ASTM A249 TP316L Bright Annealed Stainless Steel Welded Tube Heat Exchanger Tube

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, LR, GL, DNV, NK, TS, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A249 TP316L Stainless Steel Welded Tube

Payment & Shipping Terms:

Minimum Order Quantity:	500kgs
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	7 DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Product Name:	Stainless Steel Welded Tube	Standard:	ASTM A249 / ASME SA249
Material Grade:	TP304, TP304L , TP304H, TP309, TP310S, TP310H, TP316, TP316L, TP316Ti，TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, TP904L	Size:	6.35mm (1/4"), 9.52mm (3/8"), 12.7mm(1/2"), 15.88mm (5/8"), 19.05mm(3/4"), 25.4mm (1"), 31.75mm(1-1/4"), 38.1mm (1-1/2"), 44.45mm(1-3/4"), 50.8mm(2"), 63.5mm(2-1/2"), 76.2mm(3"), 101.6mm (4")
Length:	Single Random, Double Random & Cut Length	Tube End:	Plain End, Beveled End
Surface:	Bright Annealed (BA), Pickled And Annlealed , Polished	Form:	Straight & U Bend & Coil
Application:	Boiler, Super Heater, Heat Exchanger And Condenser
Highlight:	ASTM A249 Stainless Steel Welded Tube , Heat Exchanger Stainless Steel Welded Tube , Bright Annealed Stainless Steel Welded Tube

ASTM A249 TP316L Bright Annealing Stainless Steel Welded Tube for Heat Exchanger

ASTM A249 TP316L welded tubes are premium stainless steel tubes engineered for high-performance applications. Constructed from 316L stainless steel, these tubes provide outstanding resistance to corrosion, particularly in environments with high chloride levels, making them suitable for industries such as petrochemicals, pharmaceuticals, and power generation.

This step can optimize the tube's performance in high-temperature applications with following advantages:

Enhanced Corrosion Resistance: By removing impurities and oxides from the surface, bright annealing improves the protective chromium oxide layer on stainless steel, enhancing corrosion resistance.
Superior Surface Finish: The process results in a smooth, bright, and aesthetically appealing surface finish, making it ideal for applications where appearance is important.
Consistent Mechanical Properties: Bright annealing homogenizes the microstructure, resulting in consistent and improved mechanical properties such as strength and ductility.
Reduction in Secondary Processing: With a clean and bright surface finish, parts may require less machining or polishing after annealing, reducing production times and costs.
Improved Weldability: The process reduces or eliminates surface defects that can weaken welds, thereby enhancing the weldability of the material.
Thermal Stability: The targeted temperature range allows materials to retain their properties under thermal stress, making them suitable for high-temperature applications.
Minimized Contamination: The controlled atmosphere significantly reduces the risk of contaminating the metal surface, ensuring that the properties of the material remain intact.
Durability: The overall durability of the material is improved due to optimally processed microstructures, leading to longer service life in harsh environments.

ASTM A249 TP316L Stainless Steel Welded Tube Equivalent Grade

JIS	WNR. / DIN	UNS	AISI	EN
SUS316L	1.4404	S 31603	316L	02Cr17Ni12Mo2

ASTM A249 TP316L Stainless Steel Welded Tube Mechanical Properties

	Tensile Stress (Mpa)	Yield Stress (Mpa)	Elongation (%)	Elongation (%)
SA 249 316L	485	170	35	25
1.4404	490-690	190	40	30

ASTM A249 TP316L Stainless Steel Welded Tube Chemical Composition

SA 249	C	Mn	P	S	Si	Ni	Cr	Mo	N
316L	0.035	2.00	0.045	0.030	1.0	10-14	16-18	2-3
1.4404	0.03	2.00	0.040	0.015	1.0	10-13	16.5-18.5	2-2.5	0.11

Dimensional Tolerences--all dimensions in inches (mm)

Size OD	Nominal Wall	Outside Diameter	Length	Wall

1/2" (12.7)	0.065" (1.65)/0.049" (1.25)	+/-0.005 (0.13)	+1/8" (3.18) - 0	+/-10.0%
3/4" (19.1)	0.065" (1.65)/0.049" (1.25)	+/-0.005 (0.13)	+1/8" (3.18) - 0	+/-10.0%
1" (25.4)	0.065" (1.65)/0.049" (1.25)	+/-0.005 (0.13)	+1/8" (3.18) - 0	+/-10.0%
1-1/2" (38.1)	0.065" (1.65)/0.049" (1.25)	+/-0.008" (0.20)	+1/8" (3.18) - 0	+/-10.0%
2" (50.8)	0.065" (1.65)/0.049" (1.25)	+/-0.008" (0.20)	+1/8" (3.18) - 0	+/-10.0%
2-1/2" (63.5)	0.065" (1.65)	+/-0.010" (0.25)	+1/8" (3.18) - 0	+/-10.0%
3" (76.2)	0.065" (1.65)	+/-0.010" (0.25)	+1/8" (3.18) - 0	+/-10.0%
4" (101.6)	0.083" (2.11)	+/-0.015" (0.38)	+1/8" (3.18) - 0	+/-10.0%
6" (152.4)	0.083" (2.11)	+/-0.030" (0.76)	+1" (25.4) - 0	+/-10.0%
6" (152.4)	0.109" (2.77)	+/-0.030" (0.76)	+1" (25.4) - 0	+/-10.0%
8" (203.2)	0.109" (2.77)	+0.061" (1.55)/-0.031" (0.79)	+1" (25.4) - 0	+/-10.0%

Applications

Chemical Processing: These tubes are commonly used in reactors, heat exchangers, and other equipment in the chemical manufacturing industry, where resistance to aggressive chemicals is crucial.
Oil and Gas: A249 TP316L welded tubes are used in pipelines, offshore platforms, and refineries, where durability and resistance to corrosion and high temperatures are necessary.
Food and Beverage: The hygienic properties and ease of cleaning make these tubes suitable for food processing, brewing, and dairy equipment, where sanitation is paramount.
Pharmaceuticals: In the pharmaceutical industry, the tubes are used in processes and equipment that require strict adherence to cleanliness and contamination prevention.
Power Generation: A249 TP316L tubes are utilized in nuclear and thermal power plants, including applications such as steam generators, heat exchangers, and similar equipment.
Marine Applications: Their excellent corrosion resistance makes them ideal for use in shipbuilding and marine equipment, helping to protect against seawater corrosion.
Cryogenic Applications: These tubes can handle cryogenic temperatures, making them suitable for use in cryogenic storage tanks and equipment used in the liquefaction of gases.
HVAC Systems: In heating, ventilation, and air conditioning (HVAC) applications, A249 TP316L tubes are used in heat exchangers and other components to improve efficiency and reliability.
Pulp and Paper Industries: They are utilized in various parts of pulp and paper manufacturing processes due to their resistance to chemical and cleaning agents used in these facilities.
Water Treatment: A249 TP316L tubes are also instrumental in water treatment facilities, particularly in systems that require resistance to corrosive elements present in water.
