ASTM A179 Carbon Steel Seamless Boiler Tube For Heat Exchangers And Condensers A210 A1

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ISO9001-2008, API 5L, API 5CT
Model Number:	ASTM A179, ASME SA179,ASTM A210 GR.A

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Packaging Details:	PLYWOOD CASE,BUNDLE,WOVEN BAG
Delivery Time:	7DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Standard:

ASTM A179,ASME SA179

Material:

A179

Length:

6000MM,6096MM,SRL,DRL

OD:

3/4" (19.05), 1"(25.4) , 1-1/4"(31.75), 1-1/2"(38.1), 2" (50.8), 2-1/2"(63.5) , 3" (76.2)

Highlight:

A210 Carbon Steel Seamless Boiler Tube

ASTM A179 Carbon Steel Seamless Boiler Tube

Condensers Carbon Steel Seamless Boiler Tube

ASTM A179 Carbon Steel Seamless Boiler Tube for Heat Exchangers and Condensers,A210 A1

ASTM A179 covers minimum-wall thickness, seamless cold-drawn low-carbon steel tubes for tubular, heat exchanger, condensers, and other heat transfer services. seamless ASTM A 179 steel tube is supplied and produced by cold drawning method. Chemical composition contains carbon, manganese, phosphorus, and sulfur.

Application: For high, middle, low pressure boiler and pressure purpose

Production Standard, Grade, Steel No:

ASTM A179

ASTM A192

ASTM A210 GradeA-1, C

Chemical Composition,

Material	Chemical Composition(%)
Material	C	Si	Mn	P	S
ASTM A179	0.06-0.18	≤ 0.25	0.27-0.63	≤0.035	≤0.035

Delivery Condition:Annealed, Normalized, Normalized and Tempered

Mechanical Propertie,

Grade	ASTM A179
Tensile Strength(MPa)	≥325
Yield Strength(MPa)	≥180
Elongation,%	≥35
Hardness, HRB	≤72

Inspection and Test:

Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength,

Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.

Tube Sizes for Heat Exchangers & Condensers & Boiler
Outside Diameter			BWG
		25	22	20	18	16	14	12	10
			Wall Thickness mm
		0.508	0.71	0.89	1.24	1.65	2.11	2.77	3.40
mm	inch		Weight kg/m
6.35	1/4	0.081	0.109	0.133	0.174	0.212
9.53	3/8	0.126	0.157	0.193	0.257	0.356	0.429
12.7	1/2		0.214	0.263	0.356	0.457	0.612	0.754
15.88	5/8		0.271	0.334	0.455	0.588	0.796	0.995
19.05	3/4		0.327	0.405	0.553	0.729	0.895	1.236
25.4	1		0.44	0.546	0.75	0.981	1.234	1.574	2.05
31.75	1 1/4		0.554	0.688	0.947	1.244	1.574	2.014	2.641
38.1	1 1/2		0.667	0.832	1.144	1.514	1.904	2.454	3.233
44.5	1 3/4				1.342	1.774	2.244	2.894	3.5
50.8	2				1.549	2.034	2.574	3.334	4.03
63.5	2 1/2				1.949	2.554	3.244	4.214	5.13
76.2	3				2.345	3.084	3.914	5.094	6.19
88.9	3 1/2				2.729	3.609	4.584	5.974	7.27
101.6	4					4.134	5.254	6.854	8.35
114.3	4 1/2					4.654	5.924	7.734	9.43
Form of Tube: Straight & U-bend & Finned & Coiled
Stainless Steel Tube: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81.
Carbon &Alloy Steel Tube: A/SA178, A/SA179, A/SA192,A/SA209, A/SA210, A/SA213, A.SA214
