Carbon Steel Seamless Tube ASTM A192 ASME SA192 Minimum Wall Thickness High Pressure Service Boiler Furnace Application

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG GROUP
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	EN 10216-1, EN 10216-2, DIN 17175, BS 3059 Part II, NF A 49-213, NBR 5594, GB 3087, GB 5310, JIS G3461

Payment & Shipping Terms:

Minimum Order Quantity:	300-500KGS
Price:	Negotiable
Packaging Details:	Wooden Box Package
Delivery Time:	25-30 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 SET/ month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Standard:	ASTM A192, ASME SA192	Size:	O.D.: 6.0~114.0; W.T.: 1~15; L: Max 12000
Thickness:	0.8 - 12 MM	Processing Service:	Decoiling, Bending, Cutting, Punching, Welding
Sureface:	Black Painting	Package:	Iron Fram Box Package
Highlight:	Boiler Furnace Carbon Steel Seamless Tube , ASTM A192 Carbon Steel Seamless Tube , ASME SA192 Carbon Steel Seamless Tube

Carbon Steel Seamless Tube ASTM A192 ASME SA192 Minimum Wall Thickness High Pressure Service Boiler Furnace Application

Yuhong Holding Group Co., Ltd. is a world-renowned manufacturer and exporter of high-quality heat exchanger tubes and industrial equipment. With over 20 years of export experience and a presence in 80 countries, we rank among the top five exporters of heat exchanger tubes in China. Our facility spans 20,000 m², housing 55 advanced production lines and over 110 skilled employees. We pride ourselves on delivering superior product quality and outstanding service to meet the needs of our global clients.

ASTM A192/A192M specifications covers minimum-wall-thickness, seamless carbon steel boiler and superheater tubes for high pressure service. The tubing sizes and thicknesses usually furnished to this specification are 1⁄2 in. to 7 in. [12.7 to 177.8 mm] outside diameter and 0.085 to 1.000 in. [2.2 to 25.4 mm], inclusive, in minimum wall thickness. Tubing having other dimensions may be furnished, provided such tubes comply with all other requirements of ASTM A192/A192M.

SA 192 Tube Specification

Standard	:	ASME SA 192 / ASTM A192
Size Range	:	O.D.:6.0~114.0; W.T.:1~15; L: max 12000
Outer Dimensions	:	6.0mm – 114.0mm
Wall Thickness	:	1mm – 15 mm
Length	:	max 27000mm

► Standards: ASTM A192 (ASME SA192)
► Applications: A wide range scope: heat exchangers, condensers, heat transfer equipment, similar pipes and as superheater tubes for high pressure settings.
► Grade: A 192

Chemistry Composition

C, %	Mn, %	Si, %	P, %	S, %
0.06-0.18	0.27-0.63	0.25 max	0.035 max	0.035 max

Mechanical Properties

Tensile Strength , MPa	Yield Strength , MPa	Elongation, %	Hardness, HB, WT≥5.1mm	Hardness, HRB, WT＜5.1mm
325 min	180 min	35 min	137 max	77 max

Outside Diameter & Tolerance

Hot rolled	Outside Diameter, mm	Tolerance, mm
	OD≤101.6	+0.4/-0.8
	101.6＜OD≤177.8	+0.4/-1.2
	Cold Drawn	Outside Diameter, mm	Tolerance, mm
OD＜25.4		±0.10
25.4≤OD≤38.1		±0.15
38.1＜OD＜50.8		±0.20
50.8≤OD＜63.5		±0.25
63.5≤OD＜76.2		±0.30
76.2≤OD≤101.6		±0.38
101.6＜OD≤177.8		+0.38/-0.64

High Pressure Boiler Tube:

Standard

Grade

Chemical Composition (%)

Mechenical Properties

(Mpa)TS

(Mpa)YS

(%)E

DIN17175

GB5310

20G

0.17-

0.24

0.17-

0.37

0.35-

0.65

≤

0.03

≤

0.03

410-550

≥245

≥24

MoG

0.17-

0.24

0.17-

0.38

0.70-

1.00

≤

0.03

≤

0.03

≥415

≥240

≥22

MoG

0.12-

0.20

0.17-

0.37

0.40-

0.80

≤

0.03

≤

0.03

0.25-

0.35

450-600

≥270

≥22

15Cr1

MoG

0.12-

0.18

0.17-

0.37

0.40-

0.70

≤

0.03

≤

0.03

0.80-

1.10

0.40-

0.55

440-640

≥235

≥21

12Cr2

MoG

0.08-

0.15

≤0.50

0.40-

0.70

≤

0.03

≤

0.03

2.00-

2.50

0.90-

1.20

450-600

≥280

≥20

12Cr1

MoVG

0.08-

0.15

0.17-

0.35

0.40-

0.70

≤

0.03

≤

0.03

0.90-

1.20

0.25-

0.35

0.15-

0.3

470-640

≥255

≥21

Application :

Our heat exchanger tubes are used for the cooling, heating or re-heating of fluids, gases, or air in a wide range of industries, such as chemical processing, hydrocarbon processing, and oil refining, nuclear power generation and aerospace.
