Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, BV, DNV-GL , PED, TUV, LR, KR, NK, CCS |
| Model Number: | ASTM B622 UNS N10276 Alloy C276 Seamless Nickel Alloy Tube |
| Minimum Order Quantity: | 500KGS |
|---|---|
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 7 DAYS |
| Payment Terms: | L/C,T/T |
| Product Name: | Nickel Alloy Tube | Standard: | ASTM B622, ASME SB622 |
|---|---|---|---|
| Material: | N10665, N10276, NO6022, NO6035, NO6200, Etc. | NDT: | Eddy Current Test , Hydrostatic Test , Ultrasonic Test |
| Length: | Single Random, Double Random & Cut Length | Type: | Seamless, Welded |
| Form: | Straight, U Bend | End: | Plain End, Beveled End, Treaded |
| Packing: | Plywood Case, Bundle With Plastic Cap | ||
| High Light: | ASTM B622 UNS N10276 Seamless Nickel Alloy Tube | ||
ASTM B622 Hastelloy C276 UNS N10276 2.4819 Nickel Alloy Seamless Tubing
Hastelloy C276
Composition: ASTM B622 C276 tubes are composed primarily of nickel, molybdenum, and chromium. The alloy also contains small amounts of tungsten and cobalt, which enhance its corrosion resistance.
Corrosion Resistance: ASTM B622 C276 tubes exhibit exceptional corrosion resistance in a wide range of aggressive environments, including strong oxidizers, reducing environments, and chlorides. This makes them highly suitable for applications in chemical processing, pollution control, and seawater handling.
High Temperature Performance: These tubes offer excellent resistance to high-temperature oxidation and can withstand temperatures up to 1900°F (1038°C). This makes them suitable for use in heat exchangers, furnace components, and other high-temperature applications.
Versatility: ASTM B622 C276 tubes are versatile and can be easily fabricated into various forms, such as pipes, tubes, fittings, and flanges. They can also be welded using commonly used techniques, making them convenient for use in different industrial processes.
Mechanical Properties: These tubes possess outstanding mechanical properties, including good tensile strength, yield strength, and elongation. They retain their toughness and ductility even at low temperatures, providing reliable performance in demanding conditions.
Non-magnetic: ASTM B622 C276 tubes are non-magnetic, making them suitable for sensitive applications where magnetic interference should be avoided, such as in electronic equipment or MRI machines.
Equivalent Grades for Hastelloy Alloy C276 Tubes
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | - | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
The Specification of ASTM B622 UNS N10276 Nickel Alloy Tube
| Specifications | ASTM B622, B626 / ASME SB622, SB626 |
| Dimensions | ASTM, ASME and API |
| Size | 1/8” - 8” ; Seamless (Custom Sizes) 5.0mm - 203.2mm |
| Thickness | SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 |
| Type | Seamles / Welded |
| Form | Round, Square, Rectangular, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded |
Chemical Composition
| Hastelloy C276 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.010 max | 15.00 – 17.00 | 1.00 max | 0.08 max | 4.00 – 7.00 | 0.04 max | 0.03 max | 2.5 max | 14.50 – 16.50 |
Mechanical Properties
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | Psi – 1,15,000 , MPa – 790 | 40 % |
Applications
These tubes are often used in industries such as chemical processing, pulp and paper, and waste treatment, where resistance to corrosion and high temperatures is critical.
