ASTM A182 F5 Stainless Steel Weld Neck Flange RF / FF for Petrochemical Power Plants

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A182 F5

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	Negotiable
Packaging Details:	Plywooden Case /Iron Case
Delivery Time:	15-30days
Payment Terms:	L/C, T/T
Supply Ability:	1500 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Standard:	ASTM A182	Grade:	F5
Type:	Weld Neck	Application:	Petrochemical, Power Plants
Test:	Tension Test，Hardness Test, Corrosion Test, Nondestructive Test	Pressure Rating:	Class 150/300/600/900/1500/2500
Highlight:	FF Stainless Weld Neck Flange , Petrochemical Flange Stainless Steel , Weld Neck Flange Stainless Steel

ASTM A182 F5 Stainless Steel Weld Neck Flange RF/FF for Petrochemical and Power Plants

YUHONG GROUP is a leading manufacturer of industrial piping components with 30+ years of experience. We specialize in producing ASTM/ASME standard flanges for global clients in petrochemical, power generation and heavy industries.

Heat Treating Requirements for F5

Grade	Heat Treat Type	Austenitizing/Solutioning Temperature, Minimum or Range, °F [°C]	Cooling Media	Tempering Temperature, Minimum or Range, °F [°C]
F5	anneal normalize and temper	1650 [900]	furnace cool	1150 [620]

Chemical Requirements for F5

Grade	UNS Designation	Carbon	Manganese	Phosphorus	Sulfur	Silicon	Nickel	Chromium	Molybdenum
F5	K41545	0.15	0.30 - 0.60	0.03	0.03	0.5	0.5	4.0 - 6.0	0.44 - 0.65

Tensile and Hardness Requirements for F5

Grade Symbol	Tensile Strength, min, ksi [MPa]	Yield Strength, min, ksi [MPa]B	Elongation in 2 in. [50 mm] or 4D, min, %	Reduction of Area, min, %	Brinell Hardness Number, HBW, unless otherwise indicated
F5	70 [485]	40 [275]	20	35	143 - 217

Repair Welding Requirements for F5

Grade Symbol	ElectrodesA	Recommended Preheat and Interpass Temperature Range, °F [°C]	Post Weld Heat-Treatment Temperature, Minimum or Range, °F [°C]
F5	E80XX-B6, where XX can be 15, 16, or 18	400 - 700 [205 - 370]	1250 [675]
