ASTM A269 TP316L Stainless Steel Seamless Tube Cold Drawn Pickled Annealed Tube

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A269 TP316L Stainless Steel Seamless Tube

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Packaging Details:	Ply-wooden Case/ Bundle with plastic Cap
Delivery Time:	7 DAYS
Payment Terms:	L/C,T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Product Name:	Stainless Steel Seamless Tube	Standard:	ASTM A269, ASME SA269
Material:	TP316L	OD:	1/4" , 3/8", 1/2", 5/8", 3/4", 1", 1.1/4", Etc.
Length:	Single Random, Double Random & Cut Length	End:	Plain End, Beveled End
Type:	Seamless, Welded	Surface:	Polished, Annealed Pickled, Bright Annealed
Application:	Heating, Cooling, Instrumentation, Food Processing Machine,
Highlight:	ASTM A269 Stainless Steel Seamless Tube , Annealed Pickled Stainless Steel Seamless Tube , TP316L Stainless Steel Seamless Tube

ASTM A269 / ASME SA269 Stainless Steel 316L CF Pickled Annealed Seamless Tube

ASTM A269 TP316L seamless tubes are high-quality stainless steel tubes designed for exceptional corrosion resistance and strength in various environments. Made from low carbon 316L stainless steel, they are ideal for applications in the oil and gas, marine, food processing, and pharmaceutical industries. The lower carbon content minimizes the risk of carbide precipitation during welding, enhancing their durability. These tubes offer good mechanical properties, excellent weldability, and resistance to pitting, making them suitable for high-temperature and corrosive conditions. Their seamless construction ensures uniformity and reliability, making them a preferred choice for demanding applications.

Low Carbon Content: The “L” in 316L indicates lower carbon content (≤0.03%), which significantly improves the resistance to sensitization during welding. This means it’s less likely to form chromium carbides at grain boundaries, which can lead to intergranular corrosion.
Aesthetic Appeal: The smooth surface finish can be polished to a bright luster, making it suitable for applications where appearance is important (such as architectural features).
Versatility: The versatility of 316L makes it a go-to choice for various sectors, from manufacturing to utilities, providing reliable performance in diverse environments.

ASTM A269 TP316L Stainless Steel Seamless Tube Equivalent Grades

Grade	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 316L	1.4404 / 1.4435	S31603	SUS 316L	316S11 / 316S13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3

ASTM A269 TP316L Stainless Steel Seamless Tube Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Fe
SS 316L	0.035 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 - 18.00	2.00 - 3.00	10.00 - 14.00	68.89 min

ASTM A269 TP316L Stainless Steel Seamless Tube Physical Properties

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Co-eff of Thermal Expansion (µm/m/°C)			Thermal Conductivity (W/m.K)		Specific Heat 0-100°C (J/kg.K)	Elec Resistivity (nΩ.m)
			0-100°C	0-315°C	0-538°C	At 100°C	At 500°C
316L	8000	193	15.9	16.2	17.5	16.3	21.5	500	740

Inspection and Testing

When tubes are manufactured, they undergo various tests to ensure they meet the strict standards outlined by ASTM A269. Common inspection techniques include:

Hydrostatic Testing: To check for leaks and ensure that the tube can handle pressure.
Eddy Current Testing: Used for detecting surface flaws.
Dimensional Inspection: Ensures that the tube meets the specified size and wall thickness standards.
Surface Inspection
Chemical Composition
Mechanical Properties
...

Manufacturing Process:

Seamless Tubing:

Produced from solid round billets, which are heated and then pierced to create a hollow tube.

Further processing involves cold drawing to achieve the desired dimensions and surface roughness.

Annealing:

A heat treatment process that improves ductility and relieves stresses due to drawing.

Pickling:

A chemical process that removes surface oxides and impurities, resulting in a clean surface.

Applications

Oil and Gas Industry: Used in the construction of pipelines and equipment that are exposed to harsh environments, where resistance to corrosion is vital.
Marine Components: Commonly used for making marine hardware, boat fittings, and other components exposed to seawater.
Food Processing: Employed in food and beverage processing systems to ensure sanitary conditions due to its ease of cleaning and resistance to corrosive substances.
Pharmaceutical Equipment: Ideal for manufacturing tanks and tubing in the pharmaceutical industry, where hygiene and cleanliness standards are critical.
Heat Exchangers: Often utilized in heat exchangers due to its excellent resistance to chlorides and high temperatures.
