ASME SA213 TP347 TP347H Stainless Steel U Bend Tube ET/HT for Heat Exchanger Tube

ASME SA213 TP347 TP347H Stainless Steel U Bend Tube ET/HT for Heat Exchanger Tube

ASME SA213 TP347 TP347H Stainless Steel U Bend Tube ET/HT for Heat Exchanger Tube
video
ASME SA213 TP347 TP347H Stainless Steel U Bend Tube ET/HT for Heat Exchanger Tube
Product Details:
Place of Origin: China
Brand Name: YUHONG
Certification: ABS, BV, LR, DNV-GL, GOST, KR, CCS, CE, ASME , ISO9001, ISO14001, ISO 18001
Model Number: Heat Exchanger Tube, Stainless Steel U Bend Tube, ASTM A688,ASTM A213 , ASME SA213 , ASTM A249, ASME SA249, B163,B167, B444
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 10days->
Payment Terms: T/T, L/C
Supply Ability: 1500 tons per month
Contact Now
All Products
Stainless Steel Seamless Pipe (277)
Stainless Steel Seamless Tube (269)
Duplex Stainless Steel Pipe (128)
Duplex Stainless Steel Tube (27)
Needle Tube (86)
Fin Tube (596)
Heat Exchanger (10)
Heat Exchanger Tube (419)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (35)
Air Cooler (7)
Pressure Vessel (2)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (113)
Nickel Alloy Pipe (258)
Nickel Alloy Tube (75)
Copper Alloy Tube (210)
Alloy Steel Tube (173)
Titanium Tube (9)
Bright Annealed Tube (153)
Boiler Tube (138)
Steel Fitting (784)
Steel Flange (574)
Others (384)
Detailed Product Description
Material Grade: TP347 , TP347H Standard: ASTM A213 , ASTM A269 , ASME SA213
Type: U Bend , Straight , Coil Surface: Mill Finished, Bright Annealed , Polished
NDT: ET, UT, HT
Highlight:

Heat Exchanger Tube U Bend Tube

,

TP347 U Bend Tube

,

ASME SA213 U Bend Tube

ASME SA213 TP347 TP347H Stainless Steel U Bend Tube ET/HT for Heat Exchanger Tube



Yuhong Group has been dealing with austenitic stainless steel, nickel alloy steel (Hastelloy, Monel, Inconel, Inconel) seamless and welded pipes for 32 years, with sales of more than 80,000 tons of steel pipes annually. Our customers have covered more than 65 countries, such as Italy, UK, Germany, USA, Canada, Chile, Colombia, Saudi Arabia, Korea, Singapore, Australia, Poland, France, .... Our group of subsidiaries and factories have been certified by: ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2008, ISO 14001-2004.



Grade (UNS)

304/304L/304H (1.4301/1.4306/1.4948); 316/316L (1.4401/1.4404);

316Ti (1.4571)321 (1.4541); 309S (1.4833); 310S (1.4845);

317L (1.4438); 321H (1.4878); 347H (1.4550)2205 (1.4462), S31803, 2507, 904L
Outside Dia: 12.7mm - - 38.1mm (0.625" - - 1.252")
Wall thickness: 0.89 - - 2.77mm
Standards (Norm): ASTM A688 Standard for U bend Stainless steel Tube; ASTM A566
  EN 10216 - 5, DIN 17456, DIN 17458
  GB/T 14975, T 14976, T 13296, GB 5310
  ASTM A213, A 269, A312, A511, A789, A790
  JIS G3459, G3463
  GOST 9940, GOST 9941



ASME SA213 TP347 TP347H Stainless Steel U Bend Tube ET/HT for Heat Exchanger Tube 0





Application: Widely Used In Heat - exchanger Systems Bending Radius: 1.5*OD - 1500mm
Heat Treatment:

Stress Relieved After U - Bending

(Bending Area Plus 300MM For Each Leg)

 Material Grade:

304/304L/304H, 316/316L, 316Ti, 321,

309S, 310S, 317L, 321H, 347H, 2205,

S31803, 2507, 904L
Outer Diameter: 12.7mm - 38.1mm Standard:

ASTM A312, ASTM A269, ASME SA213,

ASTM A249, ASME SA249, ASTM A789,

EN10216 - 5 A106/A1016M
Type: Stainless Steel U Bends/Stainless Steel U Tube Wall Thickness: 0.89mm - 2.77mm



Corrosion Test Conducted only when specially requested by the client
Chemical Analysis Test done as per required quality standards
Destructive / Mechanical Testing Tensile | Hardness | Flattening | Flare | Flange
Reverse-bend and Re. flat tests Carried out in full compliance with relevant standards & ASTM A-450 and A-530 norms, which ensures trouble-free expansion, welding & use at customers end
Eddy Current Testing Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System
Hydrostatic Testing 100% Hydrostatic Testing carried out according to ASTM-A 450 norms for checking tube leakage, and biggest pressure we can support 20Mpa/7s .
Air Under Pressure Test To check any evidence of air leakage
Visual Inspection After passivation, every single length of tubes & pipes is subjected to thorough visual inspection by trained staff for detecting surface flaws & other imperfections


Supplementary Testing : Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. The tests conducted under this include:

  • Eddy Current Testing
  • O.P Testing
  • Radiography Testing
  • Corrosion Testing
  • Micro Testing
  • Macro Testing
  • IGC Testing
  • Ultrasonic testing
  • Liquid Penetrate testing





ASME SA213 TP347 TP347H Stainless Steel U Bend Tube ET/HT for Heat Exchanger Tube 1
