EN 10216-2 13CrMo4-5 1.7335 Seamless Boiler Tubes For Performance In High-Temperature

Product Details:

Place of Origin:	China
Brand Name:	YUHONG
Certification:	ISO9001-2008
Model Number:	EN10216-2 13CrMo4-5

Payment & Shipping Terms:

Minimum Order Quantity:	100 kgs
Price:	Negotiable
Packaging Details:	PLYWOOD CASE,BUNDLE,WOVEN BAG
Delivery Time:	Depends on quantity
Payment Terms:	T/T, L/C
Supply Ability:	100 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Standard:	EN10216-2	Grade:	13CrMo4-5 1.7335
O.D:	1/8"- 3" (3.2mm-76.2mm)	Type:	Seamless, Cold Drawn
Wall Thinkness:	MW.	Test:	ET, UT, HT, PT
Highlight:	13CrMo4-5 Seamless Boiler Tubes , 1.7335 Seamless Boiler Tubes , High Temperature Seamless Boiler Tubes

EN10216-2 13CrMo4-5 1.7335 Tube

EN 10216-2 13CrMo4-5 (1.7335) seamless tubes are engineered for high-pressure, high-temperature applications in energy and industrial sectors. Their balanced composition of chromium and molybdenum ensures reliable performance in steam and boiler systems.

13CrMo4-5 is a low alloy chromium-molybdenum steel optimized for high temperature applications.

Excellent creep strength and thermal fatigue resistance at elevated temperatures.

Better oxidation resistance in steam environments than ordinary carbon steels (e.g. P235GH).

High temperature strength: Mechanical properties are maintained up to 600°C (1112°F).

Creep resistance: Suitable for long term high temperature stress environments.

Good weldability: Requires pre- and post-weld heat treatment to avoid cracking.

Corrosion resistance: Moderate resistance to oxidation and scaling in steam/boiler environments.

EN 10216-2 13CrMo4-5 Seamless steel tubes shall be supplied in the relevant heat treatment conditions

Steel grade		Heat treatment a	Austenizing		Tempering
Steel name	Steel number	Heat treatment a	Temperature °C	Cooling Medium	Temperature °C	Cooling medium
13CrMo4-5	1.7335	+NT b c	900 to 960	Air	680 to 750	air

Chemical composition of EN 10216-2 13CrMo4-5

Steel grade	Steel number	C	Si	Mn	P max	Smax
13CrMo4-5	1.7335	0,10 to 0,17	≤ 0,35	0,40 to 0,70	0,025	0,020

Cr	Mo	Ni	Al tot	Cu
0,70 to 1,15	0,40 to 0,60	≤ 0,30	≤ 0,040	≤ 0,30

Mechanical properties of EN 10216-2 13CrMo4-5

Steel grade		Upper yield strength or proof strength R eH or Rp 0,2 for Wall Thickness Tmin.				Tensile Strength Rm	Elongation A min. % a
Steel name	Steel number	T ≤ 16	16 < T ≤ 40	40 < T ≤ 60	60 < T ≤ 100		l	t
		MPa *	MPa *	MPa *	MPa *	MPa *
13CrMo4-5	1.7335	290	290	280	-	440 to 590	22	20
