seamless Pipe

ASTM SA213 / ASTM A213 T22 T23 Alloy Steel Seamless Tube for Heat Exchanger Application

ASME SA213 T22 is a alloy steel grade in the ASME SA213M standard, which is 2.25Cr-1Mo chromium molybdenum high-temperature ferrite steel tube for boilers and superheaters. In 1985, China transplanted it to GB5310 and named it 12Cr2MoG. The oxidation resistance temperature of T22 is slightly higher than that of 12Cr1MoVG, but its strength performance is slightly lower. This steel has good processing and welding properties, as well as good durability and plasticity. Therefore, it has been widely used in harsh working environments, such as various heating pipelines and high-pressure vessels in thermal power, nuclear power, and some hydrogen equipment.

ASME SA213 T23 heat treatment system specified in ASME SA213 standard is: normalizing+tempering (normalizing temperature ≥ 1040 ℃, tempering temperature ≥ 675 ℃), yield strength ≥ 205MPa, tensile strength ≥ 415MPa, elongation ≥ 30%, and hardness ≤ 163HB.
The allowable stress of T23 steel is twice that of T22 steel, and its 580 ℃ rupture strength is 1.4 times that of 12Cr1MoV steel. The rupture strength of T23 steel is equal to that of 12Cr21MoWVTiB (G102) steel, and it has high impact toughness and good moisture permeability. It is suitable for manufacturing superheaters, reheaters, and water-cooled walls of large power plant boilers.

ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Chemical Composition and Mechanical Properties

Grade	Chemical Composition%
Grade	C	Si	Mn	P, S Max	Cr	Mo	Ni Max	V	Al Max
T2	0.10~0.20	0.10~0.30	0.30~0.61	0.025	0.50~0.81	0.44~0.65	–	–	–
T11	0.05~0.15	0.50~1.00	0.30~0.60	0.025	1.00~1.50	0.44~0.65	–	–	–
T12	0.05~0.15	Max 0.5	0.30~0.61	0.025	0.80~1.25	0.44~0.65	–	–	–
T22	0.05~0.15	Max 0.5	0.30~0.60	0.025	1.90~2.60	0.87~1.13	–	–	–
T91	0.07~0.14	0.20~0.50	0.30~0.60	0.02	8.0~9.5	0.85~1.05	0.4	0.18~0.25	0.015
T92	0.07~0.13	Max 0.5	0.30~0.60	0.02	8.5~9.5	0.30~0.60	0.4	0.15~0.25	0.015
Grade	Chemical Composition%				Mechanical Properties
Grade	W	B	Nb	N	T. S	Y. P	Elongation	Hardness
T2	–	–	–	–	≥ 415MPa	≥ 205MPa	≥ 30%	163HBW(85HRB)
T11	–	–	–	–	≥ 415MPa	≥ 205MPa	≥ 30%	163HBW(85HRB)
T12	–	–	–	–	≥ 415MPa	≥ 220MPa	≥ 30%	163HBW(85HRB)
T22	–	–	–	–	≥ 415MPa	≥ 205MPa	≥ 30%	163HBW(85HRB)
T91	–	–	0.06~0.10	0.03~0.07	≥ 585MPa	≥ 415MPa	≥ 20%	250HBW(25HRB)
T92	1.50~2.00	0.001~0.006	0.04~0.09	0.03~0.07	≥ 620MPa	≥ 440MPa	≥ 20%	250HBW(25HRB)

ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Tolerance

Permissible variations from the specified minimum wall thickness shall be in accordance with Specification A1016/A1016M.

Outside Diameter	OD Tolerance	WT Tolerance	Ovality Tolerance	Cut Length Tolerance
OD≤ 12, 7 mm	± 0, 13 mm	± 15 %	–	+ 3, 18 mm, – 0 mm
12, 7 mm < OD ≤ 38, 1 mm	± 0, 13 mm	± 10 %	max, 1, 65 mm	+ 3, 18 mm, – 0 mm
38, 1 mm < OD ≤ 88, 9 mm	± 0, 25 mm	± 10 %	max, 2, 41 mm	+ 4, 76 mm, – 0 mm
