ASTM A249 TP310S Stainless Steel Welded Tubes For Power Generation
ASTM A249 standard for stainless steel welded tubes, the wall thickness can be avg. or min. wall thickness, usually clients will choose min. wall thickness used in heat exchangers and boilers,or condenser, etc.
Chemical Composition % Max
| Material |
C |
Mn |
P |
S |
Si |
Cr |
Ni |
| TP310S |
0.08 |
2.00 |
0.045 |
0.03 |
1.00 |
24.0-26.0 |
19.0-22.0 |
Mechanical Property
| Material |
Tensile Strength min |
Yield Strength min |
Elongation (%) |
Rockwell Hardness Number,max |
| TP310S |
75ksi ( 515MPa ) |
30ksi ( 205MPa ) |
35 min |
B90 |
Advantages
TP310S material is a high-grade austenitic stainless steel with excellent oxidation & carburization resistance, is widely used in extreme-temperature environments.
1.Exceptional High-Temperature Performance:
Withstands continuous service up to 1150°C (2100°F) and intermittent exposure to 1035°C (1900°F).
Superior oxidation & carburization resistance compared to 304/316, ideal for furnaces, kilns, and exhaust systems.
2.Outstanding Corrosion Resistance:
High chromium (25%) and nickel (20%) content resists
Key Applications
1.Petrochemical & Refining
· Crackers, reformers, and pyrolysis tube
· Catalyst support grids in harsh chemical environments
2.Power Generation
· Boiler superheaters & heat exchangers
· Waste-to-energy (WTE) plants for flue gas handling
· Nuclear auxiliary systems (non-core components)
3.High-Temperature Processing
· Furnace components (radiant tubes, muffles, rollers)
· Heat treatment & annealing equipment
· Kilns and ceramic firing systems
