EN12449 CuZn20Al2As C68700 Brass Seamless Tube for Power Plants Condenser

EN12449 CuZn20Al2As C68700 Brass Seamless Tube for Power Plants Condenser

  • EN12449 CuZn20Al2As C68700 Brass Seamless Tube for Power Plants Condenser
  • EN12449 CuZn20Al2As C68700 Brass Seamless Tube for Power Plants Condenser
  • EN12449 CuZn20Al2As C68700 Brass Seamless Tube for Power Plants Condenser
  • EN12449 CuZn20Al2As C68700 Brass Seamless Tube for Power Plants Condenser
EN12449 CuZn20Al2As C68700 Brass Seamless Tube for Power Plants Condenser
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, BV, DNV-GL , PED, TUV, LR, KR, NK, CCS
Model Number: EN12449 CuZn20Al2As
Payment & Shipping Terms:
Minimum Order Quantity: 1000KGS
Price: Negotiable
Packaging Details: Strong Iron Case Packing
Delivery Time: 2-3 WEEKS
Payment Terms: L/C, T/T
Supply Ability: 1500 tons per month
Contact Now
All Products
Stainless Steel Seamless Pipe (278)
Stainless Steel Seamless Tube (267)
Duplex Stainless Steel Pipe (128)
Duplex Stainless Steel Tube (27)
Needle Tube (91)
Fin Tube (605)
Heat Exchanger (10)
Heat Exchanger Tube (421)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (35)
Air Cooler (7)
Pressure Vessel (2)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (112)
Nickel Alloy Pipe (259)
Nickel Alloy Tube (75)
Copper Alloy Tube (211)
Alloy Steel Tube (173)
Titanium Tube (9)
Bright Annealed Tube (153)
Boiler Tube (138)
Steel Fitting (787)
Steel Flange (576)
Others (384)
Detailed Product Description
Standard: EN12449:1999 Material: CuZn20Al2As
Test: Tensile Test, Hardness Tes, Eddy Current Test, Hydraulic Test, Peneumatic Test Application: Power Plants Condenser, Heat Exchangers
Highlight:

ASME SB111 Seamless Tube

,

C71500 Seamless Tube

,

C68700 Seamless Tube

EN12449 CuZn20Al2As C68700 Brass Seamless Tube for Power Plants Condenser



Plant Condensers: Optimal Corrosion & Thermal Performance

  • YUHONG ​​Material:​​ CuZn20Al2As (UNS C68700)
  • YUHONG ​​​​Standard:​​ EN 12449:2018 Compliant
  • ​​YUHONG ​​Application:​​ High-Pressure Steam Condensers
  • ​​YUHONG ​​Properties:​​ Seawater Corrosion Resistance | Anti-Biofouling | High Thermal Conductivity
  • ​​YUHONG ​​Certification:​​ SCC Tested per EN ISO 196 (Ammonia Vapor)

EN12449 Chemical Compositions

​​EN Designation​​ ​​UNS Number​​ ​​Alloy Name​​ ​​Cu (+Ag)​​ ​​Pb​​ ​​Fe​​ ​​Sn​​ ​​Zn​​ ​​Ni​​ ​​Al​​ ​​Mn​​ ​​P​​ ​​As​​ ​​Sb​​ ​​Other Elements​​ ​​Cu + Sum Listed Elements​​
​​CW004A​​ C11000 Copper ≥99.90 0.005 – – – – – – – – – – ≥99.97
​​CW008A​​ C12000 Phosphorus deoxidized Cu ≥99.90 0.005 – – – – – – 0.004–0.012 – – – ≥99.97
​​CW024A​​ C21000 Gilding brass 94.0–96.0 0.05 0.05 – Rem. – – – – – – – ≥99.5
​​CW502L​​ C22000 Commercial bronze 89.0–91.0 0.05 0.05 – Rem. – – – – – – – ≥99.5
​​CW506L​​ C23000 Red brass 84.0–86.0 0.05 0.05 – Rem. – – – – – – – ≥99.5
​​CW507L​​ C24000 Low brass 78.5–81.5 0.05 0.05 – Rem. – – – – – – – ≥99.5
​​CW508L​​ C26000 Cartridge brass 68.5–71.5 0.07 0.05 – Rem. – – – – – – – ≥99.5
​​CW600L​​ C31400 Leaded commercial bronze 87.0–89.0 0.7–1.2 0.1 – Rem. – – – – – – – ≥99.5
​​CW602N​​ C31600 Leaded brass 85.0–87.0 0.7–1.2 0.1 – Rem. – – – – – – – ≥99.5
​​CW614N​​ C33000 Leaded brass 65.0–68.0 0.25–0.7 0.07 – Rem. – – – – – – – ≥99.5
​​CW617N​​ C33500 Low-leaded brass 62.0–65.0 0.25–0.7 0.15 – Rem. – – – – – – – ≥99.5
​​CW702R​​ ​​C68700​​ ​​Aluminum brass (CuZn20Al2)​​ 76.0–79.0 0.07 0.06 – Rem. – 1.8–2.5 – – 0.02–0.10 – – ≥99.5
​​CW704R​​ C44300 Admiralty brass 70.0–73.0 0.07 0.06 – Rem. – – – – ​​0.02–0.10​​ ​​0.02–0.10​​ – ≥99.5
​​CW706R​​ C44400 Inhibited brass 70.0–73.0 0.07 0.06 – Rem. – – – – ​​0.02–0.10​​ – ​​P: 0.02–0.10​​ ≥99.5
​​CW707R​​ C44500 Inhibited brass 70.0–73.0 0.07 0.06 – Rem. – – – ​​0.02–0.10​​ – – – ≥99.5
​​CW712R​​ C46400 Naval brass 60.0–63.0 0.2 0.1 ​​0.7–1.0​​ Rem. – – – – – – – ≥99.5
​​CW715N​​ C48600 Leaded silicon brass 87.0–90.0 0.7–1.4 0.2 ​​1.3–2.2​​ Rem. – – – – – – ​​Si: 0.5 max​​ ≥99.5
​​CW721R​​ C70600 CuNi10Fe Rem. 0.02 ​​1.0–2.0​​ – – ​​9.0–11.0​​ – 0.5–1.0 – – – ​​Mn: 0.5–1.0​​ ≥99.5
​​CW725R​​ C71500 CuNi30Fe Rem. 0.02 ​​0.4–1.0​​ – – ​​29.0–32.0​​ – 0.5–1.0 – – – ​​Mn: 0.5–1.0​​ ≥99.5



