Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015 |
| Model Number: | SUS430J1L |
| Minimum Order Quantity: | 200 KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Ply-wooden Case/ Pallet |
| Delivery Time: | 5 - 60 Work Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | According To Clients' Request |
| Standard: | JIS G4304, G4305 | Material Grade: | SS430J1L, 301, 304(L), 316(L), 321, 310, 329J3L, 410, 420J2, 430, Duplex |
|---|---|---|---|
| Product Name: | Stainless Steel Strip | Technique: | Hot Rolled, Cold Rolled |
| Length: | As Customer's Requests | Width: | 3mm-1500mm |
| Thickness: | 0.05mm-3.5mm | Finish: | 2B NO.1 NO.4 BA NO.8 |
| Packing: | Standard Sea-worthy Packing | Applications: | Construction,Industry,Tube,decoration,Automotive |
JIS G4304, G4305 SUS430J1L Precision Stainless Steel Strip For Marine Applications
SUS430J1L Stainless Steel Strip is a steel product manufactured from the hot rolled strip and then pickled. This Stainless Steel Strip is made up of austenitic stainless steel consisting of chromium, nickel, and manganese as the main constituents, which makes it have excellent thermodynamic properties such as specific heat capacity, melting point, thermal conductivity and coeficient of linear expansion. Stainless Steel Strips are widely used in various industries including chemical, food processing industries, construction, building materials, automobile industries, air conditioning, refrigeration, and washers industries.
Standard:
JIS G4304 : Hot-rolled stainless steel plate, sheet and strip
JIS G4305 : Cold-rolled stainless steel plate, sheet and strip
JIS G4312 : Heat-resisting steel plate, sheet and strip
Characteristics:
Good corrosion resistance
Good weldability
Can resist corrosion from organic acids, inorganic acids, alkalis, and chlorides, among other media
High hardness, strength and wear resistance
Can withstand high temperature and high pressure working conditions.
Good formability
| Product Parameters: Stainless Steel strip | |||
| Width | 3mm~1500mm | ||
| Thickness | 0.01mm~3.5mm | width tolerance | +/-0.1mm |
| Standard | ASTM/ASME 240/480,JIS 4305,DIN EN 10088-2 | ||
| Surface | 2B,BA,8K,NO.1,NO.4,NO.3,hairline,gold ,black ,rose gold,etc | ||
| Grade | SS304, 304DQ, 201, 301, 304L, 304H, 309S, 310S, 316L, 316TI, 317L, 321, 347, 347H, 430, 410, 410S, 420, 420J2, 430, 430LNT, 430J1L, 434, 436L, 439, 441, 443, 444, 904L, 2205, 2507, S32750, S32760, 445J2, 442, etc | ||
Chemical composition:
| C | 0.025Max. |
| Si | 1.00Max. |
| Mn | 1.00Max. |
| P | 0.04Max. |
| S | 0.03Max. |
| Cr | 16.00 - 20.00 |
| Ni | 0.60Max. |
| N | 0.025Max. |
Mechanical Properties:
| Tensile strength | 633～654 MPa |
| Yield Strength | 660 MPa |
| Elongation | 38％ |
| HBS | 309～903 |
| HRC | 30 |
Applications:
Building Decoration
Fuel Heating Parts
Hot Water Supply Systems
Household Appliances
Banding Systems
Home Appliance Parts
Hareware
