EN 10216-5 1.4462 / UNS S32205 SAF Duplex 2205 Stainless Steel Seamless Pipe

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	EN 10216-5 1.4462 Duplex 2205 Stainless Steel Seamless Pipe

Payment & Shipping Terms:

Minimum Order Quantity:	500kgs
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Payment Terms:	L/C,T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Product Name:	Duplex Stainless Steel Seamless Pipe	Standard:	EN 10216-5 / ASTM A789/ A790
Grade:	1.4462 / UNS S32205	Surface:	Pickeled Annealed
Pipe End:	Plain End, Beveled End	Type:	Seamless
Application:	Oil And Gas Equipment; Heat Exchangers; Onshore/offshore Engineering
Highlight:	1.4462 Stainless Steel Seamless Pipe , UNS S32205 Stainless Steel Seamless Pipe , EN 10216-5 Stainless Steel Seamless Pipe

EN 10216-5 1.4462 / Duplex 2205 Stainless Steel Seamless Pipe Annealed & Pickled

EN 10216-5 is a part of the EN 10216 standard that specifically deals with seamless stainless steel tubes for pressure purposes. The specific alloy you mentioned, 1.4462 (also known as UNS S32205 or SAF Duplex 2205), is a duplex stainless steel known for its high strength and strength and excellent corrosion resistance, making it highly effective in demanding industrial environments.

Equivalent Grade of Duplex 2205

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
Grade	UNS No	BS	En	No	Name	Swedish SS	Japanese JIS
2205	S31803 / S32205	318S13	-	1.4462	X2CrNiMoN22-5-3	2377	SUS 329J3L

Corrosion Resistance

Pitting Corrosion: Has a high pitting resistance equivalent number (PREN), typically around 40. This makes it suitable for use in aggressive environments, such as those containing chlorides.
Stress Corrosion Cracking (SCC): Better resistance to SCC compared to conventional austenitic stainless steels, making it a preferred choice in chloride-rich environments.
General Corrosion: Excellent resistance to general corrosion in a variety of environments, including acids.

Testing and Standards

Non-Destructive Testing (NDT): Pipes are often subjected to NDT methods (like ultrasonic testing) to ensure integrity and detect any internal flaws.
Dimensional and Mechanical Tests: Encompasses tests for tensile strength, yield strength, elongation, and hardness as per the standard requirements.
Hydrostatic Testing: Each pipe may also undergo hydrostatic testing to ensure it can withstand pressure without leaking.

Fabrication and Forming

Welding:
- Suitable for welding using most conventional methods (TIG, MIG, etc.).
- It is recommended to use filler materials that match the composition of the base metal to ensure corrosion resistance and mechanical properties.
- Post-weld heat treatment (PWHT) is not typically required, but it should be controlled to prevent overheating.
Cold Working: Duplex steels can be cold worked, but this should be done carefully to avoid work hardening, which can lead to reduced ductility.

Other Material Grade

American Standard

Austenitic Steel:

TP304,TP304L,TP304H, TP304N, TP314,TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…

Duplex Steel :

S32101,S32205,S31803,S32304,S32750, S32760

Others:TP405,TP409, TP410, TP430, TP439,...

Europen Standard

1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501,1.4841

GOST Standard

08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ

Applications

Oil and Gas Industry: Used in pipelines, fittings, and components for offshore and subsea applications due to its high strength and corrosion resistance.
Chemical Processing: Ideal for processes involving aggressive chemicals, particularly in environments where chlorides are present.
Marine Applications: Frequently used in hulls, vessels, and other marine structures exposed to seawater.
Heat Exchangers: Suitable for heat exchangers in both seawater and industrial applications.
