​​TEMA Class R Exchanger: Carbon Steel Seamless Tubes Bundle, 1.5×Hydrotest per ASME Sec VIII

​​TEMA Class R Exchanger: Carbon Steel Seamless Tubes Bundle, 1.5×Hydrotest per ASME Sec VIII

TEMA Class R Carbon Steel Heat Exchanger meets stringent ASME Section VIII and TEMA standards which ensures safety, reliability, and long-term performance in demanding industrial environments.

1. Advantages of Carbon Steel Tube Bundles

2. ITP (Inspection and Test Plan) for Carbon Steel Tube Bundles

3. Hydrostatic Testing Requirements and Procedure

Key Requirements:

• Test Standard: ASME Section VIII Division 1.
• Pressure: 1.5× design working pressure.
• Hold Time: 2 hours usually we do.

Testing Procedure:

1. Preparation:

   • Assemble the tube bundle and ensure all openings are sealed with appropriate caps or plugs.

2. Pressurization:

   • Using a calibrated hydraulic pump, gradually increase pressure to the required test level (1.5× design pressure).

3. Hold Period:

   • Inspect all welds, connections, and surfaces for visible leaks or deformation

4. De-pressurization:

   • Slowly release the pressure after the test duration to avoid damage to the tube bundle.

5. Post-Test Inspection:

   • Record test results and prepare a detailed hydrotest report for client approval