EN12449 Mechanical Properties

​​EN Designation​​ ​​UNS Number​​ ​​Temper (TP)​​ ​​Rₘ (MPa) min​​ ​​Rp₀.₂ (MPa) min​​ ​​A (%) min¹​​ ​​Hardness HBW max​​
​​CW004A​​ C11000 O60 (Soft) 200 40 43 45
    H110 (Hard) 290 250 6 100
​​CW008A​​ C12000 O60 (Soft) 200 40 43 45
​​CW024A​​ C21000 O60 (Soft) 240 80 40 65
​​CW502L​​ C22000 O60 (Soft) 270 80 42 65
​​CW506L​​ C23000 O60 (Soft) 300 100 45 75
​​CW507L​​ C24000 O60 (Soft) 330 110 45 80
​​CW508L​​ C26000 O60 (Soft) 340 120 42 100
    H110 (Hard) 500 420 10 150
​​CW600L​​ C31400 O50 (Light annealed) 270 80 40 75
​​CW602N​​ C31600 O50 (Light annealed) 270 80 40 75
​​CW614N​​ C33000 O50 (Light annealed) 340 140 25 95
​​CW617N​​ C33500 O50 (Light annealed) 340 140 25 95
​​CW702R​​ ​​C68700​​ O50 (Light annealed) ​​450​​ ​​180​​ ​​25​​ ​​130​​
    H110 (Hard) 650 550 8 210
​​CW704R​​ C44300 O60 (Soft) 340 120 45 100
​​CW706R​​ C44400 O60 (Soft) 340 120 45 100
​​CW707R​​ C44500 O60 (Soft) 340 120 45 100
​​CW712R​​ C46400 O60 (Soft) 380 170 35 115
    H110 (Hard) 550 450 12 200
​​CW715N​​ C48600 O50 (Light annealed) 340 140 25 95
​​CW721R​​ C70600 O50 (Light annealed) 340 120 30 90
​​CW725R​​ C71500 O50 (Light annealed) 370 120 30 100



EN12449 Supplementary Requirements (All Grades)​​

Property​​ ​​Test Method​​ ​​Requirement​​
​​Hydrostatic Test​​ EN ISO 10896 Min. pressure: 6 MPa (60 bar) for ≥10 sec; no leakage or deformation
​​Flare Test​​ EN ISO 8494 Expand to 25% of OD without cracking (for tubes ≤100mm OD in soft temper)
​​Grain Size (Soft Tubes)​​ ASTM E112 / ISO 2624 Min. grain size ​​0.020 mm​​ (ASTM 6.0) for O60/O50 tempers
​​Stress Corrosion (SCC)​​ EN ISO 196 / ISO 6957 Optional: Pass ammonia vapor test (7 days, 35% NH₄OH) for brass alloys
​​Dezincification Resistance²​​ ISO 6509 For brass alloys: Max. depth ​​100 µm​​ (Class B/C requirements vary per alloy)





EN12449 CuZn20Al2As C68700 Brass Seamless Tube for Power Plants Condenser 0
