ASTM A269 TP304 Stainless Steel Seamless Tube Pickled Annealed for Heat Exchanger and General Service

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A269 TP304

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	7DAYS
Payment Terms:	L/C,T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Standard:	ASTM A269	Material:	TP304
NDT:	UT/ET	Surface:	Pickled And Annealed
Packing:	Ply-wooden Case Or Iron Case	Application:	Chemical And Petrochemical/Food And Beverage Processing/HVAC Systems
Highlight:	ASTM A269 stainless steel seamless tube , TP304 pickled annealed tubing , heat exchanger stainless steel tube

ASTM A269 TP304 Stainless Steel Seamless Tube Pickled Annealed for Heat Exchanger and General Service

ASTM A269 is one of the most widely used standards for austenitic stainless steel tubes, typically covering smaller outer diameters and relatively thin wall thicknesses from capillaries. For applications such as high-temperature and high-pressure boilers, superheaters, and heat exchangers, ASTM A213 TP304 should be preferred. This standard has stricter requirements for the chemical composition, mechanical properties (especially high-temperature performance), and non-destructive testing of seamless tubes, while ASTM A269 focuses more on "general service" conditions.

Why Choose ASTM A269 TP304 Stainless Steel Seamless Tube?

Versatility and Maturity: TP304 is one of the most commonly used and proven stainless steel grades, with extensive performance data and application experience.
Excellent Overall Performance: ASTM A269 TP304 seamless stainless steel tube offers an excellent balance of corrosion resistance, strength, toughness, formability, and weldability, making it suitable for a wide range of applications.
Good Processability: ASTM A269 TP304 seamless stainless steel tube is easy to bend, form, weld, and install.
High Cleanliness: ASTM A269 TP304 seamless stainless steel tube has a smooth inner wall that resists media retention and is easy to clean and sterilize, making it ideal for the food and pharmaceutical industries.
Advantages of Seamless Construction: No longitudinal welds provide greater structural integrity, generally better pressure-bearing capacity, and a more uniform internal and external surface, reducing the risk of leaks.

ASTM A269 Stainless Steel Seamless Tubes Mechanical Properties

SS GRADE	HEAT TREATMENT	TEMPERURE F (C) MINIMUM	HARDNESS
			BRINELL	ROCKWELL
TP304	Solution	1900(1040)	192HBW/ 200HV	90HRB

ASTM A269 Standard Tubing Chemical Composition

GRADE	ASTM A269 CHEMICAL COMPOSITION % MAXIMUM
GRADE	C	MN	P	S	SI	CR	NI
TP304	0.08	2.00	0.045	0.030	1.00	18.0-20.0	8.0-11.0

ASTM A269 Stainless Steel Tube Tolerance

OD, INCH	OD TOLERANCE INCH(MM)	WT TOLERANCE %	LENGTH TOLERNACE INCH(MM)
OD, INCH	OD TOLERANCE INCH(MM)	WT TOLERANCE %	+	-
≤1 /2	± 0.005 ( 0.13 )	±15	1 /8 ( 3.2 )	0
> 1 /2~1 1 /2	±0.005(0.13)	±10	1 /8(3.2)	0
> 1 1 /2~< 3 1 /2	± 0.010(0.25)	±10	3 /16(4.8)	0
> 3 1 /2~< 5 1 /2	± 0.015(0.38)	±10	3 /16(4.8)	0
> 5 1 /2~< 8	± 0.030(0.76)	±10	3 /16(4.8)	0
8~< 12	± 0.040(1.01)	±10	3 /16(4.8)	0
12~< 14	± 0.050(1.26)	±10	3 /16(4.8)	0

ASTM A269 TP304 Stainless Steel Seamless Tube Main Application

Food and Beverage Industry: Piping, brewing equipment, milk processing lines, juice piping, etc.
Pharmaceutical and Biotechnology: Process piping, purified water systems, water for injection systems, fermenters, etc.
Chemical and Petrochemical Industry: Used for conveying non-corrosive chemicals, solvents, and intermediates.
Heat Exchangers and Condensers: Used as heat transfer tubes in various shell-and-tube heat exchangers.
Instrumentation and Control Systems: Instrument ducts, pressure gauge tubing, sampling tubing, etc.
High-Cleanliness Semiconductor Industry: Also used in the conveying of certain gases and chemicals where extreme conditions are not required.
