ASTM B111 C44300 Aluminum Brass Tubes

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, ISO 9001
Model Number:	ASTM B111 C44300

Payment & Shipping Terms:

Minimum Order Quantity:	300KG
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap/Woven Case
Delivery Time:	Depends on quantity
Payment Terms:	T/T,L/C
Supply Ability:	1000 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Material Specification:	UNS C44300 (CuZn21Al1As) \| ASTM B111 Seamless Aluminum Brass Tubes	Compliance Standards:	ASME SB111 \| EN 12451 \| NACE MR0175 \| PED 2014/68/EU
Available Sizes:	OD 10mm-100mm \| Wall Thickness 1.0mm-5.0mm \| Seamless Drawn (Mandrel Process)	Operating Temperature:	-40°C To 150°C (-40°F To 302°F) \| Chloride Tolerance ≤5,000 Ppm

ASTM B111 C44300 Aluminum Brass Tubes: High-Performance Seawater Corrosion Resistance

ASTM B111 C44300 (UNS C44300) is a lead-free aluminum brass alloy specifically engineered for marine and industrial applications requiring exceptional resistance to dezincification, erosion, and biofouling. These seamless tubes are ideal for condensers, heat exchangers, and desalination systems operating in seawater or brackish environments.

Key Features:

Material Type: CuZn21Al1As (Aluminum Brass with Arsenic addition)
Standards: ASTM B111, ASME SB111, EN 12451
Temperature Range: -40°C to 150°C (-40°F to 302°F)
Certifications: NACE MR0175, ISO 9001:2015

C44300 Chemical Composition (ASTM B111)

Element	Min (%)	Max (%)	Role in Alloy
Copper (Cu)	70.0	73.0	Base metal for corrosion resistance
Zinc (Zn)	26.7	29.3	Enhances strength and workability
Arsenic (As)	0.02	0.10	Prevents dezincification in seawater
Aluminum (Al)	-	0.02	Improves oxide layer adhesion
Iron (Fe)	-	0.06	Controlled impurity
Lead (Pb)	-	0.07	Maintains machinability

Equivalent Grades & International Standards

Standard	Grade	Region/Application
UNS	C44300	Global marine systems
EN	CW702R	European heat exchangers
DIN	2.0460	German shipbuilding
JIS	C6870	Japanese condensers
GB	HAl77-2	Chinese industrial standards

Mechanical Properties of C44300 Tubes

Property	Annealed Condition	Hard Temper	Test Method
Tensile Strength (MPa)	340 - 410	440 - 520	ASTM E8/E8M
Yield Strength (MPa)	≥125	≥275	ASTM E8/E8M
Elongation (%)	≥45	≥15	ASTM E8/E8M
Hardness (Rockwell B)	65 - 75	80 - 90	ASTM E18
Thermal Conductivity (W/m·K)	116	105	ASTM E1225

Industrial Applications of C44300 Tubes

Industry	Typical Uses	Performance Advantage
Marine Engineering	Shipboard condensers, desalination plant heat exchangers	Resists biofouling and saltwater pitting (0.05 mm/year corrosion rate)
Power Generation	Steam turbine cooling systems, nuclear plant tubing	Withstands high-velocity seawater (up to 3 m/s)
Oil & Gas	Offshore platform cooling loops, LNG heat exchangers	Compatible with chlorinated fluids (up to 5 ppm Cl⁻)
Chemical Processing	Acidic fluid transfer systems, evaporators	Stable in pH 6-8.5 environments

Why Choose ASTM B111 C44300 Tubes?

Superior Lifespan: 20-30 years in seawater applications (vs. 10-15 years for Admiralty Brass).
Cost-Efficiency: 15-20% lower lifecycle cost compared to titanium alternatives.
Manufacturing Flexibility: Available as seamless/ERW tubes, U-bends, or custom lengths (1-12 meters).
Testing Guarantee: 100% eddy current tested (ASTM E309), hydrostatic pressure tested (ASTM B88).
