| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008. |
| Model Number: | T2, K11547, P2, 12ChM, 12XM, 12CrMo, STBA20, STPA20, 0.5Cr-0.5Mo |
| Minimum Order Quantity: | 100KGS |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 20-80 |
| Payment Terms: | L/C, T/T |
| Specification: | ASTM A213 , ASME SA213 | Application: | Boiler Pipe, Chemical Fertilizer Pipe, Structure Pipe |
|---|---|---|---|
| Technique: | Hot Rolled | Surface Treatment: | Black Painted |
| Shape: | Round | Certification: | PED, TUV, ISO , ABS, DNV, GL , CCS, KR |
| Length: | 6 Meters Or Customized | Package: | Standard Seaworthy Package |
| Material Grade: | T2, K11547, P2, 12ChM, 12XM, 12CrMo, STBA20, STPA20, 0.5Cr-0.5Mo | ||
| High Light: | Boiler Alloy Steel Seamless Tube,Heat Exchanger Alloy Steel Seamless Tube,Alloy Seamless Tube ASME SA213 T2 |
||
Alloy Steel Seamless Tube ASME SA213 T2 For Boiler and Heat Exchanger application
ASTM T2 seamless tubes are a type of alloy steel tube primarily used in high-temperature service applications. They are manufactured according to the ASTM A213/A213M standard, which specifies seamless ferritic and austenitic alloy steel boiler, superheater, and heat-exchanger tubes. The T2 designation indicates the specific chemical composition and mechanical properties that the tube must meet.
Standard: ASTM A213, ASME SA213
Equivalent Standards: EN 10216-2, ASTM A335, GOST 550-75, JIS G3462, JIS G3458
Material: T2, K11547
Equivalent Material: P2, 12ChM, 12XM, 12CrMo, STBA20, STPA20, 0.5Cr-0.5Mo
| Chemistry Composition | ||||||
| C, % | Mn, % | P, % | S, % | Si, % | Cr, % | Mo, % |
| 0.10-0.20 | 0.30-0.61 | 0.025 max | 0.025 max | 0.10-0.30 | 0.50-0.81 | 0.44-0.65 |
| Mechanical Properties | |||
| Tensile Strength , MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
| 415 min | 205 min | 30 min | 163 max |
Application:
