ASME SA335 P9 K90941 Ferritic Alloy Steel Seamless Pipe for Thermal Power Generation

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ISO9001-2008, PED, AD2000, LR, API 5L
Model Number:	ASME SA335 P9 K90941

Payment & Shipping Terms:

Minimum Order Quantity:	1000KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	10days->
Payment Terms:	T/T, L/C
Supply Ability:	1500 Tons per Month

Contact Now

All Products

Stainless Steel Seamless Pipe (278)

Stainless Steel Seamless Tube (267)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (91)

Fin Tube (605)

Heat Exchanger (10)

Heat Exchanger Tube (421)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (112)

Nickel Alloy Pipe (259)

Nickel Alloy Tube (75)

Copper Alloy Tube (211)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (787)

Steel Flange (576)

Others (384)

Detailed Product Description

Standard:	ASME SA213	Grade:	P9, K90941
Manufacture:	Cold Drawn	Test:	Hydrostatic Test, , Mechanical Test(Hardness Test, Transverse Test, Longitudinal Tension Test, Flattening Test, Bend Test)
Nondestructive Examination:	Practise E213, E309, E570
Highlight:	High Temperature Alloy Steel Pipe , A335 P9 Alloy Steel Pipe , Seamless Ferritic Alloy Steel Pipe

ASME SA335 P9 K90941 Ferritic Alloy Steel Seamless Pipe for Thermal Power Generation

ASME SA335 P9 Ferritic Alloy Steel Seamless Pipe are designed to cover nominal (average) wall seamless alloy-steel pipes meant for high-temperature applications.

SA335 P9 belongs to the high-temperature chromium-molybdenum alloy heat-resistant steel category. With excellent oxidation resistance, high-temperature strength, and resistance to sulfide corrosion, A335 P9 finds extensive usage in high-temperature, high-pressure, flammable, and explosive pipelines within petroleum refining and chemical equipment sectors, particularly in the direct heating pipes of heating furnaces. The operating temperature can range between 550-600 ℃.

ASME SA335 P9 Ferritic Alloy Steel Seamless Pipe Equivalent grade

Grade	Standard	Country
STBA26	JIS G3462	Japan
T9	ASTM A213	U.S.A
HT7	SAVDNIK	Sweden

ASME SA335 P9 Ferritic Alloy Steel Seamless Pipe Key Specifications

ASME SA335 Pipes: P9
Size Range: 1/8" to 26"
Schedules: 20, 30, 40, Standard (STD), 80, 100, 120, 140, 160, etc.

ASME SA335 P9 Ferritic Alloy Steel Seamless Pipe Chemical Composition

Grade	Chemical Composition(%)
Grade	C	Mn	P	S	Si	Cr	Mo
P9	≤0.015	0.30-0.60	≤0.025	≤0.025	0.25-1.00	8.00-10.00	0.90-1.10

ASME SA335 P9 Ferritic Alloy Steel Seamless Pipe Mechanical Property

Grade	Mechanical property
Grade	Tensile Strength(MPa)	Yield Strength(MPa)	Elongation(%)
P9	≥415	≥205	≥30

ASME SA335 P9 Ferritic Alloy Steel Seamless Pipe Outside diameter tolerances

NPS Designator	Over		Under
NPS Designator	in.	mm	in.	mm
1⁄8 to 1 1⁄2 , incl.	1 ⁄ 64 (0.015)	0.40	1 ⁄ 64 (0.015)	0.40
Over 1 1⁄2 to 4, incl.	1 ⁄ 32 (0.031)	0.79	1 ⁄ 32 (0.031)	0.79
Over 4 to 8, incl.	1 ⁄ 16 (0.062)	1.59	1 ⁄ 32 (0.031)	0.79
Over 8 to 12, incl.	3 ⁄ 32 (0.093)	2.38	1 ⁄ 32 (0.031)	0.79
Over 12	± 1 %

ASME SA335 P9 Ferritic Alloy Steel Seamless Pipe Inquiry Information
(1) Quantity (feet, centimetres, or number of lengths),
(2) Name of material (seamless alloy steel pipe),
(3) Grade (P9)
(4) Manufacture (hot-finished or cold-drawn),
(5) Size (NPS or outside diameter and schedule number or average wall thickness),
(6) Length (specific or random),
(7) End finish
(8) Test report required
