ASME SB111 C44300 Admiralty Brass Tube O61 Cold Finished for Heat Exchanger

Product Details:

Place of Origin:	China
Brand Name:	Yuhong
Certification:	ABS, BV, DNV-GL , PED, TUV, LR, KR, NK, CCS.
Model Number:	ASME SB111 C44300

Payment & Shipping Terms:

Minimum Order Quantity:	1000 kgs
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap etc.
Delivery Time:	20-80 days
Payment Terms:	L/C, T/T
Supply Ability:	800Tons/ month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Standard::	ASME SB111	Material::	C44300
Condition:	O61	Shape:	Round
Finish:	Cold Drawn	Test:	Expansion Test, Flattening Test, Eddy-Current Test, Hydrostatic Test
Application:	Heat Exchanger Tube
Highlight:	Cold Finished Copper Alloy Tube , O61 Copper Alloy Tube

ASME SB111 C44300 Admiralty Brass Tube O61 Cold Finished for Heat Exchanger

We are one of the largest manufacturers of stainless steel, duplex steel and alloy steel pipes in China. In our more than 20 years of development, we have won many customers all over the world, and Yuhong's products are highly appreciated by customers.

ASME SB111 C44300 Admiralty Brass is ideal for heat exchanger tubes. Normally this alloy is made to order to meet technical requirements. It is often used in oil and gas applications that also require its non-corrosive properties.C44300 Admiralty Brass Seamless Tubing minimum tensile strength in 310Mpa, minimum yield strength in 105Mpa.

COUNTRY	STANDARD	NAME
USA	ASTM B111	Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock
CHINA	GB/T8890	Seamless Copper Alloy Heat Exchanger Tubes
UK	BS2871	Copper and Copper Alloys Tubes
JAPAN	JIS H3300	Copper and Copper Alloy-Seamless Pipes and Tubes
GE	DIN1785	Wrought Copper and Copper Alloy Tubes for Condensers and Heat Exchangers

ASME SB111 C44300 Chemical Composition

Elements	Composition (%)
Cu Incl. Ag	70.0-73.0
Sn	0.9-1.2
Al	–
Ni incl. Co	–
Pb	0.07 max
Fe	0.06 max
Zn	Remainder
Mn	–
As	–
Sb	0.02-0.10
P	–
Cr	–
Other named elements	–

ASME SB111 C44300 Mechanical Properties

Properties	Measurement
Yield strength	105 MPa
Melting point	899 ~ 938 °C
Tensile strength	310 MPa
Thermal conductivity	109 W/m-K @ 20.0 °C
Density	8.53 g/cc
Heat capacity	0.09 cal/g-°C @ 20ºC
CTE linear strength	20.2 10-6/°C @ 20.0 – 300 °C

ASME SB111 C44300 Physical Properties

Copper or Copper Alloy UNS No.	Melting Point		Density		Coefficients of Linear Thermal Expansion		Specific Heat Capacity		Thermal Conductivity
	°C	°F	lb/in3	g/cm3	1×10-6/°C @ 20.0 – 30.0 °C	1×10-6/°F @ 70.0 – 570 °F	cal/g-°C, 20 °C	BTU/lb-°F @ 70°F	W/m-K, 20 °C	BTU/ft2/ft/h/°F @ 70°F

C44300	2140 – 2260	2010-2100	0.308	8.53	16.2	9	0.09	0.09	29	17

ASME SB111 C44300 Following benefits

Durability - The structure and chemical composition of the SB111 C44300 make it long-lasting. Its products can last up to 10 years, depending on where they are used and how often they are used.
Cost-effective - The overall value of installation, function and maintenance of products made from this material is relatively low. So you get quality when you choose this material to manufacture your products.
Versatile use - You can make various products with this material. For example, you can make pipes and hoses for a variety of applications.

Application
