Yuhong Holding Group Co.,LTD
Place of Origin: | China |
Brand Name: | YUHONG |
Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015 |
Model Number: | SS304, SS304L, SS316L |
Minimum Order Quantity: | 10 KGS |
---|---|
Price: | Negotiable |
Packaging Details: | Ply-wooden Case, Pallet |
Delivery Time: | 5 - 60 Work days |
Payment Terms: | T/T, L/C |
Supply Ability: | According to Clients' Requirement |
Material Grade: | SS304, SS304L, SS316L | Type: | Welded |
---|---|---|---|
Gauge: | 10G, 11G,12G......32G, 33G | Outer Diameter: | 0.2-3.4mm |
Wall Thickness: | RW, TW, ETW, UTW | Length: | As Required |
Shape: | Round | Technique: | Cold Drawn |
Finish: | Bright Annealing | Applications: | Medical,Industry,Decoration,Construction,Ornament |
Highlight: | Bright Annealed Capillary Needle Tubes,Aerospace Bright Annealed Round Tube,SS 316 Capillary Needle Tubes |
Stainless Steel 304 304L 316L Capillary Tubes, Needle Tubes For Medical Device And Aerospace
ANSI 304, 304L, 316L Stainless steel needle tube is a thin-walled tube with tight tolerances. Stainless steel needle Tubes with small diameter are used for subcutaneous injection. These needles are ideal for medical applications where corrosion resistance, uniformity and strength are required. SS injection needle has super strength, tensile strength between 1030Mpa and 1370Mpa. These needles are common products in medical applications, medical device manufacturing, and medical services. The ISO 9626 stainless steel needle tube is a very rigid needle that can be used to make a range of hypodermic needles primarily for human use. The needles range in metric size from 10 Gauge to 34 Gauge.
Stainless steel seamless medical needle tubes are produced by extrusion process. These tubes have no welds or seams, so they are much stronger and have excellent resistance under a variety of stress conditions. The SS 304 needle tube is made of nickel and chromium and has excellent performance. Its outer diameter is designed between 0.042mm and 0.095mm, and it has good tolerance to different conditions. We can customize products in different shapes and sizes according to customer requirements.
Specification & Size Range:
Capillary Tubes Grade: SS304, SS304L, SS316, SS316L,......
O.D: 0.2 –3.4 mm
W.T: 0.08 – 0.2 mm
Length: As per Customer Requirement
Standard: ASTM, DIN, ISO, other International Standards
Delivery Condition: Pickled, Polished, Bright Annealed, Electrolytic Polished
Chemical Composition:
% | C | Mn | Si | P | S | Cr | Ni | N |
Min. | - | - | - | - | - | 18.0 | 8.0 | - |
Max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 |
Mechanical Properties:
Material |
Heat Treatment |
Temperure Min.º F(º C) |
Tensile Strength Ksi (MPa), Min. |
Yield Strength Ksi (MPa), Min. |
Elongation %, Min |
TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
Applications:
Medical devices
Fabrication Industry
Food Processing Industry
Oil and Gas Industry
Chemical Industry
Water Supply Systems
Power Plants
Construction industry
Defence Industry
Paper & Pulp Industry
