High-Temperature ASTM A335 P11 Seamless Pipe Petrochemical & Power Plant Piping

High-Temperature ASTM A335 P11 Seamless Pipe Petrochemical & Power Plant Piping

  • High-Temperature ASTM A335 P11 Seamless Pipe Petrochemical & Power Plant Piping
  • High-Temperature ASTM A335 P11 Seamless Pipe Petrochemical & Power Plant Piping
  • High-Temperature ASTM A335 P11 Seamless Pipe Petrochemical & Power Plant Piping
  • High-Temperature ASTM A335 P11 Seamless Pipe Petrochemical & Power Plant Piping
High-Temperature ASTM A335 P11 Seamless Pipe Petrochemical & Power Plant Piping
Product Details:
Place of Origin: CHIAN
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM A335 P11 Seamless Pipe
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap/Woven Case
Delivery Time: Depends on quantity
Payment Terms: L/C,T/T
Supply Ability: 1000 tons per month
Contact Now
All Products
Stainless Steel Seamless Pipe (308)
Stainless Steel Seamless Tube (297)
Duplex Stainless Steel Pipe (132)
Duplex Stainless Steel Tube (33)
Needle Tube (134)
Fin Tube (672)
Heat Exchanger (20)
Heat Exchanger Tube (443)
Heat Exchanger Tube Bundle (40)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (37)
Air Cooler (9)
Pressure Vessel (4)
Stainless Steel Welded Pipe (58)
Stainless Steel Welded Tube (120)
Nickel Alloy Pipe (266)
Nickel Alloy Tube (92)
Copper Alloy Tube (240)
Alloy Steel Tube (204)
Titanium Tube (15)
Bright Annealed Tube (155)
Boiler Tube (151)
Steel Fitting (826)
Steel Flange (615)
Others (401)
Cladding Parts (7)
Detailed Product Description
Standard Specification: ASTM A335 / ASME SA-335 Material Designation: P11 / Grade P11
Optional NDT: UT, RT, PMI, Hardness Test Manufacturing Process: Seamless (SMLS)
End Preparation: Plain End / Beveled End Size Range (NPS): 1/2" To 24"
Wall Thickness: SCH 40, 80, 160, XXS Service Environment: High-Temperature Piping Systems
Highlight:

ASTM A335 P11 seamless pipe

,

high-temperature alloy steel tube

,

petrochemical power plant piping


ASTM A335 P11 Alloy Steel Seamless Pipe: High-Temperature Service Solution



1. ASTM A335 P11 Material Overview


ASTM A335 P11 seamless pipe is a chromium-molybdenum alloy steel designed for high-temperature service. Key characteristics:


  • Manufacturing Process: Hot-finished seamless (SMLS)


  • Key Alloy Elements: 1.25% Cr, 0.5% Mo (enhanced creep resistance)


  • Temperature Range: -29°C to 593°C (-20°F to 1100°F)


  • Standard Compliance: ASTM A335 / ASME SA-335


  • Certification: EN 10204 3.1/3.2 with PMI test reports


2. ASTM A335 P11 Chemical Composition


Maximum percentages unless range specified


Element Composition (%) ASTM A335 Requirement
Carbon 0.05 - 0.15 0.05 - 0.15
Manganese 0.30 - 0.60 0.30 - 0.60¹
Phosphorus ≤0.025 ≤0.025
Sulfur ≤0.025 ≤0.025
Silicon 0.50 - 1.00 0.50 - 1.00
Chromium 1.00 - 1.50 1.00 - 1.50
Molybdenum 0.44 - 0.65 0.44 - 0.65


3. ASTM A335 P11 Equivalent Grades


Global material cross-references


Standard Equivalent Grade Note
EN 13CrMo4-5 EN 10216-2
DIN 13CrMo44 DIN 17175
JIS STPA23 JIS G3458
GOST 15KhM GOST 550-75
UNS Number K11597 Unified Numbering System


4. ASTM A335 P11 Mechanical Properties


Minimum requirements per ASTM A335


Property Value Test Method
Tensile Strength ≥415 MPa (60,000 psi) ASTM A370
Yield Strength ≥205 MPa (30,000 psi) ASTM A370
Elongation ≥30% (2" gauge length) ASTM A370
Hardness ≤197 HBW / 92 HRB ASTM E18/E10
Heat Treatment Full Anneal / Normalize & Temper Mandatory


5. ASTM A335 P11 Dimensional Tolerances


Compliant with ASME B36.10M


Parameter Tolerance Standard Reference
Outer Diameter (NPS ≤4) ±0.79 mm (0.031") ASME B36.10
Outer Diameter (NPS >4) +0.25% / -0.12% of OD ASME B36.10
Wall Thickness +20% / -12.5% of nominal wall ASTM A335
Straightness ≤0.2% of length ASTM A530
Length (Random) 6-7 m (±100 mm) Commercial practice


6. ASTM A335 P11 Application Areas


High-performance service environments


  • Power Generation
    Boiler superheaters, steam lines, turbine piping (ASME B31.1 compliant)


  • Petrochemical Processing
    Refinery furnace tubes, catalytic cracker lines, hydrogen service


  • Oil & Gas
    Wellhead components, flow lines (NACE MR0175 compatible)


  • High-Temperature Utilities
    Heat exchangers, thermal fluid systems, expansion joints
