| Density | Melting Range | Yield Stress (0.2%Offset) | Tensile Stress | Elongation |
| 8.1 g/cm3 | 1443 °C (2430 °F) | Psi - 35000 , MPa - 241 | Psi - 80000 , MPa - 551 | 30 % |
Alloy WERKSTOFF NR. 2.4660 Pipe Chemical Composition
| Ni | C | Mo | Mn | Si | Fe | Cu | S | P | Cr |
| 32 - 38 | 0.02 max | 2 - 3 | 1 - 2 | 0.7 max | Bal | 3 - 4 | 0.005 max | 0.02 max | 19 - 21 |
Carpenter 20 Equivalent
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Alloy 20 | N08020 | 2.4660 | Z2NCUD31-20AZ | NiCr20CuMo | - | - | - |
Incoloy Alloy 20 Pipe is also known by its trade name Carpenter 20. Equivalent
Grades of Incoloy Alloy 20 Pipe include:
- UNS N08020
- ASTM B729
- ASTM B464
- ASTM B468
- ASTM B474
- ASME SB729
- ASME SB464
- ASME SB468
- ASME SB474
Alloy 20 Tubing Thermal Conductivity
| Mechanical & Physical Properties | 21.1°C | 49.4°C | 100°C | 150°C | 200°C | 300°C | 350°C | 400°C | 450°C | 500°C | 900°C |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Thermal Conductivity /kcal/(hr.m.°C) | - | 125.9 | 135.1 | - | 153.3 | 169.6 | - | 187.5 | - | - | - |
