ASME SA106 API 5L A53 Grade B Carbon Steel Seamless Pipe for Oil and Gas Industry

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ASME , U STAMP , PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS
Model Number:	ASME SA106

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	1--10000 USD
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap etc.
Delivery Time:	5---75 Tons
Payment Terms:	L/C, T/T
Supply Ability:	10000 Tons/Month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Standard:	ASME SA106	Equivalent Grade:	ASTM A53
Material:	Grade B	Type:	Seamless
Non Destructive Test:	Hydrostatic Test, Eddy Current Test, Ultrasonic Test
Highlight:	Fire Furnace Carbon Steel Pipe , 406.4MM Carbon Steel Pipe , A106 Carbon Steel Pipe

ASME SA106 API 5L A53 Grade B Carbon Steel Seamless Pipe for Oil and Gas Industry

In the oil and gas industry, where reliability and durability are crucial, ASME SA106 Grade B carbon steel seamless pipes stand out. Engineered to endure high - temperature, high - pressure conditions, they ensure the safe and efficient transport of fluids, making them an essential choice for critical pipeline infrastructure.

ASME SA106 Grade B Carbon Steel Seamless Pipe Chemical Requirements

Composition(%)	Carbon(max)	Manganese	Phosphorus(max)	Sulfur(min)	Silicon(min)	Chromium(max)	Copper(max)	Molybdenum(max)	Nickel(max)
Grade B	0.3	0.29 - 1.06	0.035	0.035	0.1	0.4	0.4	0.15	0.08

ASME SA106 Grade B Carbon Steel Seamless Pipe Tensile Requirements

Property	Tensile strength, min	Yield strength, min
Grade B	60,000 psi (415 MPa)	35,000 psi (240 MPa)

ASME SA106 Grade B Carbon Steel Seamless Pipe Common Size

NPS	DN	OD	5s	10s	10	20	30	40s	STD	40	60	80s	XS	80	100	120	140	160	XXS
3/4	20	26.7	1.65	2.11				2.87	2.87	2.87		3.91	3.91	3.91				5.56	7.82
1	25	33.4	1.65	2.77				3.38	3.38	3.38		4.55	4.55	4.55				6.35	9.09
1 1/4	32	42.2	1.65	2.77				3.56	3.56	356		4.85	4.85	4.85				6.35	9.70
1 1/2	40	48.3	1.65	2.77				3.68	3.68	3.68		5.08	5.08	5.08				7.14	10.15
2	50	60.3	1.65	2.77				3.91	3.91	3.91		5.54	5.54	5.54				8.74	11.07
2 1/2	65	73	2.11	3.05				5.16	5.16	5.16		7.01	7.01	7.01				9.53	14.02
3	80	88.9	2.11	3.05				5.49	5.49	5.49		7.62	7.62	7.62				11.13	15.24
3 1/2	90	101.6	2.11	3.05				5.74	5.74	5.74		8.08	8.08	8.08
4	100	114.3	2.11	3.05				6.02	6.02	6.02		8.56	8.56	8.56		11.13		13.49	17.12
5	125	141.3	2.77	3.40				6.55	6.55	6.55		9.53	953	9.53		12.70		15.88	19.05
6	150	168.3	2.77	3.40				7.11	7.11	7.11		10.97	10.97	10.97		14.27		18.26	21.95
8	200	219.1	2.77	3.76		6.35	7.04	8.18	8.18	8.18	10.31	12.70	12.70	12.70	15.09	18.26	20.62	23.01	22.23
10	250	273.1	3.40	4.19		6.35	7.80	9.27	9.27	9.27	12.70	12.70	12.70	15.09	18.26	21.44	25.40	28.58	25.40
12	300	323.9	3.96	4.57		6.35	8.38	9.53	9.53	10.31	14.27	12.70	12.70	17.48	21.44	25.40	28.58	33.32	25.40
14	350	355.6	3.96	4.78	6.35	7.92	9.53		9.53	11.13	15.09		12.70	19.05	23.83	27.79	31.75	35.71
16	400	406.4	4.19	4.78	6.35	7.92	9.53		9.53	12.70	16.66		12.70	21.44	26.19	30.96	36.53	40.49
18	450	457.2	4.19	4.78	6.35	7.92	11.13		9.53	14.27	19.05		12.70	23.83	29.36	34.93	3,967	45.24
20	500	508	4.78	5.54	6.35	9.53	12.70		9.53	15.09	20.62		12.70	26.19	32.54	38.10	44.45	50.01
22		559	4.78	5.54	6.35	9.53	12.70		9.53		22.23		12.70	28.58	34.93	41.28	47.63	53.98
24	600	610	5.54	6.35	6.35	9.53	14.27		9.53	17.48	24.61		12.70	30.96	38.89	46.02	52.37	59.54
26		660			7.92	12.70			9.53				12.70
28	700	711			7.92	12.70	15.88		9.53				12.70
30		762	6.35	7.92	7.92	12.70	15.88		9.53				12.70
32	800	813			7.92	12.70	15.88		9.53	17.48			12.70
34		884			7.92	12.70	15.88		9.53	17.48			12.70
36	900	914			7.92	12.70	15.88		9.53	19.05			12.70
38		965							9.53				12.70
40	1000	1016						9.53		12.70
42		1067				12.70	15.88		9.53	19.05			12.70
44	1100	1118							9.53				12.70
46		1168							9.53				12.70
48	1200	1219							9.53			12.70

ASME SA106 Grade B Carbon Steel Seamless Pipe NACE Test Requirements

Test Type	Test Standard	Test Method	Acceptance Criteria
HIC Test	NACE TM0284	Immerse specimens in H₂S - containing acidic solution (5% NaCl + 0.5% acetic acid, H₂S - saturated, pH 3.0 - 3.5) for 96h. Check cracks via microscopy, calculate CSR, CLR, CTR.	CSR ≤ 1.5%, CLR ≤ 15%, CTR ≤ 3% (subject to project)
SSCC Test	NACE TM0177	Method A:Four point bending: Apply 80% yield strength stress to specimens in H₂S - containing environment (5% NaCl + 0.5% acetic acid, H₂S - saturated) for 720h to check cracks. Tension test: Apply constant load (80% yield strength) in H₂S medium to observe cracks.	No visible cracks under specified conditions
