ASTM A334 GR.6 Hastelloy C-276 Tubes For Chemical Processing

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, ISO 9001
Model Number:	ASTM B334 GR.6

Payment & Shipping Terms:

Minimum Order Quantity:	300KG
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap/Woven Case
Delivery Time:	Depends on quantity
Payment Terms:	T/T,L/C
Supply Ability:	1000 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Sizing Options:

OD: 6-120 Mm | Wall Thickness: 1-10 Mm | Custom Cut-to-Length

Industry Applications:

Chemical Processing, FGD Systems, Offshore Oil & Gas, Pharmaceutical

Surface Finish:

Annealed & Pickled, Smooth Surface (Ra ≤1.6 μm)

High-Temperature Stability:

Service Temp Up To 400°C (752°F) In Oxidizing Atmospheres

Highlight:

Hastelloy C-276 Tubes

Chemical Processing Hastelloy C-276 Tubes

ASTM A334 GR.6 Hastelloy Tubes

ASTM A334 GR.6 Tubes – High-Performance Corrosion Resistance

1.Product Overview

ASTM A334 GR.6 (UNS N10276) tubes are made from Hastelloy C-276, a nickel-chromium-molybdenum alloy engineered for exceptional resistance to harsh environments, including oxidizing and reducing acids, chlorides, and seawater. Ideal for chemical processing, pollution control, and offshore applications.

2. Chemical Composition (ASTM B334 GR.6)

Element	Composition (% Weight)
Nickel (Ni)	Balance (≥52%)
Chromium (Cr)	14.5–16.5
Molybdenum (Mo)	15.0–17.0
Iron (Fe)	4.0–7.0
Tungsten (W)	3.0–4.5
Cobalt (Co)	≤2.5
Manganese (Mn)	≤1.0
Silicon (Si)	≤0.08
Carbon (C)	≤0.02
Sulfur (S)	≤0.01

3. Equivalent Grades

Property	Value (Room Temperature)
Tensile Strength	≥690 MPa (100 ksi)
Yield Strength (0.2% Offset)	≥283 MPa (41 ksi)
Elongation	≥40%
Hardness (Rockwell B)	≤100 HRB

4. Key Advantages

Superior Corrosion Resistance: Resists pitting, crevice corrosion, and stress corrosion cracking (SCC) in chloride-rich environments.
High-Temperature Stability: Maintains strength up to 400°C (752°F).
Weldability: Compatible with GTAW, GMAW, and SMAW processes without post-weld heat treatment.
Versatility: Suitable for both oxidizing (e.g., HNO₃) and reducing (e.g., HCl) media.

5. Applications of ASTM A334 GR.6 Tubes

Chemical Processing: Reactors, heat exchangers, and piping for sulfuric, hydrochloric, and acetic acid.
Pollution Control: Flue gas desulfurization (FGD) systems and scrubbers.
Oil & Gas: Offshore platforms, seawater cooling systems, and sour gas pipelines.
Pharmaceutical: Equipment handling aggressive solvents.

ASTM A334 GR.6 Hastelloy C-276 Tubes For Chemical Processing 0
